AMD Radeon RX 5600 XT (Desktop)

The AMD Radeon RX 5600 XT is a fast upper mid-range gaming graphics card for desktops. It uses the Navi 10 chip (RDNA architecture) and is manufactured in the modern 7nm process. It features 2,304 cores (36 CUs - compute units) and fast GDDR6 graphics memory (14 Gbps). The clock speed is specified by AMD at 1,365 - 1,875 MHz (base - max).

The Navi 10 chip uses the new RDNA (Radeon DNA) microarchitecture which is a successor the the GCN instruction set. It features a new processor design, a multi-level cache hierarchy and an improved rendering pipeline with support for GDDR6 memory.

The performance of the RX 5600 XT is slightly better than a Nvidia GeForce RTX 2060. That means it should be best suited for Full HD (1920x1080) and for less demanding games QHD (2650x1440) with maximum settings.

The TDP of the RX 5600 XT is specified at 185 Watt and the energy efficiency should be similar to the RTX 2060 desktop GPU.

ManufacturerAMD
Pipelines2304 - unified
Core Speed1235 - 1750 (Boost) MHz
Memory Speed12000 MHz
Memory Bus Width192 Bit
Memory TypeGDDR6
Max. Amount of Memory6144 MB
Shared Memoryno
DirectXDirectX 12, Shader 6.4
Transistor Count10300 Million
technology7 nm
Features150 W TGP (Board Power), DisplayPort 1.4 w/DFSC, HDMI 2.0b, PCIe 4.0, Radeon Media Engine
Date of Announcement21.01.2020

