AMD Radeon HD 8970M Crossfire

AMD Radeon HD 8970M Crossfire

The AMD Radeon HD 8970M Crossfire (also known as the ATI Mobility Radeon HD 8970 X2 or CrossFireX) is a combination of two high-end graphics card for big and heavy laptops. Usually, each single card renders a single frame in an alternating manner. Therefore, it may suffer from micro stuttering in low frame rates below 30 FPS due to staggering timespans between two frames (e.g., irregular delays between sequential frames).

The HD 8970M is based on the desktop HD 7870 Pitcairn chip with 1280 1D shaders and 80 texture units. The GCN (graphics core next) architecture supports DirectX11 and OpenGL 4.2. More information on the features of the single 8970M can be found on the GPU page. Compared to the 7970M, the 8970M is based on the same chip but offers an increased core clock rate by 50 MHz when in Turbo.

The Performance of two HD 8970M GPUs in Crossfire mode is similar to the GeForce GTX 680M SLI an just slightly below the GTX 780M SLI. As of 2013, however, the Crossfire solution currently suffers more from micro stuttering than Nvidia SLI solutions. Regardless, modern and demanding games like Battlefield 3 or Metro Last Light are still playable in high resolution and max. settings with anti-aliasing.

The power consumption of the CF combination is very high (2x 100 Watt) and is thus only suited for very large desktop replacement laptops.

ManufacturerAMD
Radeon HD 8900M Series
Radeon HD 8970M Crossfire 2560 @ 850 - 900 (Boost) MHz256 Bit @ 4800 MHz

Radeon HD 8970M

1280 @ 850 - 900 (Boost) MHz256 Bit @ 4800 MHz
CodenameNeptune CF
ArchitectureGCN
Pipelines2560 - unified
Core Speed *850 - 900 (Boost) MHz
Memory Speed *4800 MHz
Memory Bus Width256 Bit
Memory TypeGDDR5
Shared Memoryno
DirectXDirectX 11.1, Shader 5.0
Power Consumption200 Watt
technology28 nm
Notebook Sizelarge
Date of Announcement01.05.2012
* The specified clock rates are only guidelines for the manufacturer and can be altered by them.

Benchmarks

3DMark (2013) - Fire Strike Standard Graphics 1920x1080
0% 100%
min: 10163      avg: 10258.5 (81%)     median: 10258.5 (81%)     max: 10354 Points
3DMark (2013) - Fire Strike Standard Score 1920x1080
0% 100%
min: 8049      avg: 8097 (77%)     median: 8097 (77%)     max: 8145 Points
3DMark (2013) - Cloud Gate Standard Graphics 1280x720
0% 100%
min: 69869      avg: 69991.5 (83%)     median: 69991.5 (83%)     max: 70114 Points
3DMark (2013) - Cloud Gate Standard Score 1280x720
0% 100%
min: 22905      avg: 22932 (84%)     median: 22932 (84%)     max: 22959 Points
3DMark (2013) - Ice Storm Standard Graphics 1280x720
0% 100%
min: 309449      avg: 327559.5 (44%)     median: 327559.5 (44%)     max: 345670 Points
Unigine Heaven 3.0 - DX 11, Normal Tessellation, High Shaders 1920x1080
0% 100%
min: 122.6      avg: 122.6 (82%)     median: 122.6 (82%)     max: 122.6 fps
LuxMark v2.0 64Bit - Room Scene, OpenCL GPUs-only
0% 100%
min: 1479      avg: 1479 (97%)     median: 1479 (97%)     max: 1479 Samples/s
LuxMark v2.0 64Bit - Sala Scene, OpenCL GPUs-only
0% 100%
min: 2495      avg: 2495 (84%)     median: 2495 (84%)     max: 2495 Samples/s
3DMark 11 - Performance GPU 1280x720
0% 100%
min: 12361      avg: 12392.5 (74%)     median: 12392.5 (74%)     max: 12424 points
3DMark 11 - Performance 1280x720
0% 100%
min: 10816      avg: 10906.5 (76%)     median: 10906.5 (76%)     max: 10997 points
3DMark Vantage - P GPU no PhysX 1280x1024
0% 100%
min: 38373      avg: 39191 (85%)     median: 39191 (85%)     max: 40009 Points
3DMark Vantage - P Result no PhysX 1280x1024
0% 100%
min: 33489      avg: 34215 (82%)     median: 34215 (82%)     max: 34941 Points
3DMark 06
0% 100%
min: 25388      avg: 26430 (69%)     median: 26430 (69%)     max: 27472 Points
Unigine Heaven 2.1 - high, Tesselation (normal), DirectX11 1280x1024
0% 100%
min: 154.3      avg: 154.3 (83%)     median: 154.3 (83%)     max: 154.3 fps
PCMark Vantage - Gaming Score 1024x768
0% 100%
min: 24201      avg: 24201 (93%)     median: 24201 (93%)     max: 24201 Points
SPECviewperf 11 - Siemens NX 1920x1080
0% 100%
min: 15.08      avg: 15.5 (25%)     median: 15.5 (25%)     max: 15.9 fps
SPECviewperf 11 - Tcvis 1920x1080
0% 100%
min: 8.25      avg: 8.4 (14%)     median: 8.4 (14%)     max: 8.59 fps
SPECviewperf 11 - SolidWorks 1920x1080
0% 100%
min: 32.78      avg: 33.6 (52%)     median: 33.6 (52%)     max: 34.47 fps
SPECviewperf 11 - Pro/ENGINEER 1920x1080
0% 100%
min: 4.02      avg: 4.1 (21%)     median: 4.1 (21%)     max: 4.13 fps
SPECviewperf 11 - Maya 1920x1080
0% 100%
min: 16.88      avg: 16.9 (15%)     median: 16.9 (15%)     max: 16.98 fps
SPECviewperf 11 - Lightwave 1920x1080
0% 100%
min: 33.55      avg: 34.2 (42%)     median: 34.2 (42%)     max: 34.77 fps
SPECviewperf 11 - Ensight 1920x1080
0% 100%
min: 51.4      avg: 51.4 (64%)     median: 51.4 (64%)     max: 51.42 fps
SPECviewperf 11 - Catia 1920x1080
0% 100%
min: 11.4      avg: 11.4 (16%)     median: 11.4 (16%)     max: 11.44 fps
Cinebench R11.5 - OpenGL 64Bit
0% 100%
min: 97.28      avg: 103.5 (84%)     median: 103.5 (84%)     max: 109.72 Points
Cinebench R10 - Shading 32Bit
0% 100%
min: 8134      avg: 8134 (56%)     median: 8134 (56%)     max: 8134 Points
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailled information on the benchmark results, click on the fps number.

