AMD Radeon HD 8210

AMD Radeon HD 8210

The AMD Radeon HD 8210 is an integrated DirectX 11.1 graphics card found in AMD E1-2100 "Kabini" and A4-1250 "Temash" APUs. It offers 128 shader cores and two Compute Units based on the GCN architecture and is clocked at 300 MHz with no support for Turbo. The graphics card does not have dedicated VRAM and will access the main memory of the system (up to single-channel DDR3L-1333).

The HD 8210 integrates both UVD 4.2 and VCE 2.0 video encoders. It supports up to two external monitors via VGA, DVI, HDMI 1.4a and DisplayPort 1.2.

Depending on the benchmark, the performance of the Radeon HD 8210 is similar to the Intel HD Graphics (Ivy Bridge). This is on par with a dedicated Radeon HD 6430M, but is still too slow for modern games as of 2013. However, a few older and less demanding games will run fluently, if the limited CPU performance is sufficient.

Radeon HD 8000 Series

Radeon HD 8400 compare 128 @ 0.6 GHz
Radeon HD 8330 compare 128 @ 0.5 GHz
Radeon HD 8280 compare 128 @ 0.45 GHz
Radeon HD 8240 compare 128 @ 0.4 GHz
Radeon HD 8250 compare 128 @ 0.3 - 0.4 GHz
Radeon HD 8210 128 @ 0.3 GHz
Radeon HD 8180 compare 128 @ 0.23 GHz
CodenameTemash, Kabini
ArchitectureGCN
Pipelines128 - unified
Core Speed300 MHz
Shared Memoryyes
APIDirectX 11.1, Shader 5.0
technology28 nm
Date of Announcement23.05.2013
CPU in Radeon HD 8210GPU Base SpeedGPU Boost / Turbo
AMD A4-13504 x 1000 MHz, 8 W300 MHz? MHz
AMD E1-22002 x 1050 MHz, 9 W? MHz300 MHz
AMD A4-12502 x 1000 MHz, 9 W300 MHz? MHz
min. - max.300 - ? MHz? - 300 MHz

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
1.2 pt (1%)
3DMark - 3DMark Ice Storm Extreme Graphics
min: 9899     avg: 14467     median: 14467 (2%)     max: 19035 Points
3DMark - 3DMark Cloud Gate Score
min: 1097     avg: 1197     median: 1150 (1%)     max: 1506 Points
3DMark - 3DMark Cloud Gate Graphics
min: 1870     avg: 2333     median: 1904.5 (1%)     max: 4486 Points
3DMark - 3DMark Fire Strike Standard Score
min: 182     avg: 205.4     median: 209 (0%)     max: 215 Points
3DMark - 3DMark Fire Strike Standard Graphics
min: 222     avg: 228     median: 227 (0%)     max: 235 Points
3DMark - 3DMark Ice Storm Graphics
min: 17396     avg: 20164     median: 20119.5 (3%)     max: 22421 Points
3DMark 11 - 3DM11 Performance Score
min: 369     avg: 372.8     median: 370.5 (1%)     max: 381 Points
3DMark 11 - 3DM11 Performance GPU
min: 341     avg: 344.5     median: 343.5 (0%)     max: 350 Points
3DMark Vantage
3DM Vant. Perf. total +
3DM Vant. Perf. GPU no PhysX +
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 2107     avg: 2477     median: 2177.5 (3%)     max: 3446 Points
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 1006     avg: 1586     median: 1691 (1%)     max: 1771 points
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 7.71     avg: 8.5     median: 8.5 (3%)     max: 9.1 fps
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 1.28     avg: 6.8     median: 7.7 (2%)     max: 8.08 fps
Cinebench R15 OpenGL Ref. Match 64 Bit +
GFXBench (DX / GLBenchmark) 2.7
GFXBench 2.7 T-Rex HD Onscreen C24Z16 +
GFXBench T-Rex HD Offscreen C24Z16 +
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
min: 15     avg: 23.5     median: 23.5 (0%)     max: 32 Samples/s
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
min: 31     avg: 45     median: 45 (0%)     max: 59 Samples/s
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

low 1280x720
4.7  fps    + Compare
med. 1920x1080
2.9  fps    + Compare
high 1920x1080
2.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
13  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
12.7  fps    + Compare
med. 1366x768
9.6  fps    + Compare
high 1920x1080
5  fps    + Compare
ultra 1920x1080
4.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
13.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 15

Fifa 15

2014
low 1280x720
1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Sims 4

Sims 4

2014
low 1024x768
27.3  fps    + Compare
med. 1366x768
8.4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
6.9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
12.7 13 ~ 13 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
17.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Thief

Thief

2014
low 1024x768
2.2  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
11.2  fps    + Compare
med. 1366x768
5.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
2.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
9.9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
14  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
F1 2013

F1 2013

2013
low 1024x768
12 12 ~ 12 fps    + Compare
med. 1366x768
12  fps    + Compare
high 1366x768
12  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 14

Fifa 14

2013
low 1024x768
5 (!) 9.7 ~ 7 fps    + Compare
med. 1366x768
5 (!)  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
9.4 10 ~ 10 fps    + Compare
med. 1366x768
7.2  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
9.9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
7.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dota 2

Dota 2

2013
low 1024x768
5.7 6.8 7.2 ~ 7 fps    + Compare
med. 1366x768
6.4  fps    + Compare
ultra 1920x1080
4.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
3.3 3.3 ~ 3 fps    + Compare
med. 1366x768
2.7  fps    + Compare
high 1366x768
1.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
GRID 2

GRID 2

2013
low 1024x768
12.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
4.7  fps    + Compare
med. 1366x768
4.5  fps    + Compare
high 1366x768
3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
16.9  fps    + Compare
med. 1366x768
8.3  fps    + Compare
high 1366x768
7.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
39.2  fps    + Compare
med. 1366x768
15.4  fps    + Compare
high 1366x768
9.3  fps    + Compare
» With all tested laptops playable in detail settings low.
low 1024x768
14 15.8 16.3 ~ 15 fps    + Compare
med. 1366x768
8.8 8.8 9 ~ 9 fps    + Compare
high 1366x768
6.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Crysis 3

Crysis 3

2013
low 1024x768
8.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
4.8 5.1 ~ 5 fps    + Compare
med. 1366x768
4.1  fps    + Compare
high 1366x768
2.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
9.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
11.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 13

Fifa 13

2012
low 1024x768
8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
5.4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
19.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
12.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
13.6 21.1 22.1 ~ 19 fps    + Compare
med. 1366x768
11.5 14 14.5 ~ 13 fps    + Compare
high 1366x768
9.8 12.3 ~ 11 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
11.4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Alan Wake

Alan Wake

2012
low 1024x768
9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 2070

Anno 2070

2011
low 1024x768
20.8 23 26.5 ~ 23 fps    + Compare
med. 1366x768
10 10.6 ~ 10 fps    + Compare
high 1366x768
6.4 23 ~ 15 fps    + Compare
ultra 1920x1080
10.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
10 10.1 ~ 10 fps    + Compare
