NVIDIA GeForce RTX 2080 Super (Desktop)

NVIDIA GeForce RTX 2080 Super (Desktop)

The NVIDIA GeForce RTX 2080 Super or 2080S sits behind the GeForce RTX 2080 Ti as the second fastest desktop GPU in NVIDIA's current Turing line-up (mid 2019). It is the refresh of the one year old RTX 2080 (Desktop) with slightly higher performance. The GPU offers 3,072 cores (up from 2,944) and is based on the TU104 chip. The VRAM is still 8 GB of GDDR6 but now higher clocked at 15.5 GHz (496 GB/s vs. 14 GHz and 448 GB/s).

Features

NVIDIA manufacturers the TU104 chip on a 12 nm FinFET process and includes features like Deep Learning Super Sampling (DLSS) and Real-Time Ray Tracing (RTRT), which should combine to create more realistic lighting effects than older GPUs based on the company's Pascal architecture (if the games supports it). The RTX 2080 is also DisplayPort 1.4 ready, while there is also support for HDMI 2.0b, HDR, Simultaneous Multi-Projection (SMP) and H.265 video en/decoding (PlayReady 3.0).

Performance

The RTX 2080 Super slightly outperforms the older Nvidia Titan XP and of course the RTX 2080 which it succeeds. Therefore, the RTX2080S is located in the absolute high end and well suited for 4k gaming with high to maximum detail settings (depending on the game). Using raytracing features, will reduce the playable resolution however.

Power Requirements

NVIDIA estimates that the RTX 2080 Super should consume a maximum of 250 W, which is 35 W higher than the company rates its GeForce GTX 2080.

ManufacturerNVIDIA
GeForce RTX 2000 Series
NVIDIA Titan RTX compare 4608 @ 1.35 - 1.77 GHz384 Bit @ 14000 MHz
GeForce RTX 2080 Ti (Desktop) compare 4352 @ 1.35 - 1.55 GHz352 Bit @ 14000 MHz
GeForce RTX 2080 Super (Desktop) 3072 @ 1.65 - 1.82 GHz256 Bit @ 15500 MHz
GeForce RTX 2080 (Desktop) compare 2944 @ 1.52 - 1.71 GHz256 Bit @ 14000 MHz
GeForce RTX 2080 Super Mobile compare 3072 @ 1.37 - 1.56 GHz256 Bit @ 14000 MHz
GeForce RTX 2080 Mobile compare 2944 @ 1.38 - 1.59 GHz256 Bit @ 14000 MHz
GeForce RTX 2070 Super (Desktop) compare 2560 @ 1.61 - 1.77 GHz256 Bit @ 14000 MHz
GeForce RTX 2070 (Desktop) compare 2304 @ 1.41 - 1.62 GHz256 Bit @ 14000 MHz
GeForce RTX 2070 Super Mobile compare 2560 @ 1.14 - 1.38 GHz256 Bit @ 14002 MHz
GeForce RTX 2080 Super Max-Q compare 3072 @ 0.98 - 1.23 GHz256 Bit @ 11000 MHz
GeForce RTX 2080 Max-Q compare 2944 @ 0.74 - 1.1 GHz256 Bit @ 12000 MHz
GeForce RTX 2060 Super (Desktop) compare 2176 @ 1.47 - 1.65 GHz256 Bit @ 14000 MHz
GeForce RTX 2070 Mobile compare 2304 @ 1.22 - 1.44 GHz256 Bit @ 14000 MHz
GeForce RTX 2060 (Desktop) compare 1920 @ 1.32 - 1.62 GHz192 Bit @ 14000 MHz
GeForce RTX 2070 Super Max-Q compare 2560 @ 0.93 - 1.16 GHz256 Bit @ 11000 MHz
GeForce RTX 2070 Max-Q compare 2304 @ 0.89 - 1.19 GHz256 Bit @ 12000 MHz
GeForce RTX 2060 Mobile compare 1920 @ 0.96 - 1.2 GHz192 Bit @ 14000 MHz
GeForce RTX 2060 Max-Q compare 1920 @ 0.98 - 1.19 GHz192 Bit @ 11000 MHz
CodenameTuring TU104
ArchitectureTuring
Pipelines3072 - unified
Core Speed1650 - 1815 (Boost) MHz
Memory Speed15500 MHz
Memory Bus Width256 Bit
Memory TypeGDDR6
Max. Amount of Memory8192 MB
Shared Memoryno
DirectXDirectX 12_1, Shader 6.4
Transistor Count13600 Million
technology12 nm
FeaturesDLSS, Raytraycing, NVLink, VR Ready, G-SYNC, Vulkan, Multi Monitor, 650 Watt system power recommended
Date of Announcement02.07.2019

