NVIDIA GeForce GTX 1080 Ti (Desktop) vs NVIDIA GeForce GTX 1070 Ti (Desktop)

NVIDIA GeForce GTX 1080 Ti (Desktop)

► remove NVIDIA GeForce GTX 1080 Ti

The Nvidia GeForce GTX 1080 Ti is the fastest desktop consumer graphics card (beginning 2017). It is based on the same GP107 chip as the Titan X but with slightly higher clock speeds and a different memory configuration. It offers one memory controller less (and 11 instead of 12 GB), but the GDDR5X memory is faster clocked (11 GHz) leading to a comparable memory bandwidth. Due to the higher boost clock, the 1080Ti should be around 5 % faster compared to the Pascal Titan X and about 35 % faster compared to the GTX 1080. The TDP is equal to the Titan X with 250 Watt. A new cooler of the Founders Edition should be more efficient and quieter.

NVIDIA GeForce GTX 1070 Ti (Desktop)

► remove NVIDIA GeForce GTX 1070 Ti (Desktop)

The Nvidia GeForce GTX 1070 Ti is the second fastest Pascal based graphics card in November 2017. It is a high-end desktop graphics card based on a cut down GP104 chip as the GTX 1080 and manufactured in 16 nm FinFET at TSMC. Compared to the GTX 1080, it uses the more available GDDR5 graphics memory, and compared to the GTX 1070 it offers more shaders (2432 versus 1920). More details on the Pascal architecture including all features and comparisons to Maxwell, can be found here.

The performance of the GTX 1070 Ti was in our tests right between the GTX 1070 and GTX 1080. However, the powerefficiency was worse than the GTX 1070 and near the GTX 1080. Nvidia also specifies the 1070 Ti and 1080 at 180W.

