Intel Pentium Dual Core T4500

Intel T4500

The Intel Pentium T4500 (or Intel Pentium Dual-Core T4500) is an entry level dual-core CPU for laptops. Compared to the Core 2 Duo CPUs, the T4500 has only 1 MB Level 2 cache and some power saving technology is deactivated.

Therefore, the power consumption in idle mode should be a bit above similar clocked Core 2 Duo CPUs. Furtheremore, virtualization technology VT-x is also not available for the T4500.

Due to the slow clock rate and the small level 2 cache, the Pentium T4500 will limit the performance of demanding 3D games (e.g. Supreme Commander). For entry level applications like office, SD video cutting, image processing, Internet and casual gaming, the T4500 should be sufficient.

The Pentium T4500 is based on the Intel Penryn core and features 2 integer units, 1 floating point unit, 1 load unit, and 1 store unit in a 14-step pipeline.

SeriesIntel Pentium Dual Core
CodenamePenryn

Series: Pentium Dual Core Penryn

Intel Pentium Dual Core T4500 « 2.3 GHz2 / 2 cores
Intel Pentium Dual Core T4400 compare2.2 GHz2 / 2 cores
Intel Pentium Dual Core T4300 compare2.1 GHz2 / 2 cores
Intel Pentium Dual Core T4200 compare2 GHz2 / 2 cores
Intel Pentium Dual Core SU4100 compare1.3 GHz2 / 2 cores
Clock Rate2300 MHz
Front Side Bus800
Level 1 Cache128 KB
Level 2 Cache1 MB
Number of Cores / Threads2 / 2
Power Consumption (TDP = Thermal Design Power)35 Watt
Transistor Count410 Million
Features45 nm, 1.05-1.15V
Die Size107 mm2
SocketPGA478
FeaturesMMX, SSE, SSE2, SSE3, SSSE3, Enhanced Intel SpeedStep Technology (EIST), Intel 64, XD bit, iAMT2 (Intel Active Management), TXT
64 Bit64 Bit support
Architecturex86
Announcement Date01/10/2009
Product Link (external)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
1.3 Points (2%)
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 2234     avg: 2315     median: 2331 (14%)     max: 2367 points
+ 5 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 4283     avg: 4366     median: 4337 (3%)     max: 4490 points
+ 5 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 4458     avg: 4594     median: 4578 (3%)     max: 4747 Points
+ 3 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 2388     avg: 2447     median: 2416 (3%)     max: 2538 Points
+ 3 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 1024m *
min: 1137     avg: 1142     median: 1137 (13%)     max: 1152 s
+ 3 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 32m *
min: 35.7     avg: 35.9     median: 35.7 (7%)     max: 36.2 s
+ 3 benchmarks and specifications   + Show comparison chart
3DMark 06 - CPU - 3DMark 06 - CPU
min: 1887     avg: 1920     median: 1898 (4%)     max: 1995 Points
+ 4 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 25     avg: 25.6     median: 25.6 (6%)     max: 26.2 s
+ 2 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 62     avg: 62.9     median: 62.9 (3%)     max: 63.8 s
+ 2 benchmarks and specifications   + Show comparison chart
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
1502 s (7%)
+ 1 benchmarks and specifications   + Show comparison chart
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
21100 MIPS (10%)
+ 1 benchmarks and specifications   + Show comparison chart
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
15460 MFLOPS (12%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark 05 - PCMark 05 - Standard
min: 3747     avg: 3865     median: 3865 (8%)     max: 3983 Points
+ 2 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 CPU
5.8 Points (74%)
+ 3 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
