Intel Xeon E3-1505M v6

Intel E3-1505M v6

The Intel Xeon E3-1505M v6 is a fast quad-core processor notebooks based on the Kaby Lake architecture and was announced in January 2017. It is the second fastest mobile Xeon model and the performance is slightly better tha the 100 MHz slower clocked consumer Core i7-7820HQ. Compared to the Core processors, the chip also supports ECC-RAM (error correction). Besides four cores including Hyper-Threading support running at 3 - 4 GHz (4 cores up to 3.6 GHz, 2 cores up to 3.8 GHz), the processor is also equipped with the professional HD Graphics P630 GPU as well as a dual-channel memory controller (DDR3L-1600/DDR4-2400). It is manufactured in a 14nm process with FinFET transistors.

Architecture

Intel basically uses the same micro architecture compared to Skylake, so the per-MHz performance does not differ. The manufacturer only reworked the Speed Shift technology for faster dynamic adjustments of voltages and clocks, and the improved 14nm process allows much higher frequencies combined with better efficiency than before.

Performance

Thanks to the higher clocks, even the smaller model of the mobile Xeons is ahead of the fastest Skylake models (Xeon E3-1575M v6) and is therefore als powerful enough for very demanding applications.

Graphics

The integrated professional Intel HD Graphics P630 has 24 Execution Units (similar to previous HD Graphics 530) running at 350 - 1100 MHz. The performance depends a lot on the memory configuration; it should be comparable to a dedicated Nvidia GeForce 920M in combination with fast DDR4-2133 dual-channel memory. It offers certified drivers for 15 professional and CAD applications.

Contrary to Skylake, Kaby Lake now supports hardware decoding for H.265/HEVC Main 10 with a 10-bit color depth as well as Google's VP9 codec. The dual-core Kaby Lake processors, which were announced in January, should also support HDCP 2.2.

Power Consumption

The chip is manufactured in an improved 14nm process with FinFET transistors, which improves the efficiency even further. Intel still specifies the TDP with 45 Watts, but it can also be reduced to 35 Watts by the notebook manufacturers (cTDP down). This will obviously affect the performance, because the Turbo Boost cannot be maintained for longer periods.



SeriesIntel Kaby Lake
CodenameKaby Lake
Series: Kaby Lake Kaby Lake
Intel Core i7-7700K compare4200 - 4500 MHz4 / 88 MB
Intel Core i7-7700 compare3600 - 4200 MHz4 / 88 MB
Intel Xeon E3-1535M v6 compare3100 - 4200 MHz4 / 88 MB
Intel Core i7-7920HQ compare3100 - 4100 MHz4 / 88 MB
Intel Core i7-7700T compare2900 - 3800 MHz4 / 88 MB
Intel Core i5-7600K compare3800 - 4200 MHz4 / 48 MB
» Intel Xeon E3-1505M v63000 - 4000 MHz4 / 88 MB
Intel Core i7-7820HQ compare2900 - 3900 MHz4 / 88 MB
Intel Core i7-7820HK compare2900 - 3900 MHz4 / 88 MB
Intel Core i7-7700HQ compare2800 - 3800 MHz4 / 86 MB
Intel Core i5-7500 compare3400 - 3800 MHz4 / 46 MB
Intel Core i5-7440HQ compare2800 - 3800 MHz4 / 46 MB
Intel Core i7-7567U compare3500 - 4000 MHz2 / 44 MB
Intel Core i7-7660U compare2500 - 4000 MHz2 / 44 MB
Intel Core i7-7600U compare2800 - 3900 MHz2 / 44 MB
Intel Core i5-7300HQ compare2500 - 3500 MHz4 / 46 MB
Intel Core i5-7500T compare2700 - 3300 MHz4 / 46 MB
Intel Core i5-7287U compare3300 - 3700 MHz2 / 44 MB
Intel Core i7-7560U compare2400 - 3800 MHz2 / 44 MB
Intel Core i5-7360U compare2300 - 3600 MHz2 / 44 MB
Intel Core i5-7267U compare3100 - 3500 MHz2 / 44 MB
Intel Core i7-7500U compare2700 - 3500 MHz2 / 44 MB
Intel Core i5-7300U compare2600 - 3500 MHz2 / 43 MB
Intel Core i5-7260U compare2200 - 3400 MHz2 / 44 MB
Intel Core i5-7200U compare2500 - 3100 MHz2 / 43 MB
Intel Core i3-7100H compare3000 MHz2 / 43 MB
Intel Core i3-7167U compare2800 MHz2 / 43 MB
Intel Core i3-7130U compare2700 MHz2 / 43 MB
Intel Core i7-7Y75 compare1300 - 3600 MHz2 / 44 MB
Intel Core i5-7Y57 compare1200 - 3300 MHz2 / 44 MB
Intel Core i5-7Y54 compare1200 - 3200 MHz2 / 44 MB
Intel Core i3-7100U compare2400 MHz2 / 43 MB
Intel Core m3-7Y32 compare1000 - 3000 MHz2 / 44 MB
Intel Pentium Gold 4415U compare2300 MHz2 / 42 MB
Intel Core m3-7Y30 compare1000 - 2600 MHz2 / 44 MB
Intel Celeron 3965U compare2200 MHz2 / 22 MB
Intel Core i3-7020U compare2300 MHz2 / 43 MB
Intel Celeron 3867U compare1800 MHz2 / 22 MB
Intel Celeron 3865U compare1800 MHz2 / 22 MB
Intel Pentium Gold 4425Y compare1700 MHz2 / 42 MB
Intel Pentium Gold 4415Y compare1600 MHz2 / 42 MB
Intel Pentium Gold 4410Y compare1500 MHz2 / 42 MB
Intel Celeron 3965Y compare1500 MHz2 / 22 MB
Clock Rate3000 - 4000 MHz
Level 1 Cache256 KB
Level 2 Cache1 MB
Level 3 Cache8 MB
Number of Cores / Threads4 / 8
Power Consumption (TDP = Thermal Design Power)45 Watt
Manufacturing Technology14 nm
Max. Temperature100 °C
FeaturesDual-Channel DDR4 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI, SIPP, vPro, TXT
GPUIntel HD Graphics P630 (300 - 1150 MHz)
64 Bit64 Bit support
Starting Price$623 U.S.
Announcement Date01/03/2017
Product Link (external)Intel Kaby Lake E3-1505M v6

