AMD PRO A8-9600B

The AMD PRO A8-9600B is a mid-range APU of the Bristol Ridge series (7th generation of APUs) with 4 CPU-cores (two Excavator modules) clocked at 2.4 - 3.3 GHz. It is intended for business laptops and features the same specifications as the consumer AMD A10-9600P SoC.

It was announced in mid 2016 and is based on the same silicon as Carrizo but with more and refined features. It is a ULV-chip with a TDP of 15 Watt and integrates a Radeon R5 graphics card (384 shader cores / 6 compute cores) and a dual-channel DDR4-1866 memory controller. As Carrizo its a full featured SoC that offers all I/O ports on the chip.

The A10-9600P is slightly faster than the old 15-Watt top model of Carrizo, the FX-8800P. Therefore, the CPU performance is similar to a Broadwell 15 Watt Core i3 like The i3-5010U. See our Bristol Ridge article for more information on the architecture and improvements compared to Carrizo.

Series	AMD Bristol Ridge
Codename	Bristol Ridge
Series: Bristol Ridge Bristol Ridge AMD FX-9830P 3 - 3.7 GHz 4 / 4  AMD PRO A12-9830B 3 - 3.7 GHz 4 / 4  AMD FX-9800P 2.7 - 3.6 GHz 4 / 4  AMD PRO A12-9800B 2.7 - 3.6 GHz 4 / 4  AMD A12-9720P 2.7 - 3.6 GHz 4 / 4  AMD A12-9700P 2.5 - 3.4 GHz 4 / 4  AMD A10-9620P 2.5 - 3.4 GHz 4 / 4  AMD A10-9600P 2.4 - 3.3 GHz 4 / 4  AMD PRO A8-9600B « 2.4 - 3.3 GHz 4 / 4
Clock Rate	2400 - 3300 MHz
Level 2 Cache	2 MB
Number of Cores / Threads	4 / 4
Power Consumption (TDP = Thermal Design Power)	15 Watt
Transistor Count	3100 Million
Manufacturing Technology	28 nm
Die Size	250 mm2
Max. Temperature	90 °C
Socket	FP4
Features	Dual-Channel DDR3/DDR4-1866 Memory Controller, PCIe 3.0 x8
GPU	AMD Radeon R5 (Bristol Ridge) ( - 720 MHz)
64 Bit	64 Bit support
Architecture	x86
Announcement Date	06/01/2016
Product Link (external)	products.amd.com
