NVIDIA GeForce GTX 470

NVIDIA GeForce GTX 470

The Nvidia GeForce GTX 470 is a high-end desktop graphics card of the Fermi generation. It is based on the GF100 chip and offers only 448 of the 512 available CUDA cores. The similar named laptop graphics card Nvidia GeForce GTX 470M is definately slower as it offers only 288 shaders and reduced clock speeds.

The performance of the GTX470 is usually enough for the highest settings and Full HD resolution. However, very demanding games in our benchmarks like Witcher 2, Far Cry 2 or Metro 2033 were not playable at the highes settings with Antialiasing. See the benchmarks below for more details.

ManufacturerNVIDIA
GeForce GTX 400 Series

GeForce GTX 480

480 @ 700 MHz384 Bit @ 1848 MHz
GeForce GTX 470 448 @ 607 MHz320 Bit @ 1676 MHz

GeForce GTX 460 768MB

336 @ 675 MHz192 Bit @ 1800 MHz
CodenameGF100
ArchitectureFermi
Pipelines448 - unified
Core Speed *607 MHz
Shader Speed *1215 MHz
Memory Speed *1676 MHz
Memory Bus Width320 Bit
Memory TypeGDDR5
Max. Amount of Memory1280 MB
Shared Memoryno
DirectXDirectX 11, Shader 5.0
Power Consumption225 Watt
Transistors3000 Million
technology40 nm
FeaturesDirectX11, OpenGL 4.2, 3D Vision, PhysX, CUDA
Date of Announcement12.04.2010
Link to Manufacturer Pagehttp://www.geforce.com/hardware/desktop-...
* The specified clock rates are only guidelines for the manufacturer and can be altered by them.

Benchmarks

3DMark (2013) - Fire Strike Standard Graphics 1920x1080
0% 100%
min: 2747      avg: 2757.5 (22%)     median: 2757.5 (22%)     max: 2768 Points
3DMark (2013) - Fire Strike Standard Score 1920x1080
0% 100%
min: 2394      avg: 2396 (23%)     median: 2396 (23%)     max: 2398 Points
3DMark (2013) - Cloud Gate Standard Graphics 1280x720
0% 100%
min: 25111      avg: 25757 (31%)     median: 25757 (31%)     max: 26403 Points
3DMark (2013) - Cloud Gate Standard Score 1280x720
0% 100%
min: 14772      avg: 14953.5 (55%)     median: 14953.5 (55%)     max: 15135 Points
3DMark (2013) - Ice Storm Standard Graphics 1280x720
0% 100%
min: 162190      avg: 177491.5 (24%)     median: 177491.5 (24%)     max: 192793 Points
ComputeMark v2.1 - Normal, Score 1024x600
0% 100%
min: 2460      avg: 2460 (30%)     median: 2460 (30%)     max: 2460 Points
LuxMark v2.0 64Bit - Room Scene, OpenCL GPUs-only
0% 100%
min: 288      avg: 288 (19%)     median: 288 (19%)     max: 288 Samples/s
LuxMark v2.0 64Bit - Sala Scene, OpenCL GPUs-only
0% 100%
min: 610      avg: 610 (21%)     median: 610 (21%)     max: 610 Samples/s
3DMark 11 - Performance GPU 1280x720
0% 100%
min: 4017      avg: 4292.6 (25%)     median: 4342 (26%)     max: 4393 points
3DMark 11 - Performance 1280x720
0% 100%
min: 4267      avg: 4652.8 (32%)     median: 4718 (33%)     max: 4822 points
3DMark Vantage - P GPU no PhysX 1280x1024
Maximum value not found for - , could not paint bar!
3DMark Vantage - P Result no PhysX 1280x1024
Maximum value not found for - , could not paint bar!
3DMark 06
Maximum value not found for - , could not paint bar!
3DMark 05 - Standard 1024x768
Maximum value not found for - , could not paint bar!
3DMark 03 - Standard 1024x768
Maximum value not found for - , could not paint bar!
3DMark 2001SE - Standard 1024x768
Maximum value not found for - , could not paint bar!
Unigine Heaven 2.1 - high, Tesselation (normal), DirectX11 1280x1024
Maximum value not found for - , could not paint bar!
PCMark Vantage - Gaming Score 1024x768
Maximum value not found for - , could not paint bar!
Cinebench R10 - Shading 32Bit
Maximum value not found for - , could not paint bar!
Windows 7 Experience Index - Gaming graphics
Maximum value not found for - , could not paint bar!
Windows 7 Experience Index - Graphics
Maximum value not found for - , could not paint bar!
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailled information on the benchmark results, click on the fps number.

