Mediatek MT8176

 MT8176

The Mediatek MT8176 is an upper mainstream ARM SoC (System on a chip) that was introduced in October 2016 and is primarily used for Android based tablets. It has two fast Cortex-A72 CPU cores running at up to 2.1 GHz and four Cortex-A53 cores for power-saving in a big.LITTLE configuration. The graphics unit is based on the IMG Series 6XT (Rogue) and has the designation PowerVR GX6250 clocked at 600 MHz. Among others, the GPU includes a video decoder with 4K and H.265 support (not verified, but was already the case for the older MT8173).

Processor

The biggest highlight of the SoC are the new Cortex-A72 cores, which can be seen as the successors to the Cortex-A57 design. ARM promises much more performance in combination with reduced power consumption, which results in an excellent per-thread performance with the very high maximum clock of 2.4 GHz. The architecture is based on ARMv8-ISA and therefore supports 64-bit.

The four slower, but therefore very frugal Cortex-A53 cores (clocks unknown, probably around 1.4 GHz) are supposed to reduce the power consumption and are always active with light workloads. The big.LITTLE configuration also allows the simultaneous use of all six cores (or any combination of cores from both clusters), so the MT8173 can be called a real hexa-core.

Graphics

The graphics unit is based on Series 6XT (Rogue) from IMG and has the designation PowerVR GX6250. The 2-cluster chip has a unified-shader architecture with a total of 64 FP32 ALUs as well as 4 TMUs. Compared to the MT8173, the clocks were reduced from 700 to 600 MHz, so the gaming performance is a bit lower. High-resolution screens and complex Android games should be powered without bigger problems.

Series Mediatek
CodenameCortex-A72/-A53

Series: Mediatek Cortex-A72/-A53

Mediatek MT8176 « 2.1 GHz6 / 6 cores Cortex-A72/-A53
Mediatek MT8173 compare2.4 GHz4 / 4 cores Cortex-A72/-A53
Mediatek MT8173C compare2.1 GHz4 / 4 cores Cortex-A72/-A53
Clock Rate2100 MHz
Number of Cores / Threads6 / 6
Manufacturing Technology28 nm
Features20 MP Camera ISP, 4K Video Encoder, H.265, PowerVR GX6250 GPU
GPUPowerVR GX6250 (600 MHz)
64 Bit64 Bit support
ArchitectureARM
Announcement Date08/09/2016
Product Link (external)www.mediatek.com
