ATI Mobility Radeon 9800

ATI Mobility Radeon 9800

ATI Mobility Radeon 9800 is a slim X800 for AGP with energy saving functions and needs a lot of current. Therefore the performance of this card is correspondingly well, but it was rarely used (in a Dell 17" notebook). Nowadays (2008) the performance can be compared to middle class graphics cards.

The videoShader HD technology offers MPEG 1/2/4 decoding acceleration.

Mobility Radeon 9x00 Series

Mobility Radeon 9800 8/4 cores @ 0.35 GHz256 Bit @ 300 MHz
Mobility Radeon 9700 compare 4/2 cores @ 0.45 GHz128 / 64 Bit @ 275 MHz
Mobility Radeon 9600 compare 4/2 cores @ 0.3 GHz128 / 64 Bit @ 300 MHz
Mobility Radeon 9550 compare 4/2 cores @ 0.21 GHz64 Bit @ 183 MHz
CodenameM18
Pipelines8 / 4 Pixel- / Vertexshader
Core Speed350 MHz
Memory Speed300 MHz
Memory Bus Width256 Bit
Memory TypeDDR2 / DDR3
Max. Amount of Memory256 MB
Shared Memoryno
APIDirectX 9, Shader 2.0
Transistor Count110 Million
technology130 nm
Features130nm low-k, Powerplay
Notebook Sizelarge
Date of Announcement01.07.2004
Information110 Mio Transistoren, 130nm
Link to Manufacturer Pagewww.ati.com

Benchmarks

3DMark 2001SE - 3DMark 2001 - Standard
17800 Points (18%)
+ 1 benchmarks and specifications   - Hide comparison chart
3DMark 03 - 3DMark 03 - Standard
6500 Points (3%)
+ 1 benchmarks and specifications   - Hide comparison chart
3DMark 05 - 3DMark 05 - Standard
2800 Points (3%)
+ 1 benchmarks and specifications   - Hide comparison chart
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06
860 points (1%)
+ 1 benchmarks and specifications   - Hide comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
