Intel Core Ultra 9 285
The Intel Core Ultra 9 285 is an Arrow Lake-based desktop processor with 24 cores in two clusters. The 8 performance cores clock at up to 5.6 GHz and the 16 smaller efficiency cores at up to 4.6 GHz.
Due to the lower clock rate and the low TDP, the CPU performance is slightly below the Core Ultra 9 285K is positioned.
The Arrow Lake-S chips are composed of several chiplets. The CPU part is manufactured at TSMC in the modern N3B (3nm) process, the GPU also comes from TSMC in the N5P process. The SoC and I/O tile are manufactured in the TSMC N6 process. The base tile is manufactured by Intel in the 22nm process and carries the individual chiplets thanks to Fovero's 3D packaging.
The TDP is specified at 65 watts (long-term) to 182 watts (Turbo).
| Codename | Arrow Lake-S | ||||||||||||||||||||||||
| Series | Intel Arrow Lake | ||||||||||||||||||||||||
Series: Arrow Lake Arrow Lake-S
| |||||||||||||||||||||||||
| Clock Rate | 1900 - 5600 MHz | ||||||||||||||||||||||||
| Level 2 Cache | 39.3 MB | ||||||||||||||||||||||||
| Level 3 Cache | 36 MB | ||||||||||||||||||||||||
| Number of Cores / Threads | 24 / 24 8 x 5.6 GHz Intel Lion Cove P-core 16 x 4.6 GHz Intel Skymont E-core | ||||||||||||||||||||||||
| Power Consumption (TDP = Thermal Design Power) | 65 Watt | ||||||||||||||||||||||||
| TDP Turbo PL2 | 182 Watt | ||||||||||||||||||||||||
| Manufacturing Technology | 3 nm | ||||||||||||||||||||||||
| Max. Temperature | 105 °C | ||||||||||||||||||||||||
| Socket | LGA1851 | ||||||||||||||||||||||||
| GPU | Intel Graphics 4-Core iGPU (Arc) ( - 2000 MHz) | ||||||||||||||||||||||||
| NPU / AI | 13 TOPS INT8 | ||||||||||||||||||||||||
| 64 Bit | 64 Bit support | ||||||||||||||||||||||||
| Architecture | x86 | ||||||||||||||||||||||||
| Announcement Date | 01/06/2025 | ||||||||||||||||||||||||
| Product Link (external) | www.intel.com | ||||||||||||||||||||||||
Benchmarks
- Average benchmark values* Smaller numbers mean a higher performance
