NVIDIA GeForce GTX 1050 (Desktop) vs NVIDIA Quadro RTX 3000 (Laptop) vs NVIDIA GeForce GTX 1060 Max-Q

NVIDIA GeForce GTX 1050 (Desktop)

The Nvidia GeForce GTX 1050 is an entry level graphics card for desktops based on the Pascal architecture. It uses the same GP107 chip as the GTX 1050 Ti, but with only 640 instead of 768 shaders. The chip is manufactured at Samsung in 14 nm (opposed to the 16 nm TSCM based Pascal chips of the 1060 and up). The performance and specs should be similar to the GTX 1050 laptop version, that will be released later (early 2017). Compared to the faster GTX 1050 Ti, the 1050 offers less shaders (640 instead of 768) and only 2 GB of GDDR5 (instead of the 4 GB of the 1050 Ti).

Gaming benchmarks by Nvidia state that the GTX 1050 is about 30% faster on average than the Radeon RX 460 with 2 GB VRAM. The 4 GB version of the RX 460 should be about 10% slower and the older GTX 950 should reach a similar performance level as the new GTX 1050. Therefore, the GTX 1050 should be ideal for 1080p gaming with high detail settings (but not max settings).

NVIDIA Quadro RTX 3000 (Laptop)

NVIDIA GeForce GTX 1060 Max-Q

The Nvidia GeForce GTX 1060 with the Max-Q design is a mobile high-end GPU from the Pascal series. It is designed for thin and light laptops and about 10-15% slower than a regular GTX 1060 for laptops based on the cooling capabilities. The base frequency (1063-1265 MHz) is also much lower than on the regular GTX 1060 (1506 MHz, at least -16%) and the Boost (1341-1480 MHz) is also much lower compared to 1708 MHz (at least -13%) for the regular GTX 1060. The memory clock, however, is identical.

The clock is not the only difference compared to the regular GTX 1060 though. The drivers for the Max-Q version were optimized for efficiency (and not performance; only for Max-Q models), there are optimized voltage converters for 1V operation, high-end cooling methods, and a 40 dB limit for the fan noise (with clock adjustments to ensure this at all times).

Features

The GP106 chip is produced in 16nm FinFET at TSMC and offers a range of new features, like DisplayPort 1.4 (ready), HDMI 2.0b, HDR, Simultaneous Multi-Projection (SMP) and improved H.265 video de- and encoding (PlayReady 3.0). A list of improvements and features can be found in our article on the Pascal architecture.

The power consumption of the Max-Q design is notably lower than the normal GTX 1060 for laptops and ranges between 60 and 70 Watt (TGP) according to Nvidia.
