AMD Ryzen 5 5500U

AMD R5 5500U

The AMD Ryzen 5 5500U is a hexa-core APU of the Lucienne product family designed for use in ultra-thin, upper mid-range laptops. The processor was unveiled in H1 2021; its six CPU cores are based on the Zen 2 microarchitecture. The cores run at 2.1 GHz (base clock speed) to 4 GHz (highest Boost frequency possible) and feature the thread-doubling SMT technology for a total of 12 threads. The chip is manufactured on the modern 7 nm TSMC process.

One could be forgiven for thinking Ryzen 5 5500U is a renamed Ryzen 5 4500U - which is not the case. Ryzen 5 5500U is most similar to Ryzen 5 4600U, the most noteworthy difference between the two being the faster iGPU model of the former.

In the meantime, Ryzen 5 5600U got a little more lucky; it is based on the newer Zen 3 architecture and it also has higher clock speeds than what a 5500U can boast of.

Architecture

Ryzen 5 5500U and Ryzen 7 5700U are Zen 2-based while the neighbouring Ryzen 5 5600U and Ryzen 7 5800U use the latest Zen 3 architecture. This makes the former two a generation older than their names suggest. Still, Zen 2 is nothing to sneeze at, with its high performance-per-Watt and performance-per-MHz figures.

Ryzen 5 5500U supports dual-channel DDR4-3200 and quad-channel LPDDR4-4266 RAM and has 8 MB of Level 3 cache. Unlike desktop-grade Ryzen 5000-series processors, Ryzen 5 5500U is limited to PCI-Express 3.0 (not PCI-Express 4.0; no 7.9 GB/s NVMe SSDs here).

The processor gets soldered permanently on to the motherboard (FP6 socket interface) and is thus not user-replaceable.

Performance

The average 5500U in our database proves to be a very capable ULV CPU with performance levels approaching 45 W Intel Core i7 parts, like a Core i7-9750H or a Core i7-10750H. The Ryzen will have no trouble chewing through pretty much any workload, as of late 2021. Your mileage may vary depending on how high the Power Limits are and how competent the cooling solution of a laptop is.

Graphics

The Radeon RX Vega 7 iGPU has 7 CUs at its disposal (64 x 7 = 448 unified shaders) running at up to 1,800 MHz. Its real-life performance is close to what we've seen from GeForce MX250 and Iris Xe Graphics G7 (80 EUs); Mass Effect Legendary Edition (2021) runs well at 1080p resolution, low-to-medium settings, to give you an example. As the iGPU has no VRAM of its own, it is paramount that fast system RAM is used.

The graphics adapter definitely supports UHD 2160p monitors at 60 Hz. It will have no trouble HW-decoding HEVC, AVC, VP9, MPEG-2 and other popular video codecs. There is no AV1 support; AV1-encoded videos will be software-decoded, which six Zen 2 cores will handle with ease.

Power Consumption

The APU has a default TDP (also known as the long-term Power Limit) of 15 W. This can be set to anywhere between 10 W and 25 W by an OEM, and in most cases they do go for something higher than 15 W. Still, the 7 nm chip is a good fit for thinner, lighter laptops (with an active cooling solution, preferably) as well as tablets and gaming handhelds of various shapes and sizes.

SeriesAMD Lucienne (Zen 2, Ryzen 5000)
CodenameLucienne U (Zen 2)
Series: Lucienne (Zen 2, Ryzen 5000) Lucienne U (Zen 2)
AMD Ryzen 7 5700U compare1.8 - 4.3 GHz8 / 168 MB
» AMD Ryzen 5 5500U2.1 - 4 GHz6 / 128 MB
AMD Ryzen 3 5300U compare2.6 - 3.8 GHz4 / 84 MB
Clock Rate2100 - 4000 MHz
Level 1 Cache384 KB
Level 2 Cache3 MB
Level 3 Cache8 MB
Number of Cores / Threads6 / 12
Power Consumption (TDP = Thermal Design Power)25 Watt
Manufacturing Technology7 nm
Max. Temperature105 °C
SocketFP6
FeaturesXFR, FMA3, SSE 4.2, AVX2, SMT
GPUAMD Radeon RX Vega 7 ( - 1800 MHz)
64 Bit64 Bit support
Architecturex86
Announcement Date01/07/2021
Product Link (external)AMD Lucienne (Zen 2, Ryzen 5000) R5 5500U

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
40.4 pt (48%)
Cinebench R23 - Cinebench R23 Multi Core
min: 6030     avg: 7139     median: 7151 (12%)     max: 8353 Points
Cinebench R23 - Cinebench R23 Single Core
min: 1149     avg: 1172     median: 1172.5 (58%)     max: 1183 Points
Cinebench R20 - Cinebench R20 CPU (Single Core)
min: 452     avg: 456.9     median: 457 (58%)     max: 461 Points
Cinebench R20 - Cinebench R20 CPU (Multi Core)
min: 2223     avg: 2727     median: 2694.5 (11%)     max: 3213 Points
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 995     avg: 1214     median: 1245 (13%)     max: 1387 Points
07515022530037545052560067575082590097510501125120012751350Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 170     avg: 175.8     median: 177 (55%)     max: 177.6 Points
7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs
min: 31060     avg: 34240     median: 33890 (24%)     max: 36896 MIPS
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
min: 4174     avg: 4300     median: 4324 (52%)     max: 4356 MIPS
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
min: 7.23     avg: 8.5     median: 8.7 (19%)     max: 9.69 fps
0123456789101112131415