Company of Heroes 2
low 1024x768
55.3  fps      Compare
med. 1366x768
48.7  fps      Compare
high 1366x768
34.2  fps      Compare
ultra 1920x1080
12.5  fps      Compare
» With all tested laptops playable in detail settings med..
BioShock Infinite
low 1280x720
162.3  fps      Compare
med. 1366x768
111.5  fps      Compare
high 1366x768
100.9  fps      Compare
ultra 1920x1080
32.8  fps      Compare
» With all tested laptops playable in detail settings high.
StarCraft II: Heart of the Swarm
low 1024x768
265  fps      Compare
med. 1366x768
107  fps      Compare
high 1366x768
96  fps      Compare
ultra 1920x1080
56  fps      Compare
» With all tested laptops playable in detail settings ultra.
SimCity

SimCity

2013
low 1024x768
166  fps      Compare
ultra 1920x1080
39  fps      Compare
» With all tested laptops playable in detail settings ultra.
Tomb Raider
low 1024x768
305.6  fps      Compare
med. 1366x768
155.5  fps      Compare
high 1366x768
115.2  fps      Compare
ultra 1920x1080
44.1  fps      Compare
» With all tested laptops playable in detail settings ultra.
Dead Space 3
low 1024x768
405  fps      Compare
med. 1366x768
206  fps      Compare
high 1366x768
156  fps      Compare
ultra 1920x1080
90  fps      Compare
» With all tested laptops playable in detail settings ultra.
Far Cry 3

Far Cry 3

2012
high 1366x768
61.5  fps      Compare
ultra 1920x1080
19.7  fps      Compare
» With all tested laptops playable in detail settings high.
Medal of Honor: Warfighter
high 1366x768
75  fps      Compare
ultra 1920x1080
35  fps      Compare
» With all tested laptops playable in detail settings high.
World of Tanks v8
low 1024x768
118  fps      Compare
med. 1366x768
80  fps      Compare
high 1366x768
72  fps      Compare
ultra 1920x1080
52  fps      Compare
» With all tested laptops playable in detail settings ultra.
Max Payne 3
low 1024x768
84  fps      Compare
med. 1366x768
84  fps      Compare
high 1366x768
53  fps      Compare
ultra 1920x1080
41  fps      Compare
» With all tested laptops playable in detail settings ultra.
Diablo III
low 1024x768
241  fps      Compare
med. 1366x768
174  fps      Compare
high 1366x768
110  fps      Compare
ultra 1920x1080
80  fps      Compare
» With all tested laptops playable in detail settings ultra.
Risen 2: Dark Waters
low 1024x768
117  fps      Compare
med. 1366x768
96  fps      Compare
high 1366x768
74  fps      Compare
ultra 1920x1080
35  fps      Compare
» With all tested laptops playable in detail settings high.
Mass Effect 3
ultra 1920x1080
60  fps      Compare
» With all tested laptops playable in detail settings ultra.
Alan Wake

Alan Wake

2012
low 1024x768
127  fps      Compare
med. 1366x768
79  fps      Compare
ultra 1920x1080
34  fps      Compare
» With all tested laptops playable in detail settings med..
Star Wars: The Old Republic
low 1024x768
86  fps      Compare
high 1366x768
71  fps      Compare
» With all tested laptops playable in detail settings high.
Anno 2070

Anno 2070

2011
low 1024x768
292  fps      Compare
med. 1366x768
145  fps      Compare
high 1366x768
90  fps      Compare
ultra 1920x1080
42  fps      Compare
» With all tested laptops playable in detail settings ultra.
The Elder Scrolls V: Skyrim
high 1366x768
63  fps      Compare
ultra 1920x1080
44  fps      Compare
» With all tested laptops playable in detail settings ultra.
CoD: Modern Warfare 3
high 1366x768
124  fps      Compare
ultra 1920x1080
80  fps      Compare
» With all tested laptops playable in detail settings ultra.
Battlefield 3
low 1024x768
103  fps      Compare
med. 1366x768
75  fps      Compare
high 1366x768
61 61 61 ~ 61 fps      Compare
ultra 1920x1080
29 30 30 ~ 30 fps      Compare
» With all tested laptops playable in detail settings high.
Batman: Arkham City
low 1024x768
146  fps      Compare
med. 1366x768
136  fps      Compare
high 1366x768
96  fps      Compare
ultra 1920x1080
51  fps      Compare
» With all tested laptops playable in detail settings ultra.
Fifa 12

Fifa 12

2011
med. 1024x768
438  fps      Compare
high 1360x768
315  fps      Compare
ultra 1920x1080
224 239 ~ 232 fps      Compare
» With all tested laptops playable in detail settings ultra.
F1 2011

F1 2011

2011
high 1366x768
90 97 102 ~ 96 fps      Compare
ultra 1920x1080
60 60 61 ~ 60 fps      Compare
» With all tested laptops playable in detail settings ultra.
Deus Ex Human Revolution
ultra 1920x1080
62  fps      Compare
» With all tested laptops playable in detail settings ultra.
Dirt 3

Dirt 3

2011
ultra 1920x1080
49.9  fps      Compare
» With all tested laptops playable in detail settings ultra.
The Witcher 2: Assassins of Kings
med. 1366x768
48  fps      Compare
high 1600x900
43  fps      Compare
ultra 1920x1080
13  fps      Compare
» With all tested laptops playable in detail settings high.
Crysis 2

