The Unisoc T750 (Tanggula, former Spreadtrum) is a mid range SoC for Android based smartphones and tablets. It integrates an octa-core CPU with two clusters. Two fast ARM Cortex-A76 cores clocked at up to 2 GHz and six small ARM-Cortex-A55 cores at again up to 1.8 GHz for efficiency. The faster T760 SoC offers two more A76 cores, a faster GPU and a faster memory controller.
The integrated memory controller supports LPDDR4X with up to 1866 MHz. The integrated ISP supports two main cameras (up to 64 MPix). The integrated graphics card is an ARM Mali-G57 MC2 (2 cores) at up to 680 MHz. The integrated modem supports Wi-Fi 5 WLAN, 5G (TDD+FDD CA Sub-6GHz), and Cat15DL / Cat18 UL LTE.
The chip is manufactured in the modern 6nm process.
|Codename||Cortex-A76 / A55|
Series: Cortex-A76 / A55
|Clock Rate||1800 - 2000 MHz|
|Level 3 Cache||3 MB|
|Number of Cores / Threads||8 / 8|
|Manufacturing Technology||6 nm|
|Features||5G, LTE, ISP (up to 64MPixel), eMMC 5.1, UFS 3.1, LPDDR4X 1866MHz, LTE, GPS, Glonass, Beidou, Galileo, 802.11 b/g/n/ac, Bloetooth 5.0, FM-Radio, TEE Security|
|GPU||ARM Mali-G57 MP2 ( - 680 MHz)|
|64 Bit||64 Bit support|
