Intel Core i5-3360M

Intel 3360M

The Intel Core i5-3360M is a fast dual-core processor for laptops based on the Ivy Bridge architecture. Due to Hyperthreading, the two cores can handle up to four threads in parallel leading to better utilization of the CPU. Each core offers a base speed of 2.8 GHz but can dynamically increase clock rates with Turbo Boost up to 3.3 GHz (for 2 active cores) and 3.5 GHz (for 1 active core). As its Sandy-Bridge-based predecessor Core i5-2540M, it offers a 3 MB L3-Cache.

Ivy Bridge is an enhanced die shrink of the Sandy Bridge architecture with improvements on both GPU and CPU performance. The CPUs are produced in 22nm (versus 32nm Sandy Bridge CPUs) and are the first to introduce 3D transistors for increased energy efficiency when compared to similarly clocked Sandy Bridge processors. Other new features are integrated PCI Express 3.0 and  DDR3(L)-1600 support.

The performance of the Core i5-3360M is slightly above a similarly clocked Sandy Bridge processor due to the architectural improvements. As a result, overall performance is about 5 % above the old i7-2640M.

The integrated Intel HD Graphics 4000 offers 16 Execution Units (EUs) clocked at 650 MHz up to 1200 MHz with Turbo Boost, making it one of the faster variants.

Just like most other Ivy Bridge dual-cores, the i5-3360M is rated at a TDP of 35 W. Therefore, even smaller laptops can use the Core i5.

SeriesIntel Core i5
CodenameIvy Bridge
Clock Rate2800 - 3500 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache3072 KB
Number of Cores / Threads2 / 4
Max. Power Consumption (TDP = Thermal Design Power)35 Watt
Manufacturing Technology22 nm
FeaturesHD Graphics 4000 (650-1200MHz), DDR3-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1200 MHz)
64 Bit64 Bit support
Hardware VirtualizationVT-x, VT-d
Starting Price $266 U.S.
Announcement Date06/03/2012
Product Link (external)Intel Core i5 3360M

CPU Benchmarks

3DMark (2013): Fire Strike Standard Physics 1920x1080
0% 100%
min: 3903     avg: 4331.5 (25.41%)     max: 4650 Points
3DMark (2013): Cloud Gate Standard Physics 1280x720
0% 100%
min: 2789     avg: 3023.5 (7.26%)     max: 3288 Points
3DMark (2013): Ice Storm Standard Physics 1280x720
0% 100%
min: 24772     avg: 32399.3 (59.84%)     max: 36552 Points
TrueCrypt: Serpent Mean 100MB
0% 100%
min: 0.14     avg: 0.2 (8.61%)     max: 0.172 GB/s
TrueCrypt: Twofish Mean 100MB
0% 100%
min: 0.24     avg: 0.3 (16.09%)     max: 0.294 GB/s
TrueCrypt: AES Mean 100MB
0% 100%
min: 1.3     avg: 1.6 (17.34%)     max: 1.6 GB/s
X264 HD Benchmark 4.0: Pass 2
0% 100%
min: 4.07     avg: 9.8 (9.45%)     max: 18.68 fps
X264 HD Benchmark 4.0: Pass 1
0% 100%
min: 32.52     avg: 55.2 (27.51%)     max: 97.725 fps
WinRAR: Result
0% 100%
min: 2630     avg: 3140.6 (43.2%)     max: 3524 KB/s
wPrime 2.0x: 1024m
0% 100%
min: 467.562     avg: 495.4 (95.61%)     max: 517.624 seconds*
wPrime 2.0x: 32m
0% 100%
min: 14.773     avg: 16.7 (97.53%)     max: 19.125 seconds*
3DMark 11: Performance Physics 1280x720
0% 100%
min: 3251     avg: 3874.8 (29.32%)     max: 4292 points
3DMark Vantage: P CPU no PhysX 1280x1024
0% 100%
min: 10382     avg: 10794.1 (26.99%)     max: 11280 Points
3DMark 06 - CPU:
0% 100%
min: 3848     avg: 3974.5 (43.65%)     max: 4041 Points
Cinebench R11.5: CPU Single 64Bit
0% 100%
min: 1.29     avg: 1.4 (73.51%)     max: 1.43 Points
Cinebench R11.5: CPU Multi 64Bit
0% 100%
min: 3.2     avg: 3.3 (17.49%)     max: 3.3 Points
Cinebench R10: Rendering Single CPUs 64Bit
0% 100%
min: 5740     avg: 5903.5 (23.76%)     max: 6027 Points
Cinebench R10: Rendering Multiple CPUs 64Bit
0% 100%
min: 12217     avg: 12404.7 (33.05%)     max: 12624 Points
Cinebench R10: Rendering Single 32Bit
0% 100%
min: 4303     avg: 4651.3 (69.17%)     max: 4765 Points
Cinebench R10: Rendering Multiple CPUs 32Bit
0% 100%
min: 9887     avg: 10110.6 (29.07%)     max: 10191 Points
Super Pi mod 1.5 XS 1M:
0% 100%
min: 11     avg: 11.4 (99.47%)     max: 13.135 Seconds*
Super Pi mod 1.5 XS 2M:
0% 100%
min: 25     avg: 26 (99.78%)     max: 27.362 Seconds*
Super Pi Mod 1.5 XS 32M:
0% 100%
min: 583     avg: 599.5 (97.39%)     max: 625.795 Seconds*
SiSoft Sandra Dhrystone (MIPS):
0% 100%
min: 54510     avg: 61935 (29.39%)     max: 66000 MIPS
SiSoft Sandra Whetstone (MFLOPS):
0% 100%
min: 40000     avg: 40882.5 (31.36%)     max: 41740 MFLOPS
Windows 7 Experience Index: Processor
0% 100%
min: 7     avg: 7.2 (90.12%)     max: 7.2 points