Benchmarks

Cinebench R15 - CPU Multi 64Bit
min: 654     avg: 728     median: 737 (17%)     max: 792 Points
0102030405060708090100110120130140150160170180190200210220230240250260270280290300310320330340350360370380390400410420430440450460470480490500510520530540550560570580590600610620630640650660670680690700710720730740750760770780790800Tooltip
Cinebench R15 - CPU Single 64Bit
min: 170     avg: 170     median: 170 (76%)     max: 171 Points
Cinebench R11.5 - CPU Multi 64Bit
min: 7.89     avg: 8.3     median: 8.3 (19%)     max: 8.61 Points
Cinebench R11.5 - CPU Single 64Bit
1.9 Points (75%)
wPrime 2.10 - 1024m *
min: 319     avg: 327     median: 327.2 (4%)     max: 335.32 seconds
wPrime 2.10 - 32m *
min: 11     avg: 11     median: 11 (2%)     max: 11.02 seconds
WinRAR - Result
min: 3986     avg: 4554     median: 4554 (47%)     max: 5122 KB/s
X264 HD Benchmark 4.0 - Pass 2
min: 48     avg: 48.5     median: 48.5 (29%)     max: 49.05 fps
X264 HD Benchmark 4.0 - Pass 1
min: 185     avg: 185     median: 185 (64%)     max: 185.02 fps
3DMark 06 - CPU - CPU Score
min: 7230     avg: 7714     median: 7713.5 (52%)     max: 8197 Points
Super Pi mod 1.5 XS 1M - 1M *
min: 9     avg: 9.5     median: 9.5 (2%)     max: 10 Seconds
Super Pi mod 1.5 XS 2M - 2M *
min: 20     avg: 21.5     median: 21.5 (1%)     max: 23 Seconds
Super Pi Mod 1.5 XS 32M - 32M *
min: 489     avg: 509     median: 508.5 (2%)     max: 528 Seconds
3DMark 11 - Performance Physics 1280x720
min: 9594     avg: 9882     median: 9813 (44%)     max: 10239 points
3DMark - Ice Storm Unlimited Physics 1280x720 offscreen
min: 52711     avg: 53987     median: 53987 (62%)     max: 55263 Points
3DMark - Cloud Gate Standard Physics 1280x720
min: 4304     avg: 6891     median: 8126 (21%)     max: 8243 Points
3DMark - Fire Strike Physics 1920x1080
min: 6294     avg: 9708     median: 11348 (35%)     max: 11483 Points
Mozilla Kraken 1.1 - Total Score *
min: 847.3     avg: 884     median: 896.8 (2%)     max: 907.1 ms
Octane V2 - Total Score
min: 36239     avg: 39903     median: 39902.5 (76%)     max: 43566 Points
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
