Intel Core m5-6Y57

Intel 6Y57

The Intel Core m5-6Y57 is a very power efficient dual-core SoC based on the Skylake architecture and has been launched in September 2015. Thanks to its extremely low TDP, the CPU can be found in passively cooled tablets and 2-in-1 notebooks. In addition to two CPU cores with Hyper-Threading clocked at 1.1 - 2.8 GHz (2 cores: max. 2.4 GHz), the chip also integrates an HD Graphics 515 GPU and a dual-channel LPDDR3-1866/DDR3L-1600 memory controller. The chip is manufactured using a 14 nm process with FinFET transistors.

Architecture

Skylake replaces both Haswell and Broadwell and brings the same microarchitecture in every TDP class from 4.5 to 45 W. The extensive improvements of the Skylake design include increased out-of-order buffers, optimized prefetching and branch prediction as well as additional performance gains through Hyper-Threading. Overall, however, performance per clock has been increased by only 5 to 10 percent (compared to Haswell) respectively under 5 percent (compard to Broadwell), which is quite modest for a new architecture ("Tock").

Performance

Actual performance of the Core m5-6Y57 greatly depends on cooling capabilities and TDP configuration of the related device. While the CPU may be similar to a Core i5-6200U (Skylake, 15 W) in short benchmarks, its performance will fall short of a Core i3-6100U under continuous full load. Overall, the chip has sufficient power for office and multimedia purposes as well as somewhat more demanding applications.

Graphics

The integrated graphics unit called HD Graphics 515 represents the "GT2" version of the Skylake GPU (Intel Gen. 9). The 24 Execution Units, also called EUs, are clocked at 300 - 900 MHz (limited by available TDP headroom) and offer a performance somewhere in range of the old HD Graphics 4400 (Haswell, 15 W). Only a few games of 2015 can be played smoothly in lowest settings. For more information about performance and features, check our page for the HD Graphics 515.

Power Consumption

Specified at a TDP of 4.5 W (including CPU, GPU and memory controller), the CPU is suited for passively cooled notebooks and tablets. Optionally, the TDP can be lowered to 3.5 watts (cTDP down) or raised to 7 watts (cTDP up), affecting both heat dissipation and performance.

SeriesIntel Core m5
CodenameSkylake
Clock Rate1100 - 2800 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache4096 KB
Number of Cores / Threads2 / 4
Max. Power Consumption (TDP = Thermal Design Power)4.5 Watt
Manufacturing Technology14 nm
Die Size99 mm2
Max. Temperature100 °C
SocketBGA
FeaturesDual-Channel DDR3L-1600/LPDDR3-1866 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI, vPro, TXT
GPUIntel HD Graphics 515 (300 - 900 MHz)
64 Bit64 Bit support
Hardware VirtualizationVT-x, VT-d
Starting Price $281 U.S.
Announcement Date09/01/2015
Product Link (external)Intel Core m5 6Y57