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
62.9 pt (68%)
AMD Radeon HD 8180 -98%
...
AMD Radeon RX 5600 XT (Desktop) -11%
NVIDIA GeForce GTX 1080 Mobile -11%
NVIDIA GeForce RTX 3080 Laptop GPU -10%
NVIDIA GeForce RTX 2070 (Desktop) -10%
AMD Radeon RX Vega 64 -9%
NVIDIA Titan X Pascal -6%
NVIDIA GeForce RTX 2070 Super (Desktop) -4%
NVIDIA GeForce RTX 3070 Laptop GPU -1%
AMD Radeon RX 5700 XT (Desktop) -1%
NVIDIA GeForce RTX 2080 Super (Desktop)
AMD Radeon VII 0%
NVIDIA GeForce RTX 2080 Mobile 1%
AMD Radeon RX 6800M 2%
NVIDIA GeForce GTX 980 SLI (Laptop) 3%
NVIDIA GeForce RTX 2080 (Desktop) 4%
AMD Radeon RX 6600 XT 6%
NVIDIA GeForce RTX 3070 7%
4x NVIDIA RTX A6000 7%
NVIDIA GeForce GTX 1070 SLI (Desktop) 8%
...
AMD Radeon RX 6800 XT 47%
0%
100%
3DMark - 3DMark Time Spy Score
min: 9969     avg: 11002     median: 11215.5 (61%)     max: 11609 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Time Spy Graphics
min: 11313     avg: 11439     median: 11450 (58%)     max: 11542 Points
+ 4 benchmarks and specifications   - Hide comparison chart
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 434157     avg: 497073     median: 515887 (75%)     max: 541176 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Extreme Graphics
min: 276319     avg: 318195     median: 296636 (41%)     max: 381630 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Score
min: 37925     avg: 50367     median: 50596.5 (66%)     max: 62350 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Graphics
min: 136360     avg: 142320     median: 140388 (69%)     max: 152144 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Score
min: 21093     avg: 23130     median: 23364 (60%)     max: 24697 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Graphics
min: 26824     avg: 27647     median: 27398 (54%)     max: 28968 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Graphics
min: 285953     avg: 342060     median: 327518 (44%)     max: 412709 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Night Raid
min: 41514     avg: 51334     median: 54996 (81%)     max: 57491 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Night Raid Graphics Score
min: 85538     avg: 103690     median: 109596 (68%)     max: 115936 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Score
min: 24934     avg: 27272     median: 26415.5 (62%)     max: 31323 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
min: 37958     avg: 40354     median: 40963 (67%)     max: 41532 Points
+ 4 benchmarks and specifications   - Hide comparison chart
3DMark 05 - 3DMark 05 - Standard
43011 Points (63%)
+ 1 benchmarks and specifications   - Hide comparison chart
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 34358     avg: 38035     median: 38034.5 (62%)     max: 41711 Points
+ 2 benchmarks and specifications   + Show comparison chart
Unigine Valley 1.0 - Unigine Valley 1.0 DX
120 fps (58%)
+ 1 benchmarks and specifications   + Show comparison chart
SPECviewperf 12
specvp12 sw-03 +
SPECviewperf 12 - specvp12 sw-03
min: 70.77     avg: 71     median: 71 (31%)     max: 71.3 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp12 snx-02 +
SPECviewperf 12 - specvp12 snx-02
min: 12.26     avg: 12.8     median: 12.8 (4%)     max: 13.39 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp12 showcase-01 +
SPECviewperf 12 - specvp12 showcase-01
min: 139     avg: 141     median: 141.3 (55%)     max: 143.61 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp12 mediacal-01 +
SPECviewperf 12 - specvp12 mediacal-01
min: 38.93     avg: 42     median: 42 (25%)     max: 45 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp12 maya-04 +
SPECviewperf 12 - specvp12 maya-04
min: 130     avg: 132     median: 132.4 (57%)     max: 134.84 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp12 energy-01 +
SPECviewperf 12 - specvp12 energy-01
min: 12.11     avg: 12.6     median: 12.6 (32%)     max: 13.09 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp12 creo-01 +
SPECviewperf 12 - specvp12 creo-01
min: 52.69     avg: 52.8     median: 52.8 (28%)     max: 53 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp12 catia-04 +
SPECviewperf 12 - specvp12 catia-04
min: 104.22     avg: 107     median: 106.6 (37%)     max: 109 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp12 3dsmax-05 +
SPECviewperf 12 - specvp12 3dsmax-05
min: 217     avg: 221     median: 221.4 (66%)     max: 225.82 fps
+ 2 benchmarks and specifications   + Show comparison chart
SPECviewperf 13 specvp13 sw-04 +
SPECviewperf 13 - specvp13 sw-04
min: 96.9     avg: 98.3     median: 98.3 (45%)     max: 99.6 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 snx-03 +
SPECviewperf 13 - specvp13 snx-03