NVIDIA GeForce GTX 1080 Ti (Desktop)NVIDIA GeForce GTX 1070 Ti (Desktop)
ManufacturerNVIDIANVIDIA
GeForce GTX 1000 Series
GeForce GTX 1080 Ti 3584 @ 1.48 - 1.6 GHz352 Bit @ 11000 MHz
GeForce GTX 1080 SLI (Laptop) compare 5120 @ 1.56 - 1.73 GHz256 Bit @ 10000 MHz
GeForce GTX 1070 SLI (Desktop) compare 3840 @ 1.51 - 1.68 GHz256 Bit @ 8000 MHz
GeForce GTX 1070 SLI (Laptop) compare 4096 @ 1.44 - 1.65 GHz256 Bit @ 8000 MHz
GeForce GTX 1080 (Desktop) compare 2560 @ 1.61 - 1.73 GHz256 Bit @ 10000 MHz
GeForce GTX 1080 Mobile compare 2560 @ 1.57 - 1.73 GHz256 Bit @ 10000 MHz
GeForce GTX 1070 Ti (Desktop) 2432 @ 1.61 - 1.68 GHz256 Bit @ 8000 MHz
GeForce GTX 1070 (Desktop) compare 1920 @ 1.51 - 1.68 GHz256 Bit @ 8000 MHz
GeForce GTX 1080 Max-Q compare 2560 @ 1.1 - 1.28 GHz256 Bit @ 10000 MHz
GeForce GTX 1070 Mobile compare 2048 @ 1.44 - 1.65 GHz256 Bit @ 8000 MHz
GeForce GTX 1070 Max-Q compare 2048 @ 1.1 - 1.27 GHz256 Bit @ 8000 MHz
GeForce GTX 1060 (Desktop) compare 1280 @ 1.51 - 1.71 GHz192 Bit @ 8000 MHz
GeForce GTX 1060 Mobile compare 1280 @ 1.4 - 1.67 GHz192 Bit @ 8000 MHz
GeForce GTX 1060 Max-Q compare 1280 @ 1.06 - 1.34 GHz192 Bit @ 8000 MHz
GeForce GTX 1050 Ti Mobile compare 768 @ 1.49 - 1.62 GHz128 Bit @ 7000 MHz
GeForce GTX 1050 Ti (Desktop) compare 768 @ 1.29 - 1.39 GHz128 Bit @ 7008 MHz
GeForce GTX 1050 Ti Max-Q compare 768 @ 1.15 - 1.29 GHz128 Bit @ 7000 MHz
GeForce GTX 1050 (Desktop) compare 640 @ 1.35 - 1.46 GHz128 Bit @ 7008 MHz
GeForce GTX 1050 Mobile compare 640 @ 1.35 - 1.49 GHz128 Bit @ 7000 MHz
GeForce GTX 1050 Max-Q compare 640 @ 1 - 1.14 GHz128 Bit @ 7000 MHz
GeForce GT 1030 (Desktop) compare 384 @ 1.23 - 1.67 GHz64 Bit @ 6000 MHz
GeForce GTX 1080 Ti 3584 @ 1.48 - 1.6 GHz352 Bit @ 11000 MHz
GeForce GTX 1080 SLI (Laptop) compare 5120 @ 1.56 - 1.73 GHz256 Bit @ 10000 MHz
GeForce GTX 1070 SLI (Desktop) compare 3840 @ 1.51 - 1.68 GHz256 Bit @ 8000 MHz
GeForce GTX 1070 SLI (Laptop) compare 4096 @ 1.44 - 1.65 GHz256 Bit @ 8000 MHz
GeForce GTX 1080 (Desktop) compare 2560 @ 1.61 - 1.73 GHz256 Bit @ 10000 MHz
GeForce GTX 1080 Mobile compare 2560 @ 1.57 - 1.73 GHz256 Bit @ 10000 MHz
GeForce GTX 1070 Ti (Desktop) 2432 @ 1.61 - 1.68 GHz256 Bit @ 8000 MHz
GeForce GTX 1070 (Desktop) compare 1920 @ 1.51 - 1.68 GHz256 Bit @ 8000 MHz
GeForce GTX 1080 Max-Q compare 2560 @ 1.1 - 1.28 GHz256 Bit @ 10000 MHz
GeForce GTX 1070 Mobile compare 2048 @ 1.44 - 1.65 GHz256 Bit @ 8000 MHz
GeForce GTX 1070 Max-Q compare 2048 @ 1.1 - 1.27 GHz256 Bit @ 8000 MHz
GeForce GTX 1060 (Desktop) compare 1280 @ 1.51 - 1.71 GHz192 Bit @ 8000 MHz
GeForce GTX 1060 Mobile compare 1280 @ 1.4 - 1.67 GHz192 Bit @ 8000 MHz
GeForce GTX 1060 Max-Q compare 1280 @ 1.06 - 1.34 GHz192 Bit @ 8000 MHz
GeForce GTX 1050 Ti Mobile compare 768 @ 1.49 - 1.62 GHz128 Bit @ 7000 MHz
GeForce GTX 1050 Ti (Desktop) compare 768 @ 1.29 - 1.39 GHz128 Bit @ 7008 MHz
GeForce GTX 1050 Ti Max-Q compare 768 @ 1.15 - 1.29 GHz128 Bit @ 7000 MHz
GeForce GTX 1050 (Desktop) compare 640 @ 1.35 - 1.46 GHz128 Bit @ 7008 MHz
GeForce GTX 1050 Mobile compare 640 @ 1.35 - 1.49 GHz128 Bit @ 7000 MHz
GeForce GTX 1050 Max-Q compare 640 @ 1 - 1.14 GHz128 Bit @ 7000 MHz
GeForce GT 1030 (Desktop) compare 384 @ 1.23 - 1.67 GHz64 Bit @ 6000 MHz
CodenameGP102Pascal GP104
ArchitecturePascalPascal
Cores3584 - unified2432 - unified
Core1481 - 1600 (Boost) MHz1607 - 1683 (Boost) MHz
Memory11000 MHz8000 MHz
Bus352 Bit256 Bit
MemoryGDDR5XGDDR5
Max. Memory11264 MB8192 MB
Shared Memorynono
DirectXDirectX 12_1DirectX 12_1
Transistors12000 Million7200 Million
Technology16 nm16 nm
FeaturesDP 1.4, HDMI 2.0b, HDCP 2.2, CUDA, PCIe 3.0, GPU Boost 3.0, G-SYNCMulti-Projection, VR Ready, G-SYNC, Vulkan, Multi Monitor
Introduced28.02.2017 02.11.2017
Manufacturerhttps://www.nvidia.at/graphics-cards/gef...

