AMD Radeon HD 8590M

AMD Radeon HD 8590M

The AMD Radeon HD 8590M (sometimes also called ATI Mobility Radeon HD 8590M) is a DirectX 11.1 graphics card for laptops. It was announced early 2012 and is technically a Radeon HD 8570M with GDDR5 graphics memory. The core is clocked at 620 MHz and is able to overclock itself to 700 MHz (Boost). The GDDR5 graphics memory is clocked at 1125 MHz (4.5 GHz effective).

The 28nm Mars core uses the GCN architecture. Compared to the 8600M and 8700M series, the only clock speed, memory bus configuration, and memory type have been overhauled.

The performance of the Radeon HD 8590M should be slightly below the old Radeon HD 6750M. Current and demanding games like Far Cry 3 should run fluently only in low resolutions and detail settings.

The 384 shaders can be used with OpenCL 1.2 for general-purpose calculations (as 6 compute units). Compared to old TeraScale 2 chips, the GCN-based Mars architecture offers improved performance in this framework.

Features of the 8590M include video decoding via UVD3 for decoding MPEG-4 AVC/H.264, VC-1, MPEG-2, and Flash directly from the AMD GPU. Multi-View Codec (MVC) and MPEG-4 part 2 (DivX, xVid) HD videos are now compatible as well.

The 8500M series also supports automatic graphics switching between the integrated GPU and discrete GPU. Called Enduro, the technology supersedes AMD's Dynamic Switchable Graphics and is similar to Nvidia's Optimus. Furthermore, the 8590M can directly support up to 2 connected monitors using Eyefinity Technology if Enduro is disabled.

Other features of the 8500M series include ZeroCore for reducing power consumption when the display is turned off and Power Gating to power down areas of the chip that are not used. PowerTune allows automatic overclocking and underclocking of the graphics card as long as the GPU is within its TDP limit. For example, the chip may be underclocked when running FurMark and OCCT, but will overclock in certain games like Lost Planet, Crysis or Resident Evil 5.

The integrated HD audio processor is able to transmit HD Audio (TrueHD or DTS Master Audio) over HDMI and DisplayPort (e.g., for Blu-Ray videos). Additionally, it now allows audio to output simultaneously and in parallel to multiple devices with the new Discrete Digital Multipoint Audio (DDMA) feature.

The power consumption should be somewhat below that of the old HD 7670M. As a result, the 8590M is suited for 13-inch notebooks or larger.

ManufacturerAMD
Radeon HD 8500M Series

Radeon HD 8650G + HD 8570M Dual Graphics

768 @ 720 / 650 MHz64 Bit @ 1800 - 2000 MHz
Radeon HD 8590M 384 @ 620 MHz64 Bit @ 4500 MHz

Radeon HD 8450G + Radeon HD 8570M Dual Graphics

576 @ 720 / 650 MHz64 Bit @ 1800 MHz

Radeon HD 8570M

384 @ 650 MHz64 Bit @ 1800 - 2000 MHz

Radeon HD 8550M

384 @ 700 MHz64 Bit @ 1800 MHz
ArchitectureGCN
Pipelines384 - unified
Core Speed *620 MHz
Memory Speed *4500 MHz
Memory Bus Width64 Bit
Memory TypeGDDR5
Shared Memoryno
DirectXDirectX 11.1, Shader 5.0
technology28 nm
Notebook Sizemedium sized
Date of Announcement16.11.2012
* The specified clock rates are only guidelines for the manufacturer and can be altered by them.
