The NXP i.MX 8M Mini (or iMX8 Mini) is an SoC for IoT and consumer devices that do not require too much computing power, such as electronic notebooks or e-readers. The SoC was presented at the end of 2022.
The processor has four Cortex-A53 cores with a clock speed of up to 1.8 GHz and comes with a 512 KB L2 cache. The SoC also integrates an additional Cortex-M4 core with 400 MHz for security tasks and for simple calculations with very low energy consumption.
LPDDR4 is supported as RAM and eMMC 5.1 can be integrated as data storage. A Vivante GC Nano Ultra with a clock speed of up to 400 MHz is used as the graphics unit. The video decoder and encoder can each process up to 1080p at 60 fps.
The SoC is manufactured using the 14 nm FinFET process.
| Clock Rate | <=1800 MHz |
| Level 1 Cache | 288 KB |
| Level 2 Cache | 512 KB |
| Number of Cores / Threads | 5 / 5 4 x 1.8 GHz ARM Cortex-A53 1 x 0.4 GHz ARM Cortex-M4 |
| Manufacturing Technology | 14 nm |
| Features | (LP)DDR4-3200, SDIO 3.0, eMMC 5.1, 1x PCIe 2.0 |
| GPU | Vivante GC Nano Ultra |
| 64 Bit | 64 Bit support |
| Architecture | ARM |
| Announcement Date | 12/01/2022 |
| Product Link (external) | www.nxp.com |