3DMark - 3DMark Time Spy Score
min: 6978     avg: 8628     median: 8684.5 (50%)     max: 9806 Points
6177 Points (35%)
3DMark - 3DMark Time Spy Graphics
min: 9024     avg: 9372     median: 9401 (50%)     max: 9608 Points
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 350317     avg: 408298     median: 394694 (62%)     max: 493486 Points
442105 Points (70%)
3DMark - 3DMark Cloud Gate Score
min: 28990     avg: 41126     median: 43370.5 (58%)     max: 49475 Points
29364 Points (39%)
3DMark - 3DMark Cloud Gate Graphics
min: 105276     avg: 136458     median: 142490 (70%)     max: 157012 Points
88161 Points (43%)
3DMark - 3DMark Fire Strike Standard Score
min: 14936     avg: 19343     median: 19615.5 (59%)     max: 22823 Points
15061 Points (45%)
3DMark - 3DMark Fire Strike Standard Graphics
min: 25771     avg: 27531     median: 27564 (64%)     max: 28476 Points
18405 Points (42%)
3DMark 11 - 3DM11 Performance Score
min: 16074     avg: 24293     median: 24935 (64%)     max: 29827 Points
20106 Points (52%)
3DMark 11 - 3DM11 Performance GPU
min: 34761     avg: 37470     median: 37671.5 (64%)     max: 39241 Points
27503 Points (47%)
3DMark 06 3DMark 06 - Standard 1280x1024 + NVIDIA GeForce GTX 1080 Ti (Desktop)
3DMark 06 - Standard 1280x1024 + NVIDIA GeForce GTX 1070 Ti (Desktop)
Unigine Valley 1.0 - Unigine Valley 1.0 DX
min: 88.8     avg: 117     median: 114.5 (62%)     max: 144 fps
SPECviewperf 12
specvp12 sw-03 + NVIDIA GeForce GTX 1080 Ti (Desktop)
specvp12 snx-02 + NVIDIA GeForce GTX 1080 Ti (Desktop)
specvp12 showcase-01 + NVIDIA GeForce GTX 1080 Ti (Desktop)
specvp12 mediacal-01 + NVIDIA GeForce GTX 1080 Ti (Desktop)
specvp12 maya-04 + NVIDIA GeForce GTX 1080 Ti (Desktop)
specvp12 energy-01 + NVIDIA GeForce GTX 1080 Ti (Desktop)
specvp12 creo-01 + NVIDIA GeForce GTX 1080 Ti (Desktop)
specvp12 catia-04 + NVIDIA GeForce GTX 1080 Ti (Desktop)
specvp12 3dsmax-05 + NVIDIA GeForce GTX 1080 Ti (Desktop)
Cinebench R10 Cinebench R10 Shading (32bit) + NVIDIA GeForce GTX 1080 Ti (Desktop)
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit + NVIDIA GeForce GTX 1080 Ti (Desktop)
Cinebench R15
Cinebench R15 OpenGL 64 Bit + NVIDIA GeForce GTX 1080 Ti (Desktop)
Cinebench R15 OpenGL Ref. Match 64 Bit + NVIDIA GeForce GTX 1080 Ti (Desktop)
GFXBench (DX / GLBenchmark) 2.7
GLBench 2.7 T-Rex HD Offscreen C24Z16 + NVIDIA GeForce GTX 1080 Ti (Desktop)
GLBench 2.7 T-Rex HD Onscreen C24Z16 + NVIDIA GeForce GTX 1080 Ti (Desktop)
GFXBench 3.0 - GFXBench 3.0 Manhattan Offscreen
min: 399     avg: 476     median: 475.5 (52%)     max: 552 fps
GFXBench 3.0 - GFXBench 3.0 Manhattan
min: 59.9     avg: 60     median: 60 (16%)     max: 60 fps
GFXBench - GFXBench Car Chase Offscreen
min: 352     avg: 373     median: 373 (86%)     max: 394 fps
GFXBench - GFXBench Car Chase Onscreen
59.9 fps (23%)
Basemark GPU 1.2 - Basemark GPU 1.2 Vulkan Official Medium Offscreen 1080
1135 fps (95%)
Basemark GPU 1.2 - Basemark GPU 1.2 Vulkan Official High Offscreen 2160
102 fps (25%)
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
min: 3050     avg: 3055     median: 3054.5 (31%)     max: 3059 Samples/s
2542 Samples/s (26%)
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
min: 6583     avg: 6592     median: 6591.5 (45%)     max: 6600 Samples/s
5159 Samples/s (35%)
ComputeMark v2.1 - ComputeMark v2.1 Result
min: 21646     avg: 21948     median: 21948 (49%)     max: 22250
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
min: 319     avg: 348     median: 344.5 (68%)     max: 378 Watt
Power Consumption - The Witcher 3 Power Consumption - external Monitor *
min: 339     avg: 356     median: 355 (70%)     max: 373 Watt
Clock Speed - GPU Clock Witcher 3 ultra
min: 1780     avg: 1784     median: 1783.5 (93%)     max: 1787 MHz
Clock Speed - GPU Clock Speed Furmark
min: 1480     avg: 1506     median: 1500 (86%)     max: 1538 MHz

Average Benchmarks NVIDIA GeForce GTX 1080 Ti (Desktop) → 100% n=15

Average Benchmarks NVIDIA GeForce GTX 1070 Ti (Desktop) → 82% n=15

-
-
* Smaller numbers mean a higher performance
1 This benchmark is not used for the average calculation

low 1280x720
100%
GeForce GTX 1080 Ti:
75.9  fps
med. 1920x1080
100%
GeForce GTX 1080 Ti:
69.1  fps
high 1920x1080
100%
GeForce GTX 1080 Ti:
54  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
43.1  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
34.7  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
21.2  fps
F1 2020

