The Intel Core M-5Y10c is an ULV (ultra-low voltage) dual-core SoC based on the Broadwell architecture launched in late 2014. Thanks to its TDP of just 4.5 W (configurable), the CPU is suited for passively cooled tablets and 2-in-1 notebooks. In addition to two CPU cores with Hyper-Threading clocked at 0.8 - 2.0 GHz, the chip also integrates an HD Graphics 5300 GPU and a dual-channel LPDDR3/DDR3L(-RS) memory controller up to 25.6 GB/s. The chip is manufactured in a 14 nm process with FinFET transistors.
Architecture
Broadwell represents the "Tick" in Intel's Tick-Tock model, which means a shrink of its predecessor Haswell. The new 14 nm manufacturing process with three-dimensional FinFET transistors allows not only improvements in energy efficiency, but also a significantly smaller die size fit for more compact packages and devices.
Further advantages result from the revised microarchitecture of Broadwell. Due to its improved branch prediction, bigger buffer sizes (1500 instead of 1000 entries in the L2 TLB) and other tweaks, the performance per clock has been increased by more than 5 percent over its predecessor. There are also some new instruction set extensions designed for cryptographic applications.
Performance
The Core M-5Y10c offers a very wide turbo range from 0.8 - 2.0 GHz; however, the actual frequency will be largely limited by the TDP. Overall, performance is similar to a Core i3-4010U (Haswell, 15 W). Accordingly, the main purpose of Broadwell's higher power efficiency is to reduce power consumption instead of improving raw performance.
The Core M-5Y10c will be sufficient for office and multimedia purposes as well as more demanding applications.
Graphics
The integrated HD Graphics 5300 offers 24 Execution Units (EUs) clocked at 300 - 800 MHz. Similar to the CPU core, the GPU architecture (Intel Gen 8) has been thoroughly revised for improved performance-per-clock. However, the GPU frequency is also limited by the TDP, which prevents significant performance boosts over the older HD 4200 under continuous 3D load. Current games as of 2014 will be playable in low settings and XGA resolution.
Broadwell is the first Intel chip to fully support DirectX 11.2 as well as OpenCL 1.3/2.0 and OpenGL 4.3. Video will output natively via DisplayPort 1.2 or HDMI 1.4a. However, the new HDMI 2.0 standard is not supported.
Power Consumption
With a TDP of only 4.5 W, the Core M-5Y10c draws noticeably less power than the Haswell Y-series (11.5 W). However, the TDP can be set to different values such as 3.5 or 6 W, affecting clock rates and performance (6 W: 1.0 GHz base clock, 3.5 W: 0.6 GHz base clock). The CPU can be passively cooled even in thin tablets.
| Codename | Broadwell | ||||||||||||||||||||||||||||
| Series | Intel Core M | ||||||||||||||||||||||||||||
Series: Core M Broadwell
| |||||||||||||||||||||||||||||
| Clock Rate | 800 - 2000 MHz | ||||||||||||||||||||||||||||
| Level 1 Cache | 128 KB | ||||||||||||||||||||||||||||
| Level 2 Cache | 512 KB | ||||||||||||||||||||||||||||
| Level 3 Cache | 4 MB | ||||||||||||||||||||||||||||
| Number of Cores / Threads | 2 / 4 | ||||||||||||||||||||||||||||
| Power Consumption (TDP = Thermal Design Power) | 4.5 Watt | ||||||||||||||||||||||||||||
| Transistor Count | 1300 Million | ||||||||||||||||||||||||||||
| Manufacturing Technology | 14 nm | ||||||||||||||||||||||||||||
| Die Size | 82 mm2 | ||||||||||||||||||||||||||||
| Max. Temperature | 95 °C | ||||||||||||||||||||||||||||
| Socket | FCBGA1234 | ||||||||||||||||||||||||||||
| Features | HD Graphics 5300 (300 - 800 MHz), Dual-Channel DDR3L(-RS)/LPDDR3 Memory Controller (max. 800 MHz, 25.6 GB/s), HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI | ||||||||||||||||||||||||||||
| GPU | Intel HD Graphics 5300 (300 - 800 MHz) | ||||||||||||||||||||||||||||
| 64 Bit | 64 Bit support | ||||||||||||||||||||||||||||
| Architecture | x86 | ||||||||||||||||||||||||||||
| Announcement Date | 12/01/2014 | ||||||||||||||||||||||||||||
| Product Link (external) | ark.intel.com | ||||||||||||||||||||||||||||
- Average benchmark values for this graphics card
Acer Aspire Switch 11V SW5-173-63NV: Intel HD Graphics 5300, 11.60", 1.6 kg
External Review » Acer Aspire Switch 11V SW5-173-63NV
Asus UX305FA-FB012H: Intel HD Graphics 5300, 13.30", 1.2 kg
External Review » Asus UX305FA-FB012H
Acer Aspire Switch 11V-SW5-173-62J8: Intel HD Graphics 5300, 11.60", 1.5 kg
External Review » Acer Aspire Switch 11V-SW5-173-62J8
Acer Aspire Switch 11 V SW5-173: Intel HD Graphics 5300, 11.60", 1.5 kg
External Review » Acer Aspire Switch 11 V SW5-173
HP Pavilion 11-n108TU x360: Intel HD Graphics 5300, 11.60", 1.4 kg
External Review » HP Pavilion 11-n108TU x360
Lenovo Yoga 3 11 80J8001WGE: Intel HD Graphics 5300, 11.60", 1.1 kg
External Review » Lenovo Yoga 3 11 80J8001WGE
Lenovo Yoga 3 11: Intel HD Graphics 5300, 11.60", 1.2 kg
External Review » Lenovo Yoga 3 11
Acer Aspire Switch 12 SW5-271-61X7: Intel HD Graphics 5300, 12.50", 1.5 kg
External Review » Acer Aspire Switch 12 SW5-271-61X7
