Tiger Lake Architecture: New CPU and GPU in 2020
Tiger Lake was first announced during the Architecture Day 2020 in August and is the successor to Ice Lake. It integrates a new CPU core architecture (Willow Cove microarchitecture), new Xe graphics card (Gen12) and the latest display and I/O technology.
Tiger Lake was introduced in the two U-series (UP3 and UP4) for thin and light laptops. UP3 is designed for 12-28 W TDP range for laptops (former U-series) and UP4 for smaller devices (like tablets and fanless designs) with a TDP range of 9-15W (former Y-series). The UP4 chips also comes in a smaller package. Both feature four cores and Xe graphics with up to 96 EUs. The LLC (last level cache or L3-cache) can be up to 12 MB.
Later (early 2021?) Intel will introduce the Tiger Lake-H series for gaming laptops and mobile workstations. It features up to 8 cores, 24 MB LLC and 32 EU Xe graphics. The PCH is discrete and not on the package as in the U-series.
Tiger Lake is produced in an improved 10nm process at Intel and called 10nm SuperFin. It combines enhanced FinFET transistors with Super metal insulator metal (MIM) capacitor. According to Intel this leads to the largest single, intranode enhancement in its history, comparable to a full-node transition.
Media and Display Features
Tiger Lake SoCs (partly) integrate Thunderbolt 4 and USB4 with up to 40GB/s bandwidth per port. Furthermore, PCIe Gen4 is now integrated with 8GB/s bandwidth to memory. In the U-series the chip only offers 4 Gen4 lanes for fast SSDs, in the H-series more lanes are expected (thanks to the discrete PCH 16 additional Gen4 lanes).
Tiger Lake UP3 and UP4 adds support for 8K60 HEVC/VP9/SCC and 8K30 AV1 compared to Ice Lake.
The iGPU now supports one more display pipe (now 4) with a maximum of 4 x 4K60 HDR and HDCP2.3. HDMI 2.1 support can be achieved vie DisplayPort 1.4 bridge (8K60).
Benchmarks
For benchmarks of the Tiger Lake chips, see the CPU and GPU pages linked below or look at our benchmark test of the Intel development laptop featuring a Core i7-1185G7.
Pos | Model | L2 Cache + L3 Cache | TDP Watt | MHz - Turbo | Cores / Threads | Cinebench R15 CPU Single 64Bit | Cinebench R15 CPU Multi 64Bit | Cinebench R20 Single | Cinebench R20 | Blender(-) | Geekbench 5.4 Single-Core | Geekbench 5.4 Multi-Core |
Intel Core i9-11900KB | 10MB + 24MB | 65 | 3300 ‑ 5300 | 8/16 | 247 | 2027 | 629 | 4644 | 262.7 | 1656 | 8924 | |
Intel Core i9-11980HK | 10MB + 24MB | 45 | 2600 ‑ 5000 | 8/16 | 230n6 | 2152n7 | 594n7 | 4568.5n8 | 256n4 | 1627n5 | 9813n5 | |
Intel Core i9-11900H | 10MB + 24MB | 45 | 2500 ‑ 4900 | 8/16 | 239.5n4 | 2166n4 | 605.5n4 | 4950.5n4 | 242.5n4 | 1628n4 | 9645.5n4 | |
Intel Core i9-11950H | 10MB + 24MB | 45 | 2600 ‑ 5000 | 8/16 | 242.5n4 | 1954n5 | 619.5n4 | 4664.5n4 | 254n3 | 1631n3 | 7969n3 | |
Intel Xeon W-11955M | 10MB + 24MB | 45 | 2600 ‑ 5000 | 8/16 | 230 | 1846 | 568 | 4250 | 276 | 1586.5n2 | 9057.5n2 | |
Intel Core i7-11850H | 10MB + 24MB | 45 | 2500 ‑ 4800 | 8/16 | 232.5n2 | 1767.5n2 | 595n2 | 4244.5n2 | 285n2 | 1672.5n2 | 9250n2 | |
Intel Core i7-11800H | 10MB + 24MB | 45 | 2300 ‑ 4600 | 8/16 | 227.5n44 | 1939.5n48 | 580n45 | 4697.5n48 | 261n44 | 1572n38 | 8921.5n38 | |
