AMD Radeon R9 M270

AMD Radeon R9 M270

The AMD Radeon R9 M270 is an upper mid-range, DirectX 11-capable graphics card for notebooks. It is manufactured in 28nm and based on the GCN (Graphics Core Next) architecture from AMD. The R9 M270 is probably just a renamed Radeon HD 8870M with 640 shader units (725 - 775 MHz) and up to 4 GB of GDDR5 memory (1125 MHz / 4500 MHz effective).

According to this information (not yet officially confirmed), the performance of the R9 M270 should exactly match its predecessor. Thus, the GPU should be somewhat slower than a Nvidia GeForce GTX 760M

Please note: The technical specifications and clock rates are based on speculation and have not been verified by the manufacturer. The R9 M270 has been first seen in the Lenovo Y40.

ManufacturerAMD
Radeon R9 M200 Series

Radeon R9 M290X Crossfire

2560 @ 850 - 900MHz256 Bit @ 4800MHz

Radeon R9 M290X

1280 @ 850 - 900MHz256 Bit @ 4800MHz

Radeon R9 M275

640 @ 925MHz128 Bit @ 4500MHz
Radeon R9 M270 640 @ 725MHz128 Bit @ 4500MHz

Radeon R9 M265X

640 @ 625MHz128 Bit @ 4000MHz
ArchitectureGCN
Pipelines640 - unified
Core Speed *725 MHz
Shader Speed *725 MHz
Memory Speed *4500 MHz
Memory Bus Width128 Bit
Memory TypeGDDR5
Max. Amount of Memory4096 MB
Shared Memoryno
DirectXDirectX 11.2 Tier 1, Shader 5.0
Transistors1500 Million
technology28 nm
FeaturesOpenCL 1.2
Notebook Sizelarge
Date of Announcement01.04.2014
* The specified clock rates are only guidelines for the manufacturer and can be altered by them.
