Mediatek MT6735

MT6735

The 1.5 GHz MediaTek MT6735 is a 64-bit ARM-based SoC launched in 2014 primarily for small budget to mainstream Android devices. The quad-core processor is manufactured in 28 nm and is based on the Cortex-A53 architecture. It integrates a cat.4 LTE modem with CDMA2000 and an ARM Mali-720 GPU capable of decoding and encoding videos of up to 1080p30. Compared to the MT6732, the MT6735 utilizes a slower graphics unit.

Processor

The Cortex-A53 is the successor to the popular Cortex-A7 design. In addition to the jump from 32-bit to 64-bit architecture (ARMv8 ISA) to address more than 4 GB of memory, the new design offers better branch prediction and higher performance-to-power ratio that rivals the Cortex-A9. The four cores of the MT6732 are clocked at up to 1.5 GHz and sits roughly in between the Qualcomm Snapdragon 610 (4x Cortex-A53 at 1.7 GHz) and Snapdragon 410 (4x Cortex-A53 at 1.2 to 1.4 GHz). The power-efficient processor is fit for common tasks like browsing and running light applications.

Graphics

The integrated single-core Mali-T720 is an entry-level GPU clocked at up to 600 MHz (450 MHz likely). Most Android games will play at acceptable frame rates on medium resolutions and quality.

Features

The MT6732 SoC integrates a memory controller (32-bit LPDDR3, 6.4 GB/s), multiple radios (WLAN, Bluetooth, GPS), and a cellular modem (GSM, UMTS, GPRS, HSPA+, HSUPA, TD-SCDMA, EVDO, and LTE Cat 4). Its integrated video engine allows for 1080p playback at 30 FPS. Cameras are supported up to 13 MP.

Series Mediatek
CodenameCortex-A53
Series: Mediatek Cortex-A53
Mediatek Helio X10 MT6795 compare2.2 GHz8 / 8 Cortex-A53
Mediatek Helio P35 MT6765 compare1.8 - 2.3 GHz8 / 8 Cortex-A53
Mediatek Helio P22T MT8768T compare2.3 GHz8 / 8 Cortex-A53
Mediatek Helio P10 MT6755 compare2 GHz8 / 8 Cortex-A53
Mediatek MT8752 compare1.7 GHz8 / 8 Cortex-A53
Mediatek MT6752 compare1.7 GHz8 / 8 Cortex-A53
Mediatek MT6753 compare1.5 GHz8 / 8 Cortex-A53
Mediatek MT6750S compare1.5 GHz8 / 8 Cortex-A53
Mediatek MT6750N compare1.5 GHz8 / 8 Cortex-A53
Mediatek MT6750 compare1.5 GHz8 / 8 Cortex-A53
Mediatek MT8732 compare1.5 GHz4 / 4 Cortex-A53
Mediatek MT8165 compare1.5 GHz4 / 4 Cortex-A53
Mediatek MT6739 compare1.5 GHz4 / 4 Cortex-A53
Mediatek MT6739WW compare1.5 GHz4 / 4 Cortex-A53
Mediatek MT6732 compare1.5 GHz4 / 4 Cortex-A53
» Mediatek MT67351.5 GHz4 / 4 Cortex-A53
Mediatek MT8735 compare1.3 GHz4 / 4 Cortex-A53
Mediatek MT6737T compare1.5 GHz4 / 4 Cortex-A53
Mediatek MT6737 compare1.25 GHz4 / 4 Cortex-A53
Mediatek MT6735P compare1 GHz4 / 4 Cortex-A53
Mediatek MT6735M compare1 GHz4 / 4 Cortex-A53
Clock Rate1500 MHz
Number of Cores / Threads4 / 4
Manufacturing Technology28 nm
FeaturesRel. 9, Cat. 4 LTE (FDD & TDD), DC-HSPA+, TD-SCDMA, CDMA2000 1x/EVDO Rev. A, EDGE, 802.11n Wi-Fi, Bluetooth 4.0, 13MP image signal-processor,
GPUARM Mali-T720 ( - 600 MHz)
64 Bit64 Bit support
ArchitectureARM
Announcement Date10/15/2014
Product Link (external) Mediatek MT6735