Intel Core i7-11600H | 7.5MB + 18MB | 45 | 2900 ‑ 4600 | 6/12 | 4073 | 1401 | 6375 | |||||
Intel Xeon W-11855M | 7.5MB + 18MB | 45 | 3200 ‑ 4800 | 6/12 | 1573 | 7191 | ||||||
Intel Core i5-11500H | 7.5MB + 12MB | 45 | 2900 ‑ 4600 | 6/12 | 1507 | 6987 | ||||||
Intel Core i5-11400H | 7.5MB + 12MB | 45 | 2700 ‑ 4500 | 6/12 | 218n5 | 1249n6 | 562n5 | 3125n6 | 419n5 | 1510.5n6 | 6350.5n6 | |
Intel Core i5-11260H | 7.5MB + 12MB | 45 | 2600 ‑ 4400 | 6/12 | 3831 | 1428 | 6358 | |||||
Intel Core i7-11390H | 5MB + 12MB | 35 | 3400 ‑ 5000 | 4/8 | 239 | 1041 | 614 | 2362 | 495 | 1619.5n2 | 5838.5n2 | |
Intel Core i7-11375H | 5MB + 12MB | 35 | 3300 ‑ 5000 | 4/8 | 230 | 929 | 606 | 2569 | 473 | 1648 | 6098 | |
Intel Core i7-1195G7 | 5MB + 12MB | 28 | 2900 ‑ 5000 | 4/8 | 222n8 | 940n9 | 559n9 | 1932n9 | 597.5n10 | 1536n7 | 4734n7 | |
Intel Core i7-11370H | 5MB + 12MB | 35 | 3300 ‑ 4800 | 4/8 | 229n15 | 960n17 | 589n11 | 2199n11 | 491n11 | 1556.5n10 | 5388n10 | |
Intel Core i7-1185G7 | 5MB + 12MB | 28 | 3000 ‑ 4800 | 4/8 | 217n27 | 866n32 | 558.5n28 | 2090n28 | 578.5n28 | 1529n21 | 5550n21 | |
Intel Core i7-1165G7 | 5MB + 12MB | 28 | 2800 ‑ 4700 | 4/8 | 218n77 | 850n85 | 564n80 | 1996.5n80 | 587n79 | 1532.5n76 | 5174.5n76 | |
Intel Core i5-1155G7 | 5MB + 8MB | 28 | 2500 ‑ 4500 | 4/8 | 210 | 858 | 550 | 2173 | 540 | 1473 | 5654 | |
Pos | Model | L2 Cache + L3 Cache | TDP Watt | MHz - Turbo | Cores / Threads | Cinebench R15 CPU Single 64Bit | Cinebench R15 CPU Multi 64Bit | Cinebench R20 Single | Cinebench R20 | Blender(-) | Geekbench 5.4 Single-Core | Geekbench 5.4 Multi-Core |
Intel Core i5-11320H | 5MB + 8MB | 35 | 3200 ‑ 4500 | 4/8 | 214n3 | 950n3 | 560n3 | 2319n3 | 516n3 | 1492n3 | 5657n3 | |
Intel Core i5-11300H | 5MB + 8MB | 35 | 3100 ‑ 4400 | 4/8 | 187n8 | 961n11 | 529n11 | 2247.5n10 | 530n10 | 1415n10 | 4749n10 | |
Intel Core i5-1145G7 | 5MB + 8MB | 28 | 2600 ‑ 4400 | 4/8 | 202.5n2 | 791.5n2 | 531n2 | 1841.5n2 | 641n2 | 1428.5n2 | 5261n2 | |
Intel Core i5-1135G7 | 5MB + 8MB | 28 | 2400 ‑ 4200 | 4/8 | 198n59 | 822n63 | 515.5n60 | 1854.5n60 | 653.5n58 | 1384n56 | 4688n56 | |
Intel Core i7-1180G7 | 5MB + 12MB | 9 | 2200 ‑ 4600 | 4/8 | 188 | 549 | 492 | 1301 | 844 | 1525 | 5304 | |
Intel Core i7-1160G7 | 5MB + 12MB | 15 | 2100 ‑ 4400 | 4/8 | 200.5n4 | 816n4 | 514.5n4 | 1699n4 | 910.5n4 | 1437n4 | 4917n4 | |
Intel Core i5-1140G7 | 5MB + 8MB | 15 | 1800 ‑ 4200 | 4/8 | 179 | 630 | 438 | 1126 | 993 | 1353 | 3921 | |
Intel Core i5-1130G7 | 5MB + 8MB | 15 | 1800 ‑ 4000 | 4/8 | 179n3 | 616.5n4 | 448n2 | 1060.5n2 | 1189.5n2 | 1321.5n2 | 4802n2 | |
Intel Core i3-1125G4 | 5MB + 8MB | 28 | 2000 ‑ 3700 | 4/8 | 1198 | 3738 | ||||||
Intel Core i3-1115G4 | 2.5MB + 6MB | 28 | 3000 ‑ 4100 | 2/4 | 190n6 | 480.5n6 | 504.5n6 | 1114n6 | 1021.5n6 | 1311.5n8 | 2605n8 | |
Intel Core i3-1120G4 | 5MB + 8MB | 9 | 1100 ‑ 3500 | 4/8 | ||||||||
Intel Core i3-1110G4 | 2.5MB + 6MB | 15 | 2500 ‑ 3900 | 2/4 | 160.4 | 382 | 422 | 732 | 1560 | 772 | 1894 | |
Intel Pentium Gold 7505 | 2.5MB + 4MB | 15 | 2000 ‑ 3500 | 2/4 | 165n2 | 400n2 | 429n2 | 1017n2 | 1150n2 | 1129n3 | 2326n3 | |
Intel Celeron 6305 | 2.5MB + 4MB | 15 | 1800 | 2/2 | 83.95n2 | 161.05n2 | 217n2 | 416n2 | 2834n2 | 638n2 | 1198n2 | |
Intel Celeron 6205 | 2.5MB + 4MB | 15 | 2/2 |
