Intel Core i5-2537M

Intel 2537M

The Intel Core i5-2537M is power efficient ULV (Ultra Low Voltage) processor for thin and light laptops. The base frequency of 1.4 GHz is relatively low, but due to Turbo Boost 2.0, the CPU may clock up to 2.3 GHz (one core loaded, 2GHz with both cores loaded). However, this is depending on the cooling and power consumption of the laptop. Due to HyperThreading, the i5-2537M is able to handle 4 threads in parallel.

Sandy Bridge is the evolutionary successor of the Arrandale architecture. The most noteable improvements is the improved Turbo 2.0 and the integration of the graphics card into the 32nm CPU core.

The integrated Intel HD Graphics 3000 clocked at 350 or 900MHz (Turbo Boost). Due to the slower clock rate, compared to other HD Graphics 3000 (usually 650-1100/1300MHz in non LV processors), the performance should be noticeable lower.

The performance of the CPU should be a bit higher than a similar clocked Arrandale Core i5. Therefore, the performance should be similar to a Core i7-680UM / Core i3-330M.

The TDP of 17W (includes the integrated GPU and memory controller) allows the use of the 2537M CPU in small subnotebooks.

SeriesIntel Core i5
CodenameSandy Bridge
Clock Rate1400 - 2300 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache3072 KB
Number of Cores / Threads2 / 4
Max. Power Consumption (TDP = Thermal Design Power)17 Watt
Transistor Count624 Million
Manufacturing Technology32 nm
Die Size149 mm2
Max. Temperature100 °C
SocketBGA1023
FeaturesHD Graphics 3000 (350-900MHz), DDR3-1066/1333 Memory Controller (max 8GB), HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 3000 (350 - 900 MHz)
64 Bit64 Bit support
Hardware VirtualizationVT-x, VT-d
Starting Price $250 U.S.
Announcement Date01/03/2011
Product Link (external)Intel Core i5 2537M

Benchmarks

wPrime 2.0x - 1024m
0% 100%
min: 791.7      avg: 974.9 (12%)     median: 974.9 (12%)     max: 1158 seconds
wPrime 2.0x - 32m
0% 100%
min: 24.8      avg: 24.9 (5%)     median: 24.9 (5%)     max: 25 seconds
3DMark 11 - Performance Physics 1280x720
0% 100%
min: 2803      avg: 2803 (21%)     median: 2803 (21%)     max: 2803 points
3DMark Vantage - P CPU no PhysX 1280x1024
0% 100%
min: 20010      avg: 20010 (50%)     median: 20010 (50%)     max: 20010 Points
3DMark 06 - CPU -
0% 100%
min: 1696      avg: 2182.3 (25%)     median: 2400 (27%)     max: 2451 Points
Cinebench R11.5 - CPU Single 64Bit
0% 100%
min: 0.9      avg: 0.9 (45%)     median: 0.9 (45%)     max: 0.9 Points
Cinebench R11.5 - CPU Multi 64Bit
0% 100%
min: 1.41      avg: 1.7 (9%)     median: 1.7 (9%)     max: 1.93 Points
Cinebench R10 - Rendering Single CPUs 64Bit
0% 100%
min: 3577      avg: 3608.5 (42%)     median: 3608.5 (42%)     max: 3640 Points
Cinebench R10 - Rendering Multiple CPUs 64Bit
0% 100%
min: 5127      avg: 6200.5 (17%)     median: 6200.5 (17%)     max: 7274 Points
Cinebench R10 - Rendering Single 32Bit
0% 100%
min: 2808      avg: 2814 (42%)     median: 2814 (42%)     max: 2820 Points
Cinebench R10 - Rendering Multiple CPUs 32Bit
0% 100%
min: 4157      avg: 5329.7 (15%)     median: 5903 (17%)     max: 5929 Points
Super Pi mod 1.5 XS 1M -
0% 100%
min: 17      avg: 17.2 (4%)     median: 17.2 (4%)     max: 17.331 Seconds
Super Pi Mod 1.5 XS 32M -
0% 100%
min: 993      avg: 993 (0%)     median: 993 (0%)     max: 993 Seconds
SiSoft Sandra Whetstone (MFLOPS) -
0% 100%
min: 23500      avg: 23500 (18%)     median: 23500 (18%)     max: 23500 MFLOPS
Windows 7 Experience Index - Processor
0% 100%
min: 3.4      avg: 5 (65%)     median: 5.4 (69%)     max: 6.3 points
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
