NVIDIA GeForce 930MX

The Nvidia GeForce 930MX is an entry-level DirectX 12 graphics card for laptops that was announced in the first quarter of 2016. It is the refresh of the GeForce 930M and now supports GDDR5 graphics memory. It is based on the same GM108 chip and may feature slightly increased clock rates. Therefore, it should perform similar to the Maxwell GPU in the Surface Book (see for benchmarks).

The performance will depend on the used graphics memory. With fast GDDR5 it should be similar or slightly faster than the Maxwell GPU in the Surface Book. With DDR3 it will be somewhere between the old 930M and 940M.

See our 920MX, 930MX, 940MX rumor news article for details on what is known so far.

Manufacturer

NVIDIA

GeForce 900M Series

GeForce 945M (compare)	512 @ 928 - 1045 (Boost) MHz	128 Bit @ 2000 MHz
Maxwell GPU (940M, GDDR5) (compare)	384 @ 954 - 993 (Boost) MHz	64 Bit @ 5012 MHz
GeForce 940MX (compare)	384 @ 1122 - 1242 (Boost) MHz	64 Bit
GeForce 940M (compare)	384 @ 1072 - 1176 (Boost) MHz	64 Bit @ 2000 MHz
GeForce 930MX	384 @ 952 - 1020 (Boost) MHz	64 Bit @ 2000 MHz
GeForce 930M (compare)	384 @ 928 - 941 (Boost) MHz	64 Bit @ 1800 MHz
GeForce 920MX (compare)	256 @ 965 - 993 (Boost) MHz	64 Bit @ 1800 MHz
GeForce 920M (compare)	384 @ 954 MHz	64 Bit @ 1800 MHz
GeForce 910M (compare)	384 @ 641 MHz	64 Bit @ 2000 MHz

Codename

N16S-GMR

Architecture

Maxwell

Pipelines

384 - unified

Core Speed

952 - 1020 (Boost) MHz

Memory Speed

2000 MHz

Memory Bus Width

64 Bit

Memory Type

GDDR5/DDR3

Shared Memory

DirectX

DirectX 12 (FL 11_0), Shader 5.0

technology

28 nm

Features

GPU Boost 2.0, Optimus, PhysX, CUDA, GeForce Experience

Date of Announcement

10.03.2016

Link to Manufacturer Page

http://www.geforce.com/hardware/notebook...

Benchmarks

3DMark - Ice Storm Extreme Graphics 1920x1080

58151 Points (8%)

+ 1 benchmarks and specifications + Show comparison chart

3DMark - Cloud Gate Standard Score 1280x720

min: 6639 avg: 6949 median: 7001 (14%) max: 7147 Points

+ 5 benchmarks and specifications + Show comparison chart

3DMark - Cloud Gate Standard Graphics 1280x720

min: 8187 avg: 8892.4 median: 9056 (6%) max: 9122 Points

+ 5 benchmarks and specifications + Show comparison chart

3DMark - Fire Strike Score 1920x1080

min: 1340 avg: 1411 median: 1410 (6%) max: 1454 Points

+ 5 benchmarks and specifications + Show comparison chart

3DMark - Fire Strike Graphics 1920x1080

min: 1502 avg: 1580.6 median: 1573 (4%) max: 1637 Points

+ 5 benchmarks and specifications + Show comparison chart

3DMark - Ice Storm Standard Graphics 1280x720

min: 54961 avg: 64695.3 median: 57396 (8%) max: 81729 Points

+ 3 benchmarks and specifications + Show comparison chart

3DMark 11 - Performance 1280x720

min: 2100 avg: 2297.4 median: 2336 (8%) max: 2400 points

+ 7 benchmarks and specifications + Show comparison chart

3DMark 11 - Performance GPU 1280x720

min: 2092 avg: 2182.8 median: 2197 (4%) max: 2259 points

+ 5 benchmarks and specifications - Hide comparison chart

Intel Graphics Media Accelerator (GMA) 3600

...

AMD Radeon HD 7750M -4%

NVIDIA Quadro 4000M -4%

NVIDIA GeForce GT 650M -4%

AMD Radeon HD 7770M -3%

AMD Radeon HD 7660G + HD 7670M Dual Graphics -3%

AMD Radeon R7 M460 -2%

NVIDIA GeForce 930M -2%

AMD FirePro W4190M -1%

NVIDIA Maxwell GPU Surface Book (940M, GDDR5) -1%

NVIDIA GeForce 930MX

NVIDIA GeForce GTX 480M 0%

Intel Iris Graphics 540 0%

AMD Radeon HD 8790M 0%

AMD Radeon R6 M255DX 1%

AMD Radeon R7 M445 1%

NVIDIA GeForce GT 745M 1%

AMD Radeon R7 M440 3%

NVIDIA GeForce GTX 550 Ti 4%

NVIDIA GeForce 840M 5%

...

