Intel Core Ultra 5 245
The Intel Core Ultra 5 245 is an Arrow Lake-based desktop processor with 14 cores in two clusters. The 6 performance cores clock at up to 5.1 GHz and the 8 smaller efficiency cores at up to 4.5 GHz.
The CPU performance is slightly above the older Core i5-14600K and therefore also suited for demanding applications and 3D gaming. Thanks to the 5,1 GHz of the performance cores, the single core performance is excellent.
The integrated GPU is just called Intel Graphics and offers 4 Xe cores wit up to 1.9 GHz.
The Arrow Lake-S chips are composed of several chiplets. The CPU part is manufactured at TSMC in the modern N3B (3nm) process, the GPU also comes from TSMC in the N5P process. The SoC and I/O tile are manufactured in the older TSMC N6 process. The base tile is manufactured by Intel in the 22nm process and carries the individual chiplets thanks to Fovero's 3D packaging.
The TDP is specified at 65 watts (long-term) to 121 watts (Turbo).
| Codename | Arrow Lake-S | ||||||||||||||||||||
| Series | Intel Arrow Lake | ||||||||||||||||||||
Series: Arrow Lake Arrow Lake-S
| |||||||||||||||||||||
| Clock Rate | 3000 - 5100 MHz | ||||||||||||||||||||
| Level 2 Cache | 26 MB | ||||||||||||||||||||
| Level 3 Cache | 24 MB | ||||||||||||||||||||
| Number of Cores / Threads | 14 / 14 6 x 5.1 GHz Intel Lion Cove P-core 8 x 4.5 GHz Intel Skymont E-core | ||||||||||||||||||||
| Power Consumption (TDP = Thermal Design Power) | 65 Watt | ||||||||||||||||||||
| TDP Turbo PL2 | 121 Watt | ||||||||||||||||||||
| Manufacturing Technology | 3 nm | ||||||||||||||||||||
| Max. Temperature | 105 °C | ||||||||||||||||||||
| Socket | LGA1851 | ||||||||||||||||||||
| GPU | Intel Graphics 4-Core iGPU (Arc) (300 - 1900 MHz) | ||||||||||||||||||||
| NPU / AI | 13 TOPS INT8 | ||||||||||||||||||||
| 64 Bit | 64 Bit support | ||||||||||||||||||||
| Architecture | x86 | ||||||||||||||||||||
| Starting Price | $270 U.S. | ||||||||||||||||||||
| Announcement Date | 01/06/2025 | ||||||||||||||||||||
| Product Link (external) | www.intel.com | ||||||||||||||||||||
Benchmarks
- Average benchmark values* Smaller numbers mean a higher performance
No reviews found for this CPU (yet).
