AMD Radeon HD 7750M

AMD Radeon HD 7750M

The AMD Radeon HD 7750M is an upcoming DirectX 11 performance-class graphics card for laptops. It will be manufactured in 28nm and is based on the GCN architecture. As of this writing, all information are still based on rumors. One source of rumors is provided in the link below:
http://www.techarp.com/showarticle.aspx?artno=98&pgno=4

The design of the Radeon 7700M series has its roots to the Cape Verde chip as found, for example, on the desktop Radeon HD 7750 with 512 1D shader cores and 32 texture units. However, it has a core clock of only 575 MHz compared to 800 MHz for the HD 7750 and 675 MHz for the 7770M.  As a result, power consumption is expected to be much lower. While the desktop-version supports PCIe 3.0, the 7700M-Series doesn't (according to AMD).

The performance should be in the range of the old Radeon HD 6870M and therefore slightly below Nvidias GeForce GT 650M GDDR5.

Features of the 7750M include the new UVD3 video decoder for decoding MPEG-4 AVC/H.264, VC-1, MPEG-2, Flash and now also Multi-View Codec (MVC) and MPEG-4 part 2 (DivX, xVid) HD videos directly from the AMD GPU.

The 7700M series also supports automatic graphics switching between the integrated GPU and discrete GPU. Called Enduro, the technology supersedes AMD's Dynamic Switchable Graphics and is similar to Nvidia's Optimus. Furthermore, the 7750M can directly support up to 6 connected monitors using Eyefinity Technology if Enduro is disabled.

Other features of the 7700M series include ZeroCore for reducing power consumption when the display is turned off and Power Gating to power down areas of the chip that are not used. PowerTune allows automatic overclocking and underclocking of the graphics card as long as the GPU is within its TDP range. For example, the chip may be underclocked when running FurMark and OCCT, but will overclock in certain games like Lost Planet, Crysis or Resident Evil 5.

The integrated HD audio processor is able to transmit HD Audio (TrueHD or DTS Master Audio) over HDMI and DisplayPort (e.g., for Blu-Ray videos). Additionally, it now allows audio to output simultaneously and in parallel to multiple devices with the new Discrete Digital Multipoint Audio (DDMA) feature.

Power consumption of the 7750M should be suited for 15-inch-laptops or greater.

ManufacturerAMD
Radeon HD 7700M Series

Radeon HD 7770M

512 @ 675MHz128 Bit @ 4000MHz
Radeon HD 7750M 512 @ 575MHz128 Bit @ 4000MHz

Radeon HD 7730M

512 @ 575 - 675MHz128 Bit @ 1800MHz
CodenameLombok XL
ArchitectureGCN
Pipelines512 - unified
Core Speed *575 MHz
Shader Speed *575 MHz
Memory Speed *4000 MHz
Memory Bus Width128 Bit
Memory TypeGDDR5
Shared Memoryno
DirectXDirectX 11.1, Shader 5.0
Power Consumption36 Watt
technology28 nm
Notebook Sizemedium sized
Date of Announcement24.04.2012
* The specified clock rates are only guidelines for the manufacturer and can be altered by them.

Benchmarks

3DMark 11 - Performance GPU 1280x720
0% 100%
min: 2085      avg: 2085 (13%)     median: 2085 (13%)     max: 2085 points
3DMark 11 - Performance 1280x720
0% 100%
min: 2382      avg: 2382 (18%)     median: 2382 (18%)     max: 2382 points
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
