Intel Core i7-3610QM

Intel 3610QM

The Intel Core i7-3610QM is a fast quad-core processor for laptops based on the Ivy Bridge architecture. Due to Hyperthreading, the four cores can handle up to eight threads in parallel leading to better utilization of the CPU. Each core offers a base speed of 2.3 GHz but can dynamically increase clock rates with Turbo Boost up to 3.1 GHz (for 4 active cores), 3.2 GHz (for 2 active cores) and 3.3 GHz (for 1 active core).

Ivy Bridge is an enhanced die shrink of the Sandy Bridge architecture with improvements on both GPU and CPU performance. The CPUs are produced in 22nm (versus 32nm Sandy Bridge CPUs) and are the first to introduce 3D transistors for increased energy efficiency when compared to similarly clocked Sandy Bridge processors. Other new features are integrated PCI Express 3.0 and  DDR3(L)-1600 support. Except VT-d and vPro the 3610QM supports all functions of the Ivy Bridge core like VT-x, AES or Trusted Execution.

The performance of the Core i7-3610QM is slightly above a similarly clocked Sandy Bridge processor due to the architectural improvements. As a result, overall performance is similar to the former fastest model, the Core i7-2920XM.

The integrated Intel HD Graphics 4000 offers 16 Execution Units (EUs) clocked at 650 MHz up to 1100 MHz with Turbo Boost, making it one of the faster variants.

As with most quad-core Ivy Bridge models, the Core i7-3610QM is specified at a TDP of 45 Watts including graphics card and memory controller. Therefore, the CPU is well-suited for laptops 15-inches or greater.

SeriesIntel Core i7
CodenameIvy Bridge
Series: Core i7 Ivy Bridge
Intel Core i7-3940XM (compare)3000 - 3900 MHz4 / 88 MB
Intel Core i7-3920XM (compare)2900 - 3800 MHz4 / 88 MB
Intel Core i7-3840QM (compare)2800 - 3800 MHz4 / 88 MB
Intel Core i7-3820QM (compare)2700 - 3700 MHz4 / 88 MB
Intel Core i7-3740QM (compare)2700 - 3700 MHz4 / 86 MB
Intel Core i7-3720QM (compare)2600 - 3600 MHz4 / 86 MB
Intel Core i7-3635QM (compare)2400 - 3400 MHz4 / 86 MB
Intel Core i7-3630QM (compare)2400 - 3400 MHz4 / 86 MB
Intel Core i7-3615QM (compare)2300 - 3300 MHz4 / 86 MB
» Intel Core i7-3610QM2300 - 3300 MHz4 / 86 MB
Intel Core i7-3632QM (compare)2200 - 3200 MHz4 / 86 MB
Intel Core i7-3612QM (compare)2100 - 3100 MHz4 / 86 MB
Intel Core i7-3540M (compare)3000 - 3700 MHz2 / 44 MB
Intel Core i7-3520M (compare)2900 - 3600 MHz2 / 44 MB
Intel Core i7-3687U (compare)2100 - 3300 MHz2 / 44 MB
Intel Core i7-3667U (compare)2000 - 3200 MHz2 / 44 MB
Intel Core i7-3537U (compare)2000 - 3100 MHz2 / 44 MB
Intel Core i7-3517U (compare)1900 - 3000 MHz2 / 44 MB
Intel Core i7-3689Y (compare)1500 - 2600 MHz2 / 44 MB
Clock Rate2300 - 3300 MHz
Level 1 Cache256 KB
Level 2 Cache1 MB
Level 3 Cache6 MB
Number of Cores / Threads4 / 8
Max. Power Consumption (TDP = Thermal Design Power)45 Watt
Transistor Count1400 Million
Manufacturing Technology22 nm
Die Size160 mm2
Max. Temperature105 °C
SocketFCPGA988
FeaturesHD Graphics 4000 (650-1100MHz), DDR3(L)-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1100 MHz)
64 Bit64 Bit support
Starting Price$378 U.S.
Announcement Date04/23/2012
Product Link (external)Intel Core i7 3610QM