Crysis 2

2011
high 1366x768
126  fps      Compare
ultra 1920x1080
44  fps      Compare
» With all tested laptops playable in detail settings ultra.
Total War: Shogun 2
low 1024x768
426.6  fps      Compare
med. 1280x720
94.1 94.1 103 ~ 97 fps      Compare
ultra 1920x1080
33.7 34.2 34.2 ~ 34 fps      Compare
» With all tested laptops playable in detail settings med..
Call of Duty: Black Ops
ultra 1920x1080
76  fps      Compare
» With all tested laptops playable in detail settings ultra.
Fifa 11

Fifa 11

2010
ultra 1920x1080
235  fps      Compare
» With all tested laptops playable in detail settings ultra.
Civilization 5
low 1024x768
82.3  fps      Compare
ultra 1920x1080
48.9  fps      Compare
» With all tested laptops playable in detail settings ultra.
Mafia 2

Mafia 2

2010
ultra 1920x1080
72.9 101.3 ~ 87 fps      Compare
» With all tested laptops playable in detail settings ultra.
StarCraft 2
ultra 1920x1080
78  fps      Compare
» With all tested laptops playable in detail settings ultra.
Just Cause 2
ultra 1920x1080
45  fps      Compare
» With all tested laptops playable in detail settings ultra.
Metro 2033
high 1600x900
61  fps      Compare
ultra 1920x1080
23  fps      Compare
» With all tested laptops playable in detail settings high.
Dawn of War II - Chaos Rising
ultra 1920x1080
72.8  fps      Compare
» With all tested laptops playable in detail settings ultra.
Battlefield: Bad Company 2
ultra 1920x1080
73  fps      Compare
» With all tested laptops playable in detail settings ultra.
Stalker: Call of Pripyat
ultra 1920x1200
53  fps      Compare
» With all tested laptops playable in detail settings ultra.
Risen

Risen

2009
ultra 1920x1080
59  fps      Compare
» With all tested laptops playable in detail settings ultra.
Resident Evil 5
ultra 1920x1080
97.5 107.6 ~ 103 fps      Compare
» With all tested laptops playable in detail settings ultra.
Colin McRae: DIRT 2
ultra 1920x1080
84.9 84.9 ~ 85 fps      Compare
» With all tested laptops playable in detail settings ultra.
ArmA 2

ArmA 2

2009
ultra 1920x1080
39  fps      Compare
» With all tested laptops playable in detail settings ultra.
Far Cry 2

Far Cry 2

2008
ultra 1920x1080
98.7  fps      Compare
» With all tested laptops playable in detail settings ultra.
Crysis Warhead
low 800x600
123  fps      Compare
ultra 1024x768
55  fps      Compare
» With all tested laptops playable in detail settings ultra.
Trackmania Nations Forever
ultra 1920x1080
90.2  fps      Compare
» With all tested laptops playable in detail settings ultra.
Crysis - GPU Benchmark
ultra 1920x1080
33.8  fps      Compare
» The benchmarks indicate that the game is not playable in the tested settings.
World in Conflict - Benchmark
ultra 1920x1080
68  fps      Compare
» With all tested laptops playable in detail settings ultra.

For more games that might be playable and a list of all games and graphics cards visit our Gaming List

#0 Did not recreate cache, as it is less than 5 days old +0.002s ... 0.002s

#1 min, max, avg, median took 0.00029492378234863s +0.351s ... 0.353s

#2 Before gaming benchmark output +0s ... 0.353s

#3 return log +0.593s ... 0.946s

No reviews found for this graphics card.

» Comparison of GPUs
Detailled list of all laptop GPUs with a short description. Classified and sorted by performance.

» Benchmark List
Sortable and restrainable list of all GPUs with benchmarks (e.g. 3DMarks).

» Notebook Gaming List
Which game can be played with my graphics card.

Class 1
GeForce GTX 590
GeForce GTX 580
Radeon HD 6970
GeForce GTX 570
GeForce GTX 560 Ti
Radeon HD 5850
Radeon HD 7770
Radeon HD 7770
GeForce GTX 460 768MB
Radeon HD 6790
Radeon HD 5770
GeForce GTX 550 Ti
Class 2
GeForce GTS 450
Radeon HD 4850
Class 3
Radeon HD 5670
GeForce GT 240
Radeon R6 M255DX
GeForce GT 430
Radeon HD 5570
GeForce GT 220
Radeon HD 6450 GDDR5
Class 4
Radeon R3 (Mullins/Beema)
Mali-T760 MP6
Class 5
Radeon HD 4350
GeForce G 107M *
Chrome9HD *
Class 6
Mali-T760 MP2
unknown *

* Approximate position of the graphics adapter

> Notebook / Laptop Reviews and News > FAQ / Tips / Technics > Comparison of Laptop Graphics Cards > NVIDIA GeForce GTX 470
Author: Klaus Hinum (Update: 2013-03-20)