Dota 2

Dota 2

2013
med. 1366x768
102.3  fps      Compare
ultra 1920x1080
97.8  fps      Compare
» With all tested laptops playable in detail settings ultra.
Company of Heroes 2
med. 1366x768
57.4 57.6 ~ 58 fps      Compare
high 1366x768
48.9 49.3 ~ 49 fps      Compare
ultra 1920x1080
23.2 23.2 ~ 23 fps      Compare
» With all tested laptops playable in detail settings high.
GRID 2

GRID 2

2013
med. 1366x768
140.8 159.4 ~ 150 fps      Compare
high 1366x768
128.4 134.8 ~ 132 fps      Compare
ultra 1920x1080
110.3 112.7 ~ 112 fps      Compare
» With all tested laptops playable in detail settings ultra.
Metro: Last Light
med. 1366x768
97.9 100 ~ 99 fps      Compare
high 1366x768
79.3 84.9 ~ 82 fps      Compare
ultra 1920x1080
53 53.2 ~ 53 fps      Compare
» With all tested laptops playable in detail settings ultra.
BioShock Infinite
med. 1366x768
161.4 172.2 ~ 167 fps      Compare
high 1366x768
146.6 166.2 ~ 156 fps      Compare
ultra 1920x1080
86.1 87.7 ~ 87 fps      Compare
» With all tested laptops playable in detail settings ultra.
StarCraft II: Heart of the Swarm
med. 1366x768
160.1  fps      Compare
high 1366x768
140.1  fps      Compare
ultra 1920x1080
60.6  fps      Compare
» With all tested laptops playable in detail settings ultra.
SimCity

SimCity

2013
med. 1366x768
118.3  fps      Compare
high 1366x768
90.4  fps      Compare
ultra 1920x1080
47.8  fps      Compare
» With all tested laptops playable in detail settings ultra.
Tomb Raider
med. 1366x768
369.5 388 ~ 379 fps      Compare
high 1366x768
275.1 284.4 ~ 280 fps      Compare
ultra 1920x1080
126 126.5 ~ 126 fps      Compare
» With all tested laptops playable in detail settings ultra.
Crysis 3

Crysis 3

2013
med. 1366x768
114.9  fps      Compare
high 1366x768
91.2  fps      Compare
ultra 1920x1080
37.8  fps      Compare
» With all tested laptops playable in detail settings ultra.
Dead Space 3
med. 1366x768
168.5  fps      Compare
high 1366x768
168.2  fps      Compare
ultra 1920x1080
166.7  fps      Compare
» With all tested laptops playable in detail settings ultra.
Far Cry 3

Far Cry 3

2012
med. 1366x768
96.8  fps      Compare
high 1366x768
78.8  fps      Compare
ultra 1920x1080
51  fps      Compare
» With all tested laptops playable in detail settings ultra.
Assassin´s Creed III
med. 1366x768
44.6  fps      Compare
high 1366x768
43.1  fps      Compare
ultra 1920x1080
32.5  fps      Compare
» With all tested laptops playable in detail settings high.
Hitman: Absolution
med. 1366x768
76.4  fps      Compare
high 1366x768
68.1  fps      Compare
ultra 1920x1080
65.4  fps      Compare
» With all tested laptops playable in detail settings ultra.
Call of Duty: Black Ops 2
med. 1366x768
243.1 249.6 ~ 246 fps      Compare
high 1366x768
207.3 219.8 ~ 214 fps      Compare
ultra 1920x1080
152 158.2 ~ 155 fps      Compare
» With all tested laptops playable in detail settings ultra.
Need for Speed: Most Wanted
med. 1366x768
60  fps      Compare
high 1366x768
59.8  fps      Compare
ultra 1920x1080
59.8  fps      Compare
» With all tested laptops playable in detail settings ultra.
Dishonored
med. 1366x768
128.8 129 ~ 129 fps      Compare
high 1366x768
128.2 129 ~ 129 fps      Compare
ultra 1920x1080
128 128.2 ~ 128 fps      Compare
» With all tested laptops playable in detail settings ultra.
Fifa 13

Fifa 13

2012
med. 1366x768
362.3  fps      Compare
high 1366x768
266.2  fps      Compare
ultra 1920x1080
213  fps      Compare
» With all tested laptops playable in detail settings ultra.
F1 2012

F1 2012

2012
high 1366x768
101  fps      Compare
