Intel Core i5-3360M
The Intel Core i5-3360M is a fast dual-core processor for laptops based on the Ivy Bridge architecture. Due to Hyperthreading, the two cores can handle up to four threads in parallel leading to better utilization of the CPU. Each core offers a base speed of 2.8 GHz but can dynamically increase clock rates with Turbo Boost up to 3.3 GHz (for 2 active cores) and 3.5 GHz (for 1 active core). As its Sandy-Bridge-based predecessor Core i5-2540M , it offers a 3 MB L3-Cache.
Ivy Bridge is an enhanced d ie shrink of the Sandy Bridge architecture with improvements on both GPU and CPU performance. The CPUs are produced in 22nm (versus 32nm Sandy Bridge CPUs) and are the first to introduce 3D transistors for increased energy efficiency when compared to similarly clocked Sandy Bridge processors. Other new features are integrated PCI Express 3.0 and DDR3(L)-1600 support.
The performance of the Core i5-3360M is slightly above a similarly clocked Sandy Bridge processor due to the architectural improvements. As a result, overall performance is about 5 % above the old i7-2640M .
The integrated Intel HD Graphics 4000 offers 16 Execution Units (EUs) clocked at 650 MHz up to 1200 MHz with Turbo Boost, making it one of the faster variants.
Just like most other Ivy Bridge dual-cores, the i5-3360M is rated at a TDP of 35 W . Therefore, even smaller laptops can use the Core i5.
Series Intel Core i5 Codename Ivy Bridge Series: Core i5 Ivy Bridge Clock Rate 2800 - 3500 MHz Level 1 Cache 128 KB Level 2 Cache 512 KB Level 3 Cache 3 MB Number of Cores / Threads 2 / 4 Power Consumption (TDP = Thermal Design Power) 35 Watt Manufacturing Technology 22 nm Features HD Graphics 4000 (650-1200MHz), DDR3-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization GPU Intel HD Graphics 4000 (650 - 1200 MHz)64 Bit 64 Bit support Architecture x86 Starting Price $266 U.S. Announcement Date 06/03/2012 Product Link (external) ark.intel.com
Benchmarks Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.2 avg: 3.3 median: 3.3 (4%) max: 3.3 Points
...
...
max:
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.29 avg: 1.4 median: 1.4 (35%) max: 1.43 Points
...
...
max:
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 4303 avg: 4651 median: 4692 (28%) max: 4765 points
...
...
max:
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 9887 avg: 10111 median: 10140.5 (7%) max: 10191 points
...
...
max:
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 12217 avg: 12405 median: 12422 (9%) max: 12624 Points
...
...
max:
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 5740 avg: 5903 median: 5911 (7%) max: 6027 Points
...
...
wPrime 2.10 - wPrime 2.0 1024m *
min: 467.6 avg: 495.5 median: 506 (6%) max: 518 s
...
...
VIA C3-M C3-M-1200
wPrime 2.10 - wPrime 2.0 32m *
min: 14.77 avg: 16.7 median: 16.3 (3%) max: 19.13 s
...
...
min: 2630 avg: 3141 median: 3417 (5%) max: 3524 points
...
...
max:
X264 HD Benchmark 4.0 - x264 Pass 2
min: 4.07 avg: 9.8 median: 6.5 (2%) max: 18.68 fps
...
...
max:
X264 HD Benchmark 4.0 - x264 Pass 1
min: 32.52 avg: 55.2 median: 35.4 (8%) max: 97.7 fps
...
...
max:
TrueCrypt - TrueCrypt Serpent
min: 0.14 avg: 0.2 median: 0.2 (5%) max: 0.172 GB/s
...
...
max:
TrueCrypt - TrueCrypt Twofish
min: 0.24 avg: 0.3 median: 0.3 (5%) max: 0.294 GB/s
...
...
max:
TrueCrypt - TrueCrypt AES
min: 1.3 avg: 1.6 median: 1.6 (4%) max: 1.6 GB/s
...
...
max:
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3848 avg: 3975 median: 3994.5 (9%) max: 4041 Points
...
...
max:
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 11 avg: 11.4 median: 11 (2%) max: 13.14 s
...
...
VIA C3-M C3-M-1200
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 25 avg: 26 median: 26 (1%) max: 27.36 s
...
...
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 583 avg: 600 median: 599 (3%) max: 626 s
...
...
VIA C3-M C3-M-1200
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 54510 avg: 61935 median: 65030 (31%) max: 66000 MIPS
...
...
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 40000 avg: 40883 median: 40775 (31%) max: 41740 MFLOPS
...
...
max:
Windows 7 Experience Index - Win7 CPU
min: 7 avg: 7.2 median: 7.2 (92%) max: 7.2 Points
...
...
max:
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 10382 avg: 10794 median: 10792 (10%) max: 11280 Points
...
...
max:
3DMark 11 - 3DM11 Performance Physics
min: 3251 avg: 3875 median: 3968 (11%) max: 4292 Points
...
...
max:
3DMark - 3DMark Ice Storm Physics
min: 24772 avg: 32399 median: 34136.5 (28%) max: 36552 Points
...
...
max:
3DMark - 3DMark Cloud Gate Physics
min: 2789 avg: 3024 median: 3008.5 (8%) max: 3288 Points
...
...
max:
3DMark - 3DMark Fire Strike Standard Physics
min: 3903 avg: 4332 median: 4386.5 (8%) max: 4650 Points
...
...
max:
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
