NVIDIA Quadro M4000M

NVIDIA Quadro M4000M

The Nvidia Quadro M4000M is a high-end, DirectX 12 (FL_12_1) and OpenGL 4.5-compatible graphics card for mobile workstations. It is a Maxwell-based GPU built on the GM204 chip with all 1280 of the 1536 shader cores activated and is manufactured in 28 nm at TSMC. Therefore, the GPU is similar to the consumer Nvidia GeForce GTX 970M. The Quadro M4000M is built for the Intel Skylake generation and is a successor to the Quadro K4100M (Kepler-based). The M4000M usually comes with 4 GB GDDR5 VRAM clocked at 1250 MHz (5000 MHz effective, 160 GB/s opposed to 102.4 GB/s of the K4100M).

The Quadro series offers certified drivers that are optimized for stability and performance in professional applications like CAD or DCC. OpenGL performance, for example, should be significantly better compared to GeForce graphics cards of similar specifications.

Performance

The clock speeds of the Quadro M4000M are very similar to the GTX 970M based on the same chip. The base clock is slightly higher with 975 versus 924 MHz but the Boost speed is lower at 1013 versus 1038 MHz. Therefore, with good cooling the GTX 970M should be slightly faster. Compared to the Quadro line-up, it is the second fastest Quadro card in 2015 and therefore clearly faster than the old Quadro K4100M.

Using CUDA (Compute Capability 5.2) or OpenCL 1.2, the cores of the Quadro M4000M can be used for general calculations.

Power Consumption

The power consumption of the Quadro M4000M is rated at the same TGP of 100 Watt as the M5000M and older K5100M/K4100M (including the board and memory components). Therefore, the card is suited for large notebooks with 17-inch displays or greater.

ManufacturerNVIDIA
Quadro M Series
Quadro M5500 2048 @ 1139 - 1140 (Boost) MHz256 Bit @ 6606 MHz
Quadro M5000M 1536 @ 962 - 1051 (Boost) MHz256 Bit @ 5000 MHz
Quadro M4000M 1280 @ 975 - 1013 (Boost) MHz256 Bit @ 5012 MHz
Quadro M3000M 1024 @ 1050 MHz256 Bit @ 5000 MHz
Quadro M2200 1024 @ 694 - 1038 (Boost) MHz128 Bit @ 5508 MHz
Quadro M1200 640 @ 991 - 1150 (Boost) MHz128 Bit @ 5000 MHz
Quadro M2000M 640 @ 1038 - 1197 (Boost) MHz128 Bit @ 5000 MHz
Quadro M1000M 512 @ 993 - 1072 (Boost) MHz128 Bit @ 5000 MHz
Quadro M620 512 128 Bit @ 5000 MHz
Quadro M520 384 @ 756 - 1019 (Boost) MHz64 Bit
Quadro M600M 384 @ 837 - 876 (Boost) MHz128 Bit @ 5012 MHz
Quadro M500M 384 @ 1029 - 1124 (Boost) MHz64 Bit @ 4004 MHz
ArchitectureMaxwell
Pipelines1280 - unified
Core Speed *975 - 1013 (Boost) MHz
Memory Speed *5012 MHz
Memory Bus Width256 Bit
Memory TypeGDDR5
Max. Amount of Memory4096 MB
Shared Memoryno
DirectXDirectX 12_1, Shader 5.0
Power Consumption100 Watt
Transistors5200 Million
technology28 nm
FeaturesOptimus, PhysX, 3D Vision Pro, nView, Optimus
Notebook Sizelarge
Date of Announcement02.10.2015
Link to Manufacturer Pagehttp://www.nvidia.com/object/quadro-for-...
* The specified clock rates are only guidelines for the manufacturer and can be altered by them.

Benchmarks

Cinebench R15
Ref. Match 64Bit +
OpenGL 64Bit +
3DMark - Cloud Gate Standard Score 1280x720
0%
100%
min: 13452     avg: 17686 (36%)     median: 17686 (36%)     max: 21920 Points
3DMark - Ice Storm Standard Graphics 1280x720
0%
100%
min: 218874     avg: 218874 (29%)     median: 218874 (29%)     max: 218874 Points
3DMark 11 - Performance 1280x720
0%
100%
min: 9042     avg: 9295.5 (32%)     median: 9295.5 (32%)     max: 9549 points
SPECviewperf 12
Solidworks (sw-03) 1900x1060 +
Siemens NX (snx-02) 1900x1060 +
Showcase (showcase-01) 1900x1060 +
Medical (medical-01) 1900x1060 +
Maya (maya-04) 1900x1060 +
Energy (energy-01) 1900x1060 +
Creo (creo-01) 1900x1060 +
Catia (catia-04) 1900x1060 +
SPECviewperf 11
Siemens NX 1920x1080 +
Tcvis 1920x1080 +
SolidWorks 1920x1080 +
Pro/ENGINEER 1920x1080 +
Maya 1920x1080 +
Lightwave 1920x1080 +
Ensight 1920x1080 +
Catia 1920x1080 +
Cinebench R11.5 OpenGL 64Bit +
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailled information on the benchmark results, click on the fps number.

Rise of the Tomb Raider
med. 1366x768
90  fps    + Compare
high 1920x1080
55  fps    + Compare
ultra 1920x1080
48  fps    + Compare
3840x2160
20  fps    + Compare
» With all tested laptops playable in detail settings ultra.
BioShock Infinite
med. 1366x768
196  fps    + Compare
high 1366x768
181  fps    + Compare
ultra 1920x1080
85  fps    + Compare
» With all tested laptops playable in detail settings ultra.
For more games that might be playable and a list of all games and graphics cards visit our Gaming List

Notebook reviews with NVIDIA Quadro M4000M graphics card

Lenovo ThinkPad P70-20ER000XUS: Intel Xeon E3-1505M v5, 17.3", 3.7 kg
  Review » Lenovo ThinkPad P70-20ER000XUS Workstation Review

Lenovo ThinkPad P70-20ER000CGE: Intel Xeon E3-1505M v5, 17.3", 3.4 kg
  External Review » Lenovo ThinkPad P70-20ER000CGE