Benchmarks

Octane V2 - Total Score
0%
100%
min: 22402     avg: 26345.3 (59%)     median: 28156 (63%)     max: 28478 Points
Cinebench R15 - CPU Single 64Bit
0%
100%
min: 95     avg: 98 (44%)     median: 98 (44%)     max: 101 Points
Cinebench R15 - CPU Multi 64Bit
0%
100%
min: 171     avg: 175.5 (9%)     median: 175.5 (9%)     max: 180 Points
Mozilla Kraken 1.1 - Total Score
0%
100%
min: 1055.9     avg: 1302.3 (2%)     median: 1258.6 (2%)     max: 1592.4 ms
Geekbench 3 - 32 Bit Multi-Core Score
0%
100%
min: 5244     avg: 5244 (17%)     median: 5244 (17%)     max: 5244 Points
Geekbench 3 - 32 Bit Single-Core Score
0%
100%
min: 2672     avg: 2672 (57%)     median: 2672 (57%)     max: 2672 Points
Geekbench 3 - 64 Bit Multi-Core Score
0%
100%
min: 5633     avg: 5633 (17%)     median: 5633 (17%)     max: 5633 Points
Geekbench 3 - 64 Bit Single-Core Score
0%
100%
min: 2780     avg: 2780 (58%)     median: 2780 (58%)     max: 2780 Points
3DMark - Fire Strike Physics 1920x1080
0%
100%
min: 2681     avg: 2807.5 (13%)     median: 2807.5 (13%)     max: 2934 Points
3DMark - Cloud Gate Standard Physics 1280x720
0%
100%
min: 1848     avg: 1951.5 (5%)     median: 1951.5 (5%)     max: 2055 Points
3DMark - Ice Storm Unlimited Physics 1280x720 offscreen
0%
100%
min: 26372     avg: 26372 (38%)     median: 26372 (38%)     max: 26372 Points
3DMark - Ice Storm Extreme Physics 1920x1080
0%
100%
min: 24101     avg: 24362.5 (37%)     median: 24362.5 (37%)     max: 24624 Points
3DMark - Ice Storm Standard Physics 1280x720
0%
100%
min: 24245     avg: 24508.5 (16%)     median: 24508.5 (16%)     max: 24772 Points
Sunspider - 1.0 Total Score
0%
100%
min: 89.3     avg: 159.1 (4%)     median: 159.1 (4%)     max: 228.8 ms
TrueCrypt - Serpent Mean 100MB
0%
100%
min: 0.151     avg: 0.2 (0%)     median: 0.2 (0%)     max: 0.151 GB/s
TrueCrypt - AES Mean 100MB
0%
100%
min: 1.5     avg: 1.5 (14%)     median: 1.5 (14%)     max: 1.5 GB/s
X264 HD Benchmark 4.0 - Pass 2
0%
100%
min: 11.72     avg: 11.7 (12%)     median: 11.7 (12%)     max: 11.72 fps
X264 HD Benchmark 4.0 - Pass 1
0%
100%
min: 92.55     avg: 92.6 (40%)     median: 92.6 (40%)     max: 92.55 fps
wPrime 2.0x - 1024m
0%
100%
min: 892.201     avg: 892.2 (11%)     median: 892.2 (11%)     max: 892.201 seconds
3DMark 11 - Performance Physics 1280x720
0%
100%
min: 2517     avg: 2599 (16%)     median: 2599 (16%)     max: 2681 points
3DMark 06 - CPU -
0%
100%
min: 2596     avg: 2596 (24%)     median: 2596 (24%)     max: 2596 Points
Cinebench R11.5 - CPU Single 64Bit
0%
100%
min: 1.1     avg: 1.1 (51%)     median: 1.1 (51%)     max: 1.16 Points
Cinebench R11.5 - CPU Multi 64Bit
0%
100%
min: 1.93     avg: 2 (10%)     median: 2 (10%)     max: 2.03 Points
Cinebench R10 - Rendering Single CPUs 64Bit
0%
100%
min: 4859     avg: 4859 (54%)     median: 4859 (54%)     max: 4859 Points
Cinebench R10 - Rendering Multiple CPUs 64Bit
0%
100%
min: 7877     avg: 7877 (19%)     median: 7877 (19%)     max: 7877 Points
Cinebench R10 - Rendering Single 32Bit
0%
100%
min: 3809     avg: 3849 (52%)     median: 3849 (52%)     max: 3889 Points
Cinebench R10 - Rendering Multiple CPUs 32Bit
0%
100%
min: 6204     avg: 6428 (16%)     median: 6428 (16%)     max: 6652 Points
Super Pi mod 1.5 XS 1M -
0%
100%
min: 13.376     avg: 13.4 (3%)     median: 13.4 (3%)     max: 13.376 Seconds
Super Pi mod 1.5 XS 2M -
0%
100%
min: 30.128     avg: 30.1 (1%)     median: 30.1 (1%)     max: 30.128 Seconds
Super Pi Mod 1.5 XS 32M -
0%
100%
min: 746.877     avg: 746.9 (3%)     median: 746.9 (3%)     max: 746.877 Seconds
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