F1 2020

2020
low 1280x720
100%
GeForce GTX 1080 Ti:
248  fps
med. 1920x1080
100%
GeForce GTX 1080 Ti:
213  fps
high 1920x1080
100%
GeForce GTX 1080 Ti:
207  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
153  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
118  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
71.9  fps
low 1280x720
100%
GeForce GTX 1080 Ti:
253  fps
med. 1920x1080
100%
GeForce GTX 1080 Ti:
204  fps
high 1920x1080
100%
GeForce GTX 1080 Ti:
137  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
119  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
88.6   fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
51.9   fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
179  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
131  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
67.6  fps
high 1920x1080
100%
GeForce GTX 1080 Ti:
123  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
79.7  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
37.5  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
116  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
107  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
52.8  fps
high 1920x1080
100%
GeForce GTX 1080 Ti:
79  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
50.7 50.9 ~ 51 fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
40.9  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
26.5  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
121  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
98  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
49.4  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
97  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
80  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
47.4  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
122  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
91  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
51.7  fps
GRID 2019

GRID 2019

2019
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
94  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
78  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
52.8  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
81  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
62  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
37  fps
FIFA 20

FIFA 20

2019
4K 3840x2160
100%
GeForce GTX 1080 Ti:
173  fps
low 1280x720
100%
GeForce GTX 1080 Ti:
145  fps
med. 1920x1080
100%
GeForce GTX 1080 Ti:
128  fps
high 1920x1080
100%
GeForce GTX 1080 Ti:
103  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
85.4  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
61.7  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
34.1  fps
Control

Control

2019
low 1280x720
100%
GeForce GTX 1080 Ti:
233  fps
86%
GeForce GTX 1070 Ti (Desktop):
200  fps
med. 1920x1080
100%
GeForce GTX 1080 Ti:
107  fps
73%
GeForce GTX 1070 Ti (Desktop):
78  fps
high 1920x1080
100%
GeForce GTX 1080 Ti:
82  fps
71%
GeForce GTX 1070 Ti (Desktop):
58.5  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
53.2  fps
70%
GeForce GTX 1070 Ti (Desktop):
37.1  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
25.8  fps
69%
GeForce GTX 1070 Ti (Desktop):
17.9  fps
F1 2019

F1 2019

2019
low 1280x720
GeForce GTX 1070 Ti (Desktop):
244  fps
med. 1920x1080
GeForce GTX 1070 Ti (Desktop):
183  fps
high 1920x1080
GeForce GTX 1070 Ti (Desktop):
164  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
125  fps
96%
GeForce GTX 1070 Ti (Desktop):
120  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
122  fps
77%
GeForce GTX 1070 Ti (Desktop):
94  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
71  fps
80%
GeForce GTX 1070 Ti (Desktop):
57  fps
low 1280x720
GeForce GTX 1070 Ti (Desktop):
271  fps
med. 1920x1080
GeForce GTX 1070 Ti (Desktop):
249  fps
high 1920x1080
GeForce GTX 1070 Ti (Desktop):
241  fps
ultra 1920x1080
GeForce GTX 1070 Ti (Desktop):
219  fps
QHD 2560x1440
GeForce GTX 1070 Ti (Desktop):
222  fps
4K 3840x2160
GeForce GTX 1070 Ti (Desktop):
221  fps
low 1280x720
100%
GeForce GTX 1080 Ti:
249 318 ~ 284 fps
med. 1920x1080
100%
GeForce GTX 1080 Ti:
151  fps
high 1920x1080
100%
GeForce GTX 1080 Ti:
109  fps
79%
GeForce GTX 1070 Ti (Desktop):
86.6  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
82.8 85.4 ~ 84 fps
75%
GeForce GTX 1070 Ti (Desktop):
63.4  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
59  fps
70%
GeForce GTX 1070 Ti (Desktop):
41.2  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
30.6  fps
66%
GeForce GTX 1070 Ti (Desktop):
20.3  fps
Rage 2

Rage 2

2019
low 1280x720
100%
GeForce GTX 1080 Ti:
265  fps
med. 1920x1080
100%
GeForce GTX 1080 Ti:
142  fps
high 1920x1080
100%
GeForce GTX 1080 Ti:
124  fps
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
121  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
80  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
38.9  fps
Anno 1800

Anno 1800

2019
ultra 1920x1080
100%
GeForce GTX 1080 Ti:
50.9  fps
90%
GeForce GTX 1070 Ti (Desktop):
46  fps
QHD 2560x1440
100%
GeForce GTX 1080 Ti:
46.6  fps
87%
GeForce GTX 1070 Ti (Desktop):
40.4  fps
4K 3840x2160
100%
GeForce GTX 1080 Ti:
37.7  fps
64%
GeForce GTX 1070 Ti (Desktop):
24.1  fps
low 1280x720
100%
GeForce GTX 1080 Ti:
197 fps  fps
med. 1920x1080
100%
GeForce GTX 1080 Ti:
154 fps