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
56 pt (61%)
AMD Radeon HD 8180 -98%
...
NVIDIA GeForce RTX 2060 (Desktop) -10%
NVIDIA GeForce GTX 1070 (Desktop) -8%
NVIDIA Quadro P5200 -6%
NVIDIA GeForce RTX 2060 Super (Desktop) -5%
AMD Radeon RX 6600 -2%
AMD Radeon RX Vega 56 -2%
NVIDIA Quadro RTX 5000 (Laptop) -1%
AMD Radeon RX 5700 (Desktop) 0%
NVIDIA GeForce RTX 3060 0%
AMD Radeon RX 5600 XT (Desktop)
NVIDIA GeForce GTX 1080 Mobile 0%
NVIDIA GeForce RTX 3080 Laptop GPU 1%
NVIDIA GeForce RTX 2070 (Desktop) 2%
AMD Radeon RX Vega 64 2%
NVIDIA Titan X Pascal 6%
NVIDIA GeForce RTX 2070 Super (Desktop) 8%
NVIDIA GeForce RTX 3070 Laptop GPU 11%
AMD Radeon RX 5700 XT (Desktop) 12%
NVIDIA GeForce RTX 2080 Super (Desktop) 12%
...
AMD Radeon RX 6800 XT 65%
0%
100%
3DMark - 3DMark Time Spy Score
min: 7916     avg: 7978     median: 7977.5 (43%)     max: 8039 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Time Spy Graphics
min: 7491     avg: 7547     median: 7546.5 (38%)     max: 7602 Points
+ 2 benchmarks and specifications   - Hide comparison chart
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 419088     avg: 457873     median: 457873 (67%)     max: 496658 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Extreme Graphics
min: 276174     avg: 327316     median: 327316 (45%)     max: 378458 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Score
min: 53465     avg: 54221     median: 54220.5 (71%)     max: 54976 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Graphics
min: 114476     avg: 115759     median: 115758 (57%)     max: 117041 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Score
min: 19464     avg: 19694     median: 19464 (50%)     max: 20153 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Graphics
min: 21734     avg: 21817     median: 21817 (43%)     max: 21900 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Graphics
min: 299522     avg: 363231     median: 363230 (48%)     max: 426939 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Night Raid
min: 49374     avg: 49682     median: 49681.5 (73%)     max: 49989 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Night Raid Graphics Score
min: 84143     avg: 87223     median: 87222.5 (54%)     max: 90302 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Score
25782 Points (61%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
30515 Points (50%)
+ 1 benchmarks and specifications   - Hide comparison chart
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
65563 Points (62%)
+ 1 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
64590 Points (59%)
+ 1 benchmarks and specifications   - Hide comparison chart
3DMark 05 - 3DMark 05 - Standard
50634 Points (74%)
+ 1 benchmarks and specifications   - Hide comparison chart
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
45998 Points (75%)
+ 1 benchmarks and specifications   + Show comparison chart
Unigine Valley 1.0 - Unigine Valley 1.0 DX
91 fps (44%)
+ 1 benchmarks and specifications   + Show comparison chart
SPECviewperf 12
specvp12 sw-03 +
SPECviewperf 12 - specvp12 sw-03
102 fps (44%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 snx-02 +
SPECviewperf 12 - specvp12 snx-02
41.9 fps (12%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 showcase-01 +
SPECviewperf 12 - specvp12 showcase-01
111 fps (44%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 mediacal-01 +
SPECviewperf 12 - specvp12 mediacal-01
39.7 fps (24%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 maya-04 +
SPECviewperf 12 - specvp12 maya-04
106 fps (45%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 energy-01 +
SPECviewperf 12 - specvp12 energy-01
10.1 fps (25%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 creo-01 +
SPECviewperf 12 - specvp12 creo-01
75.3 fps (40%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 catia-04 +
SPECviewperf 12 - specvp12 catia-04
152 fps (52%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 3dsmax-05 +
SPECviewperf 12 - specvp12 3dsmax-05
170 fps (51%)
+ 1 benchmarks and specifications   + Show comparison chart
SPECviewperf 13 specvp13 sw-04 +
SPECviewperf 13 - specvp13 sw-04
min: 117.85     avg: 118     median: 118.4 (55%)     max: 119 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 snx-03 +
SPECviewperf 13 - specvp13 snx-03
min: 64.8     avg: 67.3     median: 67.3 (11%)     max: 69.71 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 showcase-02 +
SPECviewperf 13 - specvp13 showcase-02
min: 108     avg: 109     median: 109.1 (43%)     max: 110.21 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 medical-02 +
SPECviewperf 13 - specvp13 medical-02
min: 65.23     avg: 67.9     median: 67.9 (37%)     max: 70.6 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 maya-05 +
SPECviewperf 13 - specvp13 maya-05
min: 210     avg: 210     median: 210.5 (42%)     max: 210.96 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 energy-02 +
SPECviewperf 13 - specvp13 energy-02
min: 19.43     avg: 19.5     median: 19.5 (15%)     max: 19.5 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 creo-02 +
SPECviewperf 13 - specvp13 creo-02
min: 140     avg: 144     median: 143.8 (37%)     max: 147.5 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 catia-05 +
SPECviewperf 13 - specvp13 catia-05
min: 230.22     avg: 231     median: 230.6 (49%)     max: 231 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 3dsmax-06 +
SPECviewperf 13 - specvp13 3dsmax-06
min: 155     avg: 164     median: 163.9 (48%)     max: 172.75 fps
+ 2 benchmarks and specifications   + Show comparison chart
SPECviewperf 2020 specvp2020 solidworks-05 4k +
SPECviewperf 2020 - specvp2020 solidworks-05 4k
51.1 fps (15%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 snx-04 4k +
SPECviewperf 2020 - specvp2020 snx-04 4k
72.2 fps (15%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 medical-03 4k +
SPECviewperf 2020 - specvp2020 medical-03 4k
12.7 fps (24%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 maya-06 4k +
SPECviewperf 2020 - specvp2020 maya-06 4k
120 fps (27%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 energy-03 4k +
SPECviewperf 2020 - specvp2020 energy-03 4k
25.1 fps (18%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 creo-03 4k +
SPECviewperf 2020 - specvp2020 creo-03 4k
46.5 fps (29%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 catia-06 4k +
SPECviewperf 2020 - specvp2020 catia-06 4k
26.1 fps (21%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 3dsmax-07 4k +
SPECviewperf 2020 - specvp2020 3dsmax-07 4k
40.7 fps (24%)
+ 1 benchmarks and specifications   + Show comparison chart
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
1692 Samples/s (8%)
+ 1 benchmarks and specifications   + Show comparison chart
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
4898 Samples/s (9%)
+ 1 benchmarks and specifications   + Show comparison chart
ComputeMark v2.1 - ComputeMark v2.1 Result
15783 points (33%)
+ 1 benchmarks and specifications   + Show comparison chart
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
321 Watt (49%)
+ 1 benchmarks and specifications   + Show comparison chart
Power Consumption - The Witcher 3 Power Consumption - external Monitor *
288 Watt (40%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Guardians of the Galaxy

Guardians of the Galaxy

2021
low 1280x720
83  fps    + Compare
med. 1920x1080
82  fps    + Compare
high 1920x1080
82  fps    + Compare
ultra 1920x1080
87  fps    + Compare
QHD 2560x1440
62  fps    + Compare
4K 3840x2160
27  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Additional Benchmarks
Low Preset 1920x1080
106
Back 4 Blood

Back 4 Blood

2021
med. 1920x1080
172 fps  fps    + Compare
high 1920x1080
150 fps  fps    + Compare
ultra 1920x1080
138 fps  fps    + Compare
QHD 2560x1440
91.9 fps  fps    + Compare
4K 3840x2160
48 fps  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Additional Benchmarks
Low Preset (DX12) 1920x1080
248
Far Cry 6

Far Cry 6

2021
low 1280x720
142  fps    + Compare
med. 1920x1080
113  fps    + Compare
high 1920x1080
100  fps    + Compare
ultra 1920x1080
87  fps    + Compare
QHD 2560x1440
63  fps    + Compare
4K 3840x2160
7  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Additional Benchmarks
Low Graphics Quality 1920x1080
130
New World

New World

2021
low 1280x720
147 fps  fps    + Compare
med. 1920x1080
88.5 fps  fps    + Compare
