Rockchip RK3566

RK3566

The Rockchip RK3566 is an entry-level ARM SoC (system-on-a-chip) introduced in 2020, which is primarily used in AIot devices and e-ink tablets, for example in Lenovo's Paper Smart. The chip is manufactured in 22nm and integrates four ARM Cortex-A55 cores with up to 2 GHz. As a GPU it integrates a ARM Mali-G52 MP2 (2 cores). Furthermore, a video decoder with H.264 and H.265 support is integrated, among other things.

Besides the CPU and graphics chip, the chip also integrates an LPDDR3/LPDDR4x memory controller, but no cellular modem. Das SoC beinhaltet ein Modem für Wi-Fi 5 (a/b/g/n/ac). Furthermore, an AI unit with 1 TOPS is installed.

Series
CodenameARM Cortex-A55

Series: ARM Cortex-A55

Rockchip RK3566 « - 2 GHz4 / 4 cores ARM Cortex-A55
Samsung Exynos W930 compare1.4 GHz2 / 2 cores
Samsung Exynos W920 compare1.18 GHz2 / 2 cores ARM Cortex-A55
Clock Rate <=2000 MHz
Number of Cores / Threads4 / 4
Manufacturing Technology22 nm
GPUARM Mali-G52 MP2
64 Bit64 Bit support
ArchitectureARM
Announcement Date01/01/2020
Product Link (external)www.96rocks.com

Benchmarks

3DMark - 3DMark Sling Shot Extreme (ES 3.1) Unlimited Physics
1061 Points (13%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 6.2 - Geekbench 6.2 Single-Core
203 points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 6.2 - Geekbench 6.2 Multi-Core
493 points (2%)
+ 1 benchmarks and specifications   - Hide comparison chart
Geekbench 5.5 - Geekbench 5.1 - 5.5 64 Bit Single-Core
143 points (6%)
+ 1 benchmarks and specifications   - Hide comparison chart
Geekbench 5.5 - Geekbench 5.1 - 5.5 64 Bit Multi-Core
312 points (1%)
+ 1 benchmarks and specifications   - Hide comparison chart
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
745 points (7%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
1418 points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
34733 ms (41%)
+ 1 benchmarks and specifications   + Show comparison chart
Octane V2 - Octane V2 Total Score
5022 Points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 4 - WebXPRT 4 Score
21 Points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 3 - WebXPRT 3 Score
36 Points (8%)
+ 1 benchmarks and specifications   + Show comparison chart
Antutu v9 - AnTuTu v9 Total Score
105826 Points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
Antutu v9 - AnTuTu v9 CPU
29585 Points (8%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Work Score 3.0
4045 Points (19%)
+ 1 benchmarks and specifications   + Show comparison chart
CrossMark - CrossMark Overall
172 Points (7%)
+ 1 benchmarks and specifications   + Show comparison chart
Power Consumption - Geekbench 5.5 Power Consumption 150cd *
5.8 Watt (3%)
+ 1 benchmarks and specifications   + Show comparison chart
01234567Tooltip
Power Consumption - Idle Power Consumption 150cd 1min *
1.8 Watt (2%)
+ 1 benchmarks and specifications   + Show comparison chart
00.10.30.40.60.70.911.21.31.41.61.71.922.22.32.42.62.7Tooltip
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
