Intel Core i7-5775C

Intel 5775C

The Intel Core i7-5775C is a high-end quad-core desktop processor based on the Broadwell architecture. It was announced in June 2015 and offers 4 cores at 3.3 to 3.7 GHz (Turbo Boost). Thanks to Hyperthreading 8 threads can be worked on in parallel.

The speciality of the i7-5775C is the 128 MB eDRAM cache on the chip that works as a L4 cache for the CPU and integrated graphics card (Iris Pro Graphics 6200 GT3e, see for more details and benchmarks). The GPU offers 48 EUs (execution units) clocked at 300 to 1150 MHz. Thanks to the eDRAM it is similar fast to a dedicated GeForce 940M.

Rated at a TDP of 65 Watt the Core i7 is suited for Desktop PCs and very large desktop replacement laptops (like the Clevo P770ZM).

SeriesIntel Core i7 (Desktop)
CodenameBroadwell
Clock Rate3300 - 3700 MHz
Level 1 Cache256 KB
Level 2 Cache1024 KB
Level 3 Cache6144 KB
Number of Cores / Threads4 / 8
Max. Power Consumption (TDP = Thermal Design Power)65 Watt
Manufacturing Technology14 nm
SocketFCLGA1150
FeaturesIris Pro Graphics 6200 (300 - 1150 MHz), DDR3L-1600 Memory Controller, HyperThreading, AVX, AVX2, TSX-NI, Quick Sync, Virtualization
GPUIntel Iris Pro Graphics 6200 (300 - 1150 MHz)
64 Bit64 Bit support
Hardware VirtualizationVT-x, VT-d
Starting Price $366 U.S.
Announcement Date06/02/2015
Product Link (external)Intel Core i7 (Desktop) 5775C

Benchmarks

Cinebench R15 - CPU Single 64Bit
0%
100%
min: 152     avg: 152.3 (78%)     median: 152 (78%)     max: 153 Points
+ 3 benchmarks and specifications   + Show comparison chart
Cinebench R15 - CPU Multi 64Bit
0%
100%
min: 756     avg: 769.3 (36%)     median: 772 (36%)     max: 780 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - Fire Strike Physics 1920x1080
0%
100%
min: 11250     avg: 11790.8 (52%)     median: 11888 (53%)     max: 12137 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark - Cloud Gate Standard Physics 1280x720
0%
100%
min: 8254     avg: 8563 (22%)     median: 8602 (22%)     max: 8833 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - Ice Storm Unlimited Physics 1280x720 offscreen
0%
100%
min: 58293     avg: 58293 (84%)     median: 58293 (84%)     max: 58293 Points
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - Ice Storm Extreme Physics 1920x1080
0%
100%
min: 56825     avg: 57612.5 (87%)     median: 57612.5 (87%)     max: 58400 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark - Ice Storm Standard Physics 1280x720
0%
100%
min: 57711     avg: 57711 (37%)     median: 57711 (37%)     max: 57711 Points
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - Serpent Mean 100MB
0%
100%
min: 0.4     avg: 0.4 (24%)     median: 0.4 (24%)     max: 0.4 GB/s
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - Twofish Mean 100MB
0%
100%
min: 0.704     avg: 0.7 (33%)     median: 0.7 (34%)     max: 0.704 GB/s
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - AES Mean 100MB
0%
100%
min: 4.4     avg: 4.4 (36%)     median: 4.4 (36%)     max: 4.4 GB/s
+ 1 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - Pass 2
0%
100%
min: 46.24     avg: 46.2 (38%)     median: 46.2 (38%)     max: 46.24 fps
+ 1 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - Pass 1
0%
100%
min: 179.84     avg: 179.8 (77%)     median: 179.8 (77%)     max: 179.84 fps
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.0x - 1024m
0%
100%
min: 196.69     avg: 196.7 (2%)     median: 196.7 (2%)     max: 196.69 seconds
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.0x - 32m
0%
100%
min: 6.297     avg: 6.3 (1%)     median: 6.3 (1%)     max: 6.297 seconds
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - Performance Physics 1280x720
0%
100%
min: 9875     avg: 9976 (61%)     median: 9976 (61%)     max: 10077 points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 06 - CPU -
0%
100%
min: 7933     avg: 7933 (63%)     median: 7933 (63%)     max: 7933 Points
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 - CPU Single 64Bit
0%
100%
min: 1.79     avg: 1.8 (81%)     median: 1.8 (81%)     max: 1.79 Points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 - CPU Multi 64Bit
0%
100%
min: 8.29     avg: 8.3 (35%)     median: 8.3 (35%)     max: 8.35 Points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Rendering Single CPUs 64Bit
0%
100%
min: 7756     avg: 7756 (86%)     median: 7756 (86%)     max: 7756 Points
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Rendering Multiple CPUs 64Bit
0%
100%
min: 29510     avg: 29510 (72%)     median: 29510 (72%)     max: 29510 Points
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Rendering Single 32Bit
0%
100%
min: 5844     avg: 5844 (79%)     median: 5844 (79%)     max: 5844 Points
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Rendering Multiple CPUs 32Bit
0%
100%
min: 22261     avg: 22261 (45%)     median: 22261 (45%)     max: 22261 Points
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 1M -
0%
100%
min: 10.312     avg: 10.3 (2%)     median: 10.3 (2%)     max: 10.312 Seconds
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 2M -
0%
100%
min: 23.125     avg: 23.1 (1%)     median: 23.1 (1%)     max: 23.125 Seconds
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi Mod 1.5 XS 32M -
0%
100%
min: 515.944     avg: 522 (2%)     median: 522 (2%)     max: 528 Seconds
+ 2 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