NVIDIA GeForce GTX 1070 SLI (Laptop) 1920%

100%

3DMark Vantage
P Result 1280x1024 +

P GPU no PhysX 1280x1024 +

3DMark 06 Standard 1280x1024 +

SPECviewperf 11
Siemens NX 1920x1080 +

Tcvis 1920x1080 +

SolidWorks 1920x1080 +

Pro/ENGINEER 1920x1080 +

Maya 1920x1080 +

Lightwave 1920x1080 +

Ensight 1920x1080 +

Catia 1920x1080 +

SPECviewperf 12
Solidworks (sw-03) 1900x1060 +

Siemens NX (snx-02) 1900x1060 +

Showcase (showcase-01) 1900x1060 +

Medical (medical-01) 1900x1060 +

Maya (maya-04) 1900x1060 +

Energy (energy-01) 1900x1060 +

Creo (creo-01) 1900x1060 +

Catia (catia-04) 1900x1060 +

Cinebench R10 Shading 32Bit +

Cinebench R11.5 OpenGL 64Bit +

Cinebench R15
OpenGL 64Bit +

Ref. Match 64Bit +

GFXBench (DX / GLBenchmark) 2.7
T-Rex HD Offscreen C24Z16 1920x1080 +

T-Rex HD Onscreen C24Z16 +

GFXBench 3.0 - Manhattan Offscreen OGL off screen

66.8 fps (12%)

+ 1 benchmarks and specifications + Show comparison chart

GFXBench 3.0 - Manhattan Onscreen OGL on screen

53.9 fps (15%)

+ 1 benchmarks and specifications + Show comparison chart

LuxMark v2.0 64Bit - Room GPUs-only

min: 264 avg: 290 median: 264 (5%) max: 342 Samples/s

+ 3 benchmarks and specifications + Show comparison chart

LuxMark v2.0 64Bit - Sala GPUs-only

min: 543 avg: 571 median: 544 (5%) max: 626 Samples/s

+ 3 benchmarks and specifications + Show comparison chart

ComputeMark v2.1 - Normal, Score 1024x600

min: 1535 avg: 1587.5 median: 1587.5 (7%) max: 1640 Points

+ 2 benchmarks and specifications + Show comparison chart

- Range of benchmark values for this graphics card

- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailled information on the benchmark results, click on the fps number.

Dishonored 2

2016

23.6 fps + Compare

19.7 fps + Compare

» The benchmarks indicate that the game is not playable in the tested settings.

Call of Duty Infinite Warfare

2016

28.2 fps + Compare

25.6 fps + Compare

» The benchmarks indicate that the game is not playable in the tested settings.

Titanfall 2

2016

61.6 fps + Compare

50.2 fps + Compare

27.9 fps + Compare

22.8 fps + Compare

» With all tested laptops playable in detail settings med..

Battlefield 1

2016

45.5 fps + Compare

29.7 fps + Compare

13.4 fps + Compare

12 fps + Compare

» With all tested laptops playable in detail settings low.

Deus Ex Mankind Divided

2016

22.4 fps + Compare

15.3 fps + Compare

Model	CPU	Memory	Core / Memory	GPU Memory	Value
HP ProBook 470 G4 Z2Y46ES	7500U	32768 MB	952 / 1001 MHz	2048MB DDR3 (Samsung) ForceWare 369.37	58151

Model	CPU	Memory	Core / Memory	GPU Memory	Value
HP Envy x360 15t-w200	7500U	8192 MB	952 - 1020 / 900 MHz	2048MB 21.20.16.4471	6639
HP ProBook 450 G4 Y8B60EA	7500U	8192 MB		2048MB DDR3 10.18.13.6871	6908
HP ProBook 440 G4-Y8B51EA	7500U	8192 MB	952 / 1000 MHz	2048MB DDR3 ForceWare 368.71	7001
HP ProBook 470 G4	7500U	8192 MB	1019 / 1000 MHz	2048MB Forceware 368.71	7050
HP ProBook 470 G4 Z2Y46ES	7500U	32768 MB	952 / 1001 MHz	2048MB DDR3 (Samsung) ForceWare 369.37	7147

Model	CPU	Memory	Core / Memory	GPU Memory	Value
HP Envy x360 15t-w200	7500U	8192 MB	952 - 1020 / 900 MHz	2048MB 21.20.16.4471	8187
HP ProBook 470 G4 Z2Y46ES	7500U	32768 MB	952 / 1001 MHz	2048MB DDR3 (Samsung) ForceWare 369.37	9031
HP ProBook 440 G4-Y8B51EA	7500U	8192 MB	952 / 1000 MHz	2048MB DDR3 ForceWare 368.71	9056
HP ProBook 470 G4	7500U	8192 MB	1019 / 1000 MHz	2048MB Forceware 368.71	9066
HP ProBook 450 G4 Y8B60EA	7500U	8192 MB		2048MB DDR3 10.18.13.6871	9122

Model	CPU	Memory	Core / Memory	GPU Memory	Value
HP Envy x360 15t-w200	7500U	8192 MB	952 - 1020 / 900 MHz	2048MB 21.20.16.4471	1340
HP ProBook 470 G4	7500U	8192 MB	1019 / 1000 MHz	2048MB Forceware 368.71	1407
HP ProBook 470 G4 Z2Y46ES	7500U	32768 MB	952 / 1001 MHz	2048MB DDR3 (Samsung) ForceWare 369.37	1410
HP ProBook 440 G4-Y8B51EA	7500U	8192 MB	952 / 1000 MHz	2048MB DDR3 ForceWare 368.71	1444
HP ProBook 450 G4 Y8B60EA	7500U	8192 MB		2048MB DDR3 10.18.13.6871	1454

Model	CPU	Memory	Core / Memory	GPU Memory	Value
HP Envy x360 15t-w200	7500U	8192 MB	952 - 1020 / 900 MHz	2048MB 21.20.16.4471	1502
HP ProBook 470 G4 Z2Y46ES	7500U	32768 MB	952 / 1001 MHz	2048MB DDR3 (Samsung) ForceWare 369.37	1570
HP ProBook 470 G4	7500U	8192 MB	1019 / 1000 MHz	2048MB Forceware 368.71	1573
HP ProBook 440 G4-Y8B51EA	7500U	8192 MB	952 / 1000 MHz	2048MB DDR3 ForceWare 368.71	1621
HP ProBook 450 G4 Y8B60EA	7500U	8192 MB		2048MB DDR3 10.18.13.6871	1637