Benchmarks

3DMark - 3DMark Ice Storm Physics
min: 4569     avg: 7272     median: 7266 (5%)     max: 9420 Points
+ 13 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Extreme Physics
min: 4447     avg: 7291     median: 7152 (6%)     max: 9532 Points
+ 13 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Unlimited Physics
min: 6220     avg: 8308     median: 7568 (6%)     max: 10441 Points
+ 25 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Sling Shot Extreme (ES 3.1) Unlimited Physics
min: 840     avg: 852     median: 854 (11%)     max: 862 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Sling Shot (ES 3.0) Unlimited Physics
min: 783     avg: 830     median: 848 (12%)     max: 859 Points
+ 4 benchmarks and specifications   + Show comparison chart
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
min: 482     avg: 519     median: 519 (6%)     max: 556 points
+ 2 benchmarks and specifications   + Show comparison chart
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
min: 1333     avg: 1430     median: 1430 (2%)     max: 1527 points
+ 2 benchmarks and specifications   + Show comparison chart
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
min: 424     avg: 540     median: 560.5 (9%)     max: 602 points
+ 9 benchmarks and specifications   + Show comparison chart
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
min: 1192     avg: 1510     median: 1577 (4%)     max: 1690 points
+ 9 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 1338     avg: 1530     median: 1443.5 (3%)     max: 1807 points
+ 6 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 470     avg: 531     median: 505.5 (10%)     max: 626 points
+ 6 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
min: 1147     avg: 1612     median: 1569 (2%)     max: 2533 points
+ 11 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 64 Bit Single-Core
min: 404     avg: 541     median: 532 (9%)     max: 626 points
+ 11 benchmarks and specifications   + Show comparison chart
Linpack Android / IOS - Linpack Multi Thread
min: 24.63     avg: 163.9     median: 211 (7%)     max: 237.6 MFLOPS
+ 5 benchmarks and specifications   + Show comparison chart
Linpack Android / IOS - Linpack Single Thread
min: 7.181     avg: 68.5     median: 77.3 (8%)     max: 112.8 MFLOPS
+ 5 benchmarks and specifications   + Show comparison chart
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 12505     avg: 17109     median: 16585 (19%)     max: 32901 ms
+ 26 benchmarks and specifications   + Show comparison chart
Sunspider - Sunspider 1.0 Total Score *
min: 1561     avg: 1871     median: 1750 (19%)     max: 2604 ms
+ 9 benchmarks and specifications   + Show comparison chart
Sunspider - Sunspider 0.9.1 Total Score *
min: 1477     avg: 1812     median: 1843.5 (17%)     max: 2085 ms
+ 4 benchmarks and specifications   + Show comparison chart
Octane V2 - Octane V2 Total Score
min: 1910     avg: 2564     median: 2657 (3%)     max: 3246 Points
+ 26 benchmarks and specifications   + Show comparison chart
Vellamo 3.x - Vellamo 3.x Metal
min: 705     avg: 999     median: 881 (24%)     max: 1529 Points
+ 4 benchmarks and specifications   + Show comparison chart
Vellamo 3.x - Vellamo 3.x Multicore Beta
min: 1023     avg: 1199     median: 1216.5 (27%)     max: 1339 Points
+ 4 benchmarks and specifications   + Show comparison chart
Vellamo 3.x - Vellamo 3.x Browser
min: 1515     avg: 2052     median: 1968.5 (26%)     max: 2755 Points
+ 4 benchmarks and specifications   + Show comparison chart
Quadrant Standard Edition 2.0 - Quadrant Standard 2.0 Total Score
min: 9063     avg: 11768     median: 9368 (22%)     max: 19273 points
+ 4 benchmarks and specifications   + Show comparison chart
AnTuTu v5 - AnTuTu v5 Total Score
min: 19740     avg: 24574     median: 24428 (25%)     max: 31538 Points
+ 7 benchmarks and specifications   + Show comparison chart
AnTuTu v6 - AnTuTu v6 Total Score
min: 22998     avg: 27495     median: 25415 (9%)     max: 33786 Points
+ 20 benchmarks and specifications   + Show comparison chart
PassMark PerformanceTest Mobile V1 - PerformanceTest Mobile CPU Tests
min: 9848     avg: 38620     median: 34641 (5%)     max: 101503 Points
+ 5 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Computer Vision
1403 Points (7%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Storage
1970 Points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Work Score 2.0
min: 2324     avg: 2555     median: 2554.5 (17%)     max: 2785 Points
+ 2 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Work Score
min: 1908     avg: 3109     median: 3010 (15%)     max: 3856 Points
+ 20 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
