NVIDIA GeForce RTX 5060 Laptop

The Nvidia GeForce RTX 5060 Laptop is a mobile graphics card from the Blackwell family for laptops, which Team Green presented in April 2025 and became available in May. It is based on the GB206 chip and offers 3328 shader / CUDA cores, 104 tensor cores and 26 ray tracing units. The 8 GB GDDR7 graphics memory is connected via a 128-bit memory bus. Other features of the GPU include native PCIe 5 support, DisplayPort 2.1a, DirectX 12_2 Ultimate and support for DLSS4 and Reflex 2.
Performance
As always, the performance depends on the cooling and the maximum power consumption (TGP) of the RTX 5060 Laptop. In synthetic benchmarks, the new card is just ahead of the old RTX 4070 Laptop GPU in synthetic benchmarks. In our gaming tests, however, the mobile RTX 4070 is still slightly faster. As a result, the GPU is recommended for QHD gaming with maximum settings and DLSS or slightly reduced detail level in demanding games (such as F1 25).
Power consumption
The chip can be configured from 45 to 100 watts TGP and can be clocked differently accordingly. With 45 watts TGP, for example, the GP clocks from 952 - 1455 MHz, at the full 100 watts with 1950 - 2310 MHz.
The chip is produced in the 5nm process at TSMC (4N FinFET).
GeForce RTX 5000 Laptop GPU Series
| |||||||||||||||||||
| Codename | GN22-X4 | ||||||||||||||||||
| Architecture | Blackwell | ||||||||||||||||||
| Pipelines | 3328 - unified | ||||||||||||||||||
| TMUs | 104 | ||||||||||||||||||
| ROPs | 48 | ||||||||||||||||||
| Raytracing Cores | 26 | ||||||||||||||||||
| Tensor / AI Cores | 104 | ||||||||||||||||||
| Core Speed | 952 - 1455 (Boost) MHz | ||||||||||||||||||
| Theoretical Performance | 9.684 TFLOPS FP16, 9.684 TFLOPS FP32 | ||||||||||||||||||
| AI GPU | 572 TOPS INT8 | ||||||||||||||||||
| Cache | L1: 3.3 MB, L2: 32 MB | ||||||||||||||||||
| Memory Speed | 24000 effective = 1500 MHz | ||||||||||||||||||
| Memory Bus Width | 128 Bit | ||||||||||||||||||
| Memory Type | GDDR7 | ||||||||||||||||||
| Max. Amount of Memory | 8 GB | ||||||||||||||||||
| Shared Memory | no | ||||||||||||||||||
| Memory Bandwidth | 384 GB/s | ||||||||||||||||||
| API | DirectX 12_2, Shader 6.8, OpenGL 4.6, OpenCL 3.0, Vulkan 1.4 | ||||||||||||||||||
| Power Consumption | 100 Watt (45 - 100 Watt TGP) | ||||||||||||||||||
| Transistor Count | 21.9 Billion | ||||||||||||||||||
| Die Size | 181 mm² | ||||||||||||||||||
| Man. Technology | 5 nm | ||||||||||||||||||
| PCIe | 5 | ||||||||||||||||||
| Displays | 4 Displays (max.), DisplayPort 2.1a | ||||||||||||||||||
| Features | DLSS4, Reflex 2, CUDA 12.8 | ||||||||||||||||||
| Notebook Size | medium sized | ||||||||||||||||||
| Date of Announcement | 02.01.2025 | ||||||||||||||||||
| Link to Manufacturer Page | www.nvidia.com | ||||||||||||||||||
| Predecessor | GeForce RTX 4060 Laptop GPU | ||||||||||||||||||
Benchmarks
3DM Vant. Perf. total +
Cinebench R15 OpenGL 64 Bit +
* Smaller numbers mean a higher performance
Game Benchmarks
The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

ARC Raiders
2025
The Outer Worlds 2
2025
Battlefield 6
2025
Borderlands 4
2025
F1 25
2025
Doom: The Dark Ages
2025
Civilization 7
2025
Monster Hunter Wilds
2025
Stalker 2
2024
Until Dawn
2024
Space Marine 2
2024
Star Wars Outlaws
2024
Black Myth: Wukong
2024
F1 24
2024
Ghost of Tsushima
2024
Alan Wake 2
2023
Cyberpunk 2077
2023
Baldur's Gate 3
2023
X-Plane 11.11
2018
Dota 2 Reborn
2015
GTA V
2015For more games that might be playable and a list of all games and graphics cards visit our Gaming List
