UNISOC Tangula T770

Tangula T770

The Unisoc T770 Tanggula (former Spreadtrum) is a mid range SoC for Android based smartphones and tablets. It integrates an octa-core CPU with three clusters. One fast ARM Cortex-A76 clocked at up to 2.5 GHz, three more A76 performance cores clocked at up to 2.2 GHz and a power efficiency cluster of four ARM-Cortex-A55 cores with up to 2 GHz. The integrated memory controller supports LPDDR4/4X with up to 2133 MHz (2x 16 Bit). The integrated ISP supports two main cameras and two subsidiary cameras (up to 108 MPix). The integrated graphics card is an ARM Mali-G57 MC4 (4 cores) at up to 780 MHz. Unisoc also specifies that the T770 offers hardware AI acceleration.

The chip is manufactured in the modern 6nm process.

Series
CodenameCortex-A76 / A55

Series: Cortex-A76 / A55

MediaTek Dimensity 820 compare2 - 2.6 GHz8 / 8 cores Cortex-A76 / A55
MediaTek Dimensity 810 compare2 - 2.4 GHz8 / 8 cores Cortex-A76 / A55
MediaTek Dimensity 800 compare2 GHz8 / 8 cores Cortex-A76 / A55
MediaTek Dimensity 800U compare2 - 2.4 GHz8 / 8 cores Cortex-A76 / A55
UNISOC T820 compare2.1 - 2.7 GHz8 / 8 cores Cortex-A76 / A55
UNISOC Tangula T770 « 2 - 2.5 GHz8 / 8 cores Cortex-A76 / A55
UNISOC Tangula T760 compare2 - 2 GHz8 / 8 cores3 MB L3 Cortex-A76 / A55
MediaTek Dimensity 700 compare2 - 2.2 GHz8 / 8 cores Cortex-A76 / A55
MediaTek Dimensity 720 compare2 GHz8 / 8 cores Cortex-A76 / A55
UNISOC T750 compare1.8 - 2 GHz8 / 8 cores3 MB L3 Cortex-A76 / A55
Clock Rate2000 - 2500 MHz
Number of Cores / Threads8 / 8
Manufacturing Technology6 nm
FeaturesISP (2 main + 2 subsidiary, 108M 4-in-1, 64M ZSL)
GPUARM Mali-G57 MP4 ( - 780 MHz)
64 Bit64 Bit support
ArchitectureARM
Announcement Date01/01/2020

Benchmarks

Geekbench 5.4 - Geekbench 5.1 - 5.4 64 Bit Single-Core
622 points (27%)
+ 1 benchmarks and specifications   - Hide comparison chart
Geekbench 5.4 - Geekbench 5.1 - 5.4 64 Bit Multi-Core
2226 points (8%)
+ 1 benchmarks and specifications   - Hide comparison chart
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
2763 points (29%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
8087 points (9%)
+ 1 benchmarks and specifications   + Show comparison chart
Antutu v9 - AnTuTu v9 Total Score
419246 Points (30%)
+ 1 benchmarks and specifications   + Show comparison chart
Antutu v9 - AnTuTu v9 CPU
133629 Points (44%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Add one or more devices and compare

In the following list you can select (and also search for) devices that should be added to the comparison. You can select more than one device.

restrict list:

show all (including archived), 2023, 2022
v1.22
log 31. 20:12:17

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Sun, 28 May 2023 13:55:04 +0200 +0.001s ... 0.001s

#3 composed specs +0.047s ... 0.048s

#4 did output specs +0s ... 0.048s

#5 getting avg benchmarks for device 14025 +0.002s ... 0.05s

#6 got single benchmarks 14025 +0.006s ... 0.056s

#7 got avg benchmarks for devices +0s ... 0.056s

#8 min, max, avg, median took s +0.066s ... 0.122s

#9 return log +0.036s ... 0.158s

No reviews found for this CPU (yet).
