Mediatek Helio P25

The Mediatek Helio P25 is an upper mainstream ARM SoC for smartphones (mainly Android based) that was introduced in 2017. It is manufactured in a 16 nm FinFET+ process and is equipped with 8 ARM Cortex-A53 CPU cores. The cores are divided in two clusters, a performance cluster clocked at up to 2.6 GHz and a power efficiency cluster clocked at up to 1.6 GHz. The chip also includes an LTE modem (Cat. 6).

The integrated ARM Mali T880 MP2  GPU is clocked at up to 1000 MHz and has two cluster (from 16) from the Midgard (4th Gen) architecture.

Series	Mediatek Mediatek Helio 20
Codename	Cortex-A53
Series: Mediatek Helio 20 Cortex-A53 Mediatek Helio P25 « 2.6 GHz 8 / 8  Cortex-A53 Mediatek Helio A25 1.8 GHz 8 / 8  Cortex-A53 Mediatek Helio P23 MT6763T 2.3 - 2.5 GHz 8 / 8  Cortex-A53 Mediatek Helio P23 MT6763V 2 GHz 8 / 8  Cortex-A53 Mediatek Helio P20 (LP4) MT6757 2.3 GHz 8 / 8  Cortex-A53 Mediatek Helio P22 MT6762 2 GHz 8 / 8  Cortex-A53 Mediatek Helio A22 MT6762M 2 GHz 4 / 4  Cortex-A53 Mediatek Helio A22 MT6761 2 GHz 4 / 4  Cortex-A53 Mediatek Helio A20 MT6761D 1.8 GHz 4 / 4  Cortex-A53
Clock Rate	2600 MHz
Number of Cores / Threads	8 / 8
Manufacturing Technology	16 nm
Features	Carrier Aggregation (CA), CDMA2000 1x/EVDO Rev. A (SRLTE), FDD / TDD LTE Cat-6, LTE TDD 64QAM UL, WiFi a/b/g/n/ac, Bluetooth, FM Radio, GNSS: GPS, Glonass, Beidou, Galileo, Camera ISP 24MP, eMMC 5.1, LPDDR4(X) up to 1600MHz
GPU	ARM Mali-T880 MP2 (1000 MHz)
64 Bit	64 Bit support
Architecture	ARM
Announcement Date	02/08/2016
Product Link (external)	Mediatek Mediatek Helio 20 Helio P25

Benchmarks
