Intel Pentium G860

Intel G860

The Intel Pentium G860 is a low-end dual-core desktop processor based on the Sandy Bridge architecture. Compared to the more expensive Core i3, Core i5 and Core i7 CPUs, many features are disabled including Turbo Boost, Hyper-Threading, AVX and AES. Each core offers a base speed of 3.0 GHz.

Sandy Bridge is the evolutionary successor of the Arrandale/Clarkdale architecture. The most noteable improvements are the new 256 Bit AVX instructions, the improved Turbo 2.0 (both features not supported by the G860) and the integration of the graphics card into the 32nm CPU core.

The performance of the Pentium G860 is slightly above that of a similarly clocked Clarkdale processor due to some architectural improvements. Compared to AMD's Trinity Desktop APUs, the Pentium G860 offers higher raw performance than the A6-5400K, but is still below the A8-5600K and A10-5800K.

The integrated Intel HD Graphics (Sandy Bridge) offers 6 Execution Units (EUs) clocked at 650 MHz up to 1100 MHz with Turbo Boost. The very low performance is only sufficient for older and less demanding games.

The total power consumption of the CPU, graphics and memory controller is specified by Intel at 77 watts (TDP).

SeriesIntel Pentium (Desktop)
CodenameSandy Bridge
Clock Rate3000 MHz
Level 1 Cache128 KB
Level 2 Cache256 KB
Level 3 Cache3 MB
Number of Cores / Threads2 / 2
Power Consumption (TDP = Thermal Design Power)65 Watt
Transistor Count504 Million
Manufacturing Technology32 nm
Max. Temperature69.1 °C
SocketFCLGA1155
FeaturesDual-Channel DDR3-1333 Memory Controller (32 GB), Intel HD Graphics
GPUIntel HD Graphics (Sandy Bridge) (650 - 1100 MHz)
64 Bit64 Bit support
Architecturex86
Starting Price$75 U.S.
Announcement Date09/15/2011
Product Link (external)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
2.3 Points (3%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.2 Points (30%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
3964 points (24%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
7695 points (6%)
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
9063 Points (6%)
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
4953 Points (6%)
wPrime 2.10 - wPrime 2.0 1024m *
752 s (9%)
wPrime 2.10 - wPrime 2.0 32m *
23.6 s (5%)
X264 HD Benchmark 4.0 - x264 Pass 2
12.7 fps (4%)
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (3%)
TrueCrypt - TrueCrypt Twofish
0.2 GB/s (3%)
TrueCrypt - TrueCrypt AES
0.2 GB/s (1%)
3DMark 06 - CPU - 3DMark 06 - CPU
3065 Points (7%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
13.1 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
29.6 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
685 s (3%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
7551 Points (7%)
3DMark - 3DMark Ice Storm Physics
21820 Points (18%)
3DMark - 3DMark Cloud Gate Physics
1998 Points (5%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
5023 Points (10%)
Geekbench 2 - 32 Bit - Geekbench Integer
4579 Points (9%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
