AMD Radeon RX 6700M

AMD Radeon RX 6700M

The AMD Radeon RX 6700M is a mobile high-end graphics card for gaming laptops. It uses the Navi 22 chip based on the new RDNA 2 architecture. It uses 2,304 of the 2,560 shaders (= 36 CUs), 144? TMUs, and 64 ROPs. The 160 Bit memory system connects 10 GB GDDR6 with 2 GHz memory clock. Furthermore, the RX6800M includes 80 MB Infinity Cache. AMD specified 2.3 GHz game clock for 10.6 TFLOPS theoretical FP32 performance at a TDP of 135 Watt. This means the GPU is in theory 11% slower than the RX 6800M.

The gaming performance of the RX 6700M is positioned slightly below a RTX 3070. When Raytracing effects are activated, it falls behind the GeForce GPUs.

The Navi 22 chip is manufactured at TSMC in the modern 7nm process.

Radeon RX 6000M Series

Radeon RX 6850M XT compare 2560 @ 2.46 GHz192 Bit @ 18000 MHz
Radeon RX 6800M compare 2560 @ 2.12 - 2.3 GHz192 Bit @ 16000 MHz
Radeon RX 6800S compare 2048 @ 1.8 - 1.98 GHz128 Bit @ 16000 MHz
Radeon RX 6700M 2304 @ 2.3 GHz160 Bit @ 16000 MHz
Radeon RX 6650M XT compare 2048 @ 2.16 GHz128 Bit @ 18000 MHz
Radeon RX 6650M compare 1792 @ 2.22 GHz128 Bit @ 18000 MHz
Radeon RX 6600M compare 1792 @ 2.07 - 2.18 GHz128 Bit @ 14000 MHz
Radeon RX 6700S compare 1792 @ 1.7 - 1.89 GHz128 Bit @ 14000 MHz
Radeon PRO W6600M compare 1792 128 Bit @ 14000 MHz
Radeon RX 6600S compare 1792 @ 1.88 GHz128 Bit @ 16000 MHz
Radeon RX 6550M compare 1024 @ 2 - 2.56 GHz64 Bit @ 18000 MHz
Radeon RX 6500M compare 1024 @ 2.19 GHz64 Bit @ 18000 MHz
Radeon RX 6550S compare 1024 @ 2.17 GHz64 Bit @ 16000 MHz
Radeon RX 6450M compare 768 @ 2 - 2.22 GHz64 Bit @ 18000 MHz
Radeon RX 6300M compare 768 @ 1.51 GHz128 Bit @ 18000 MHz
CodenameR21M-E110-70
ArchitectureRDNA 2
Pipelines2304 - unified
Core Speed2300 (Boost) MHz
Memory Speed16000 MHz
Memory Bus Width160 Bit
Memory TypeGDDR6
Max. Amount of Memory10 GB
Shared Memoryno
APIDirectX 12, Shader 6.4, OpenGL 4.6
Power Consumption135 Watt
Transistor Count17.2 Billion
technology7 nm
FeaturesDisplayPort 1.4 w/DFSC, HDMI 2.0b, Radeon Media Engine (H.264 4K150 decode, 4K90 encode / H.265 4K90 decode, 4K60 encode / VP9 4K90 decode)
Notebook Sizemedium sized
Date of Announcement01.09.2020

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
12.7 pt (38%)
3DMark Vantage
3DM Vant. Perf. total +
3DM Vant. Perf. GPU no PhysX +
3DMark 06 3DMark 06 - Standard 1280x1024 +
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 OpenGL Ref. Match 64 Bit +
Emissions Witcher 3 Fan Noise +
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

med. 1920x1080
195  fps    + Compare + 📈 Graph
high 1920x1080
163  fps    + Compare + 📈 Graph
ultra 1920x1080
149  fps    + Compare + 📈 Graph
» With all tested laptops playable in detail settings ultra.
Far Cry 6

Far Cry 6

2021
med. 1920x1080
97  fps    + Compare
high 1920x1080
82  fps    + Compare
ultra 1920x1080
74  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Additional Benchmarks
Ultra Graphics Quality + HD Textures + DXR TAA 1920x1080
54
FIFA 22

FIFA 22

2021
med. 1920x1080
229  fps    + Compare + 📈 Graph