Benchmarks

Cinebench R11.5 - CPU Multi 64Bit
min: 3.44     avg: 6.1     median: 6.2 (23%)     max: 6.42 Points
+ 41 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 - CPU Single 64Bit
min: 0.72     avg: 1.3     median: 1.4 (56%)     max: 1.38 Points
+ 17 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Rendering Single 32Bit
min: 2410     avg: 4367.9     median: 4420 (48%)     max: 4594 Points
+ 37 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Rendering Multiple CPUs 32Bit
min: 9752     avg: 17071.8     median: 17230 (35%)     max: 17972 Points
+ 37 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Rendering Multiple CPUs 64Bit
min: 5650     avg: 20572.3     median: 21316 (28%)     max: 22148 Points
+ 39 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Rendering Single CPUs 64Bit
min: 2842     avg: 5543     median: 5588 (54%)     max: 6774 Points
+ 39 benchmarks and specifications   + Show comparison chart
wPrime 2.0x - 1024m *
min: 248.929     avg: 299.9     median: 279 (3%)     max: 395.929 seconds
+ 16 benchmarks and specifications   + Show comparison chart
wPrime 2.0x - 32m *
min: 8.5     avg: 9.7     median: 8.7 (2%)     max: 12.809 seconds
+ 15 benchmarks and specifications   + Show comparison chart
WinRAR - Result
min: 2637     avg: 4178.5     median: 4313 (51%)     max: 4447 KB/s
+ 13 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - Pass 2
min: 33.5     avg: 34.2     median: 34.3 (1%)     max: 34.6 fps
+ 12 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - Pass 1
min: 133     avg: 135.1     median: 134.9 (50%)     max: 137.35 fps
+ 12 benchmarks and specifications   + Show comparison chart
TrueCrypt - Serpent Mean 100MB
min: 0.287     avg: 0.3     median: 0.3 (17%)     max: 0.326 GB/s
+ 14 benchmarks and specifications   + Show comparison chart
TrueCrypt - Twofish Mean 100MB
min: 0.525     avg: 0.5     median: 0.5 (18%)     max: 0.554 GB/s
+ 14 benchmarks and specifications   + Show comparison chart
TrueCrypt - AES Mean 100MB
min: 2.9     avg: 3.1     median: 3.1 (16%)     max: 3.1 GB/s
+ 14 benchmarks and specifications   + Show comparison chart
3DMark 06 - CPU
min: 3522     avg: 5921.1     median: 6078 (42%)     max: 6464 Points
+ 40 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 1M *
min: 11     avg: 11.6     median: 11.3 (2%)     max: 16 Seconds
+ 23 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 2M *
min: 25     avg: 26.2     median: 26 (1%)     max: 29 Seconds
+ 23 benchmarks and specifications   + Show comparison chart
Super Pi Mod 1.5 XS 32M *
min: 603.851     avg: 620.5     median: 619.2 (3%)     max: 645 Seconds
+ 23 benchmarks and specifications   + Show comparison chart
SiSoft Sandra Dhrystone (MIPS)
min: 99000     avg: 114716     median: 121640 (58%)     max: 127440 MIPS
+ 11 benchmarks and specifications   + Show comparison chart
SiSoft Sandra Whetstone (MFLOPS)
min: 75000     avg: 76995.5     median: 77840 (60%)     max: 80560 MFLOPS
+ 11 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Processor
min: 6.3     avg: 7.5     median: 7.6 (97%)     max: 7.6 points
+ 32 benchmarks and specifications   + Show comparison chart
3DMark Vantage - P CPU no PhysX 1280x1024
min: 16136     avg: 21156.8     median: 21503 (36%)     max: 22164 Points
+ 39 benchmarks and specifications   + Show comparison chart
3DMark 11 - Performance Physics 1280x720
min: 3103     avg: 7294.8     median: 7684 (41%)     max: 8051 points
+ 43 benchmarks and specifications   + Show comparison chart
3DMark - Ice Storm Standard Physics 1280x720
min: 19256     avg: 38000.2     median: 40521.5 (26%)     max: 40919 Points
+ 10 benchmarks and specifications   + Show comparison chart
3DMark - Cloud Gate Standard Physics 1280x720
min: 3040     avg: 5645.2     median: 5987 (15%)     max: 6094 Points
+ 11 benchmarks and specifications   + Show comparison chart
3DMark - Fire Strike Physics 1920x1080
min: 4170     avg: 7766.9     median: 8277.5 (31%)     max: 8340 Points
+ 12 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Stream
5242 Points (42%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Memory
5320 Points (48%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Floating Point
11843 Points (34%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Integer
10752 Points (33%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Total Score
9493 Points (36%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
