Intel Core i7-6970HQ
The Intel Core i7-6970HQ is a fast quad-core processor for notebooks based on the Skylake architecture and was introduced in the beginning of 2016. Besides four CPU cores including Hyperthreading, which are clocked between 2.8-3.7 GHz (probable Turbo steps: 4 cores: up to 3.3 GHz, 2 cores: up to 3.5 GHz), the processor also includes a very fast graphics unit. The Iris Pro Graphics 580 (GT4e) has 72 EUs as well as 128 MB eDRAM cache, which can also be used by the CPU cores. It is manufactured using a 14 nm process with FinFET transistors.
Contrary to other models like the Core i7-6920HQ, the i7-6970HQ does have a much faster GPU, but neither supports the instruction set extensions TSX-NI nor vPro.
Intel uses Skylake to replace both Broadwell as well as Haswell and therefore uses one core design for all TDP classes between 4.5-45 Watts. Several improvements of the Skylake architecture include bigger Out-to-Order-Buffer, optimizations for pre-fetching as well as bigger gains by Hyperthreading. However, the changes are small for a "Tock" – a new micro architecture – in general, so the per-MHz performance is only between 5-10 % (compared to Haswell) or less than 5 % higher (compared to Broadwell), respectively.
The i7-6970HQ also benefits from the additional eDRAM cache in some cases, which can accelerate memory-heavy applications in particular.
Thanks to the additional eDRAM cache, the i7-6970HQ should even compete with the higher-clocked i7-6920HQ and is therefore one of the fastest notebook processors in the beginning of 2016. Even the most demanding applications and excessive multi-tasking are no problem for the high-end CPU.
The integrated GPU with the designation Iris Pro Graphics 580 (also known as "GT4e") represents the fastest version of the Skylake GPU (Intel Gen. 9). 72 Execution Units (EUs) run at 350 up to 1050 MHz and allow a performance comparable to a dedicated mainstream chip. The GPU might be able to compete with a GeForce 945M under perfect conditions and it is therefore the fastest iGPU on the market by a pretty big margin. Modern games from 2015/2016 can usually be played smoothly at medium settings. More information about the performance and the features is available on our dedicated page for the Iris Pro Graphics 580.
According to its TDP of 45 Watts, the chip is primarily designed for bigger notebooks starting with 15-inch screens. The TDP can optionally be reduced to 35 Watts (cTDP down), but this would obviously affect the performance.
|Series||Intel Core i7|
|Clock Rate||2800 - 3700 MHz|
|Level 1 Cache||256 KB|
|Level 2 Cache||1024 KB|
|Level 3 Cache||8192 KB|
|Number of Cores / Threads||4 / 8|
|Max. Power Consumption (TDP = Thermal Design Power)||45 Watt|
|Manufacturing Technology||14 nm|
|Max. Temperature||100 °C|
|Features||Dual-Channel DDR3L-1600/DDR4-2133 Memory Controller, AVX, AVX2, Quick Sync, Virtualization, AES-NI, TXT|
|GPU||Intel Iris Pro Graphics 580 (350 - 1050 MHz)|
|64 Bit||64 Bit support|
|Hardware Virtualization||VT-x, VT-d|
|Starting Price||$623 U.S.|
|Product Link (external)||Intel Core i7 6970HQ|