min: 21.94     avg: 23     median: 23 (4%)     max: 24.11 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 showcase-02 +
SPECviewperf 13 - specvp13 showcase-02
min: 138     avg: 141     median: 141.3 (55%)     max: 144.5 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 medical-02 +
SPECviewperf 13 - specvp13 medical-02
min: 71.3     avg: 71.5     median: 71.5 (39%)     max: 71.61 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 maya-05 +
SPECviewperf 13 - specvp13 maya-05
min: 296     avg: 312     median: 312.3 (62%)     max: 328.67 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 energy-02 +
SPECviewperf 13 - specvp13 energy-02
min: 23.78     avg: 24.8     median: 24.8 (19%)     max: 25.89 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 creo-02 +
SPECviewperf 13 - specvp13 creo-02
min: 220.06     avg: 227     median: 227 (58%)     max: 234 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 catia-05 +
SPECviewperf 13 - specvp13 catia-05
min: 157.71     avg: 163     median: 162.9 (35%)     max: 168 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp13 3dsmax-06 +
SPECviewperf 13 - specvp13 3dsmax-06
min: 213     avg: 220     median: 220.4 (65%)     max: 227.75 fps
+ 2 benchmarks and specifications   + Show comparison chart
SPECviewperf 2020 specvp2020 solidworks-05 4k +
SPECviewperf 2020 - specvp2020 solidworks-05 4k
118 fps (35%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 snx-04 4k +
SPECviewperf 2020 - specvp2020 snx-04 4k
19.9 fps (4%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 medical-03 4k +
SPECviewperf 2020 - specvp2020 medical-03 4k
11.8 fps (23%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 maya-06 4k +
SPECviewperf 2020 - specvp2020 maya-06 4k
197 fps (44%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 energy-03 4k +
SPECviewperf 2020 - specvp2020 energy-03 4k
30.5 fps (22%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 creo-03 4k +
SPECviewperf 2020 - specvp2020 creo-03 4k
73.6 fps (45%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 catia-06 4k +
SPECviewperf 2020 - specvp2020 catia-06 4k
37.7 fps (31%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp2020 3dsmax-07 4k +
SPECviewperf 2020 - specvp2020 3dsmax-07 4k
69.5 fps (41%)
+ 1 benchmarks and specifications   + Show comparison chart
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
3430 Samples/s (15%)
+ 1 benchmarks and specifications   + Show comparison chart
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
7878 Samples/s (14%)
+ 1 benchmarks and specifications   + Show comparison chart
ComputeMark v2.1 - ComputeMark v2.1 Result
21009 points (44%)
+ 1 benchmarks and specifications   + Show comparison chart
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
min: 328     avg: 373     median: 376.8 (58%)     max: 413.6 Watt
+ 3 benchmarks and specifications   + Show comparison chart
Power Consumption - The Witcher 3 Power Consumption - external Monitor *
min: 336     avg: 368     median: 359.4 (50%)     max: 416.1 Watt
+ 4 benchmarks and specifications   + Show comparison chart
020406080100120140160180200220240260280300320340331332335332332332330332328325325329328341324332322326324326334327329330329330330327343327326327324325325324325324323326324326327326326325329326325327325329327326328329332339340340338336337337339338336338338339338339340340340339341342340343343342334342330338337337339337337338338341336339338338341338340336339343344337340339338340340340341341339341339339340341341343341339340340333336341336338337337337339338339339340341339339340341338337337337337337337339338339339339340340339339339339339338338339339341340340340340340341339339342340340342341Tooltip
Clock Speed - GPU Clock Witcher 3 ultra
min: 1883     avg: 1902     median: 1901.5 (95%)     max: 1920 MHz
+ 2 benchmarks and specifications   + Show comparison chart
Clock Speed - GPU Clock Speed Furmark
1741 MHz (69%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Far Cry 6

Far Cry 6

2021
low 1280x720
105 fps  fps    + Compare
med. 1920x1080
98.6 fps  fps    + Compare
high 1920x1080
92 fps  fps    + Compare
ultra 1920x1080
87 fps  fps    + Compare
QHD 2560x1440
82.3 fps  fps    + Compare
4K 3840x2160
51.5 fps  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Additional Benchmarks
Low Graphics Quality 1920x1080
106 fps
FIFA 22

FIFA 22

2021
4K 3840x2160
208 fps  fps    + Compare
F1 2021

F1 2021

2021
low 1280x720
231  fps    + Compare
med. 1920x1080
212  fps    + Compare
high 1920x1080
183  fps    + Compare
ultra 1920x1080
113 114 ~ 114 fps    + Compare
QHD 2560x1440
92.3  fps    + Compare
4K 3840x2160
53.5  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Hitman 3

Hitman 3

2021
low 1280x720
272  fps    + Compare
