AMD A10-4655M

AMD A10-4655M

The AMD A10-4655M is a mobile low-voltage (LV) quad-core processor based on the Trinity architecture. Officially introduced in Q2 2012, it is the direct successor to the Llano A-series of APUs (Accelerated Processing Unit). The processing unit is manufactured in 32nm SOI and integrates a 2.0 GHz CPU (up to 2.8 GHz w/ Turbo Core) with a relatively fast Radeon HD 7620G GPU alongside a dual-channel memory controller, video de- and encoders and a northbridge.

The CPU cores are based on a reworked Bulldozer architecture, called Piledriver. Although marketed as a quad-core processor, the A10-4655M includes only two modules with four integer-cores and two floating-point cores total. As a result, the CPU is not a true quad-core processor.

When compared to previous Bulldozer cores, AMD has managed to improve upon the IPC (instructions per clock) performance of Trinity cores while allowing for higher clock frequencies. However, when compared to its Llano predecessor, the multithreaded performance of Trinity has only been slightly improved. The enhanced Turbo Core 3.0 feature functions well in speeding up single threaded performance, although it is still not on the same level as Intel’s Turbo Boost equivalent. Regardless, AMD has managed to include other features as well, such as the AVX extension (including FMA) and support for AES encryption.

In terms of raw general performance, the A10-4655M performs similar to the A8-4500M and the Llano-based A8-3500M. Single-threaded workloads can especially benefit from the new architecture and the updated Turbo Core functionality. If compared to Intels Core-i3-series, the A10-4655M offers less performance in most cases. Nonetheless, CPU performance from the AMD processor is sufficient for all daily workloads like Office, Internet browsing and even light video editing or gaming.

The integrated DirectX 11-compatible Radeon HD 7620G offers all 384 shader cores of the Trinity chip and, thanks to Turbo Core, will operate anywhere between 360 to 497 MHz depending on the current application demand. On average, the performance of the HD 7620G GPU is comparable to a dedicated Radeon HD 7610M and even faster than the HD Graphics 4000 as found in Intel’s Ivy Bridge.

The power consumption of the A10-4655M APU is rated at 25 Watt TDP and is therefore comparable to previous LV-processors. Consequently, the A10-4655M is best suited for 12-inch notebooks or larger.

SeriesAMD A-Series
CodenameTrinity
Clock Rate2000 - 2800 MHz
Level 2 Cache4096 KB
Number of Cores / Threads4 / 4
Max. Power Consumption (TDP = Thermal Design Power)25 Watt
Transistor Count1303 Million
Manufacturing Technology32 nm
Die Size246 mm2
FeaturesSSE (1, 2, 3, 3S, 4.1, 4.2, 4A), x86-64, AES, AVX, FMA
64 Bit64 Bit support
Hardware VirtualizationAMD-V
Announcement Date05/15/2012

Benchmarks

3DMark (2013) - Fire Strike Standard Physics 1920x1080
0% 100%
min: 2102      avg: 2102 (13%)     median: 2102 (13%)     max: 2102 Points
3DMark (2013) - Cloud Gate Standard Physics 1280x720
0% 100%
min: 1223      avg: 1223 (3%)     median: 1223 (3%)     max: 1223 Points
3DMark (2013) - Ice Storm Standard Physics 1280x720
0% 100%
min: 19991      avg: 19991 (37%)     median: 19991 (37%)     max: 19991 Points
TrueCrypt - Serpent Mean 100MB
0% 100%
min: 0.117      avg: 0.1 (7%)     median: 0.1 (7%)     max: 0.117 GB/s
TrueCrypt - Twofish Mean 100MB
0% 100%
min: 0.208      avg: 0.2 (13%)     median: 0.2 (13%)     max: 0.208 GB/s
TrueCrypt - AES Mean 100MB
0% 100%
min: 0.949      avg: 0.9 (11%)     median: 0.9 (11%)     max: 0.949 GB/s
WinRAR - Result
0% 100%
min: 1263      avg: 1263 (17%)     median: 1263 (17%)     max: 1263 KB/s
wPrime 2.0x - 1024m
0% 100%
min: 1280      avg: 1280 (15%)     median: 1280 (15%)     max: 1280 seconds
3DMark 11 - Performance Physics 1280x720
0% 100%
min: 2236      avg: 2236 (17%)     median: 2236 (17%)     max: 2236 points
3DMark Vantage - P CPU no PhysX 1280x1024
0% 100%
min: 5259      avg: 5259 (13%)     median: 5259 (13%)     max: 5259 Points
3DMark 06 - CPU -
0% 100%
min: 2153      avg: 2160.5 (24%)     median: 2160.5 (24%)     max: 2168 Points
Cinebench R11.5 - CPU Single 64Bit
0% 100%
min: 0.52      avg: 0.5 (26%)     median: 0.5 (26%)     max: 0.52 Points
Cinebench R11.5 - CPU Multi 64Bit
0% 100%
min: 1.65      avg: 1.7 (9%)     median: 1.7 (9%)     max: 1.65 Points
Cinebench R10 - Rendering Single CPUs 64Bit
0% 100%
min: 2280      avg: 2280 (27%)     median: 2280 (27%)     max: 2280 Points
Cinebench R10 - Rendering Multiple CPUs 64Bit
0% 100%
min: 6495      avg: 6495 (18%)     median: 6495 (18%)     max: 6495 Points
Cinebench R10 - Rendering Single 32Bit
0% 100%
min: 1137      avg: 1137 (17%)     median: 1137 (17%)     max: 1137 Points
Cinebench R10 - Rendering Multiple CPUs 32Bit
0% 100%
min: 4530      avg: 4530 (13%)     median: 4530 (13%)     max: 4530 Points
Super Pi mod 1.5 XS 1M -
0% 100%
min: 22      avg: 22 (5%)     median: 22 (5%)     max: 22 Seconds
Super Pi mod 1.5 XS 2M -
0% 100%
min: 80      avg: 80 (3%)     median: 80 (3%)     max: 80 Seconds
Super Pi Mod 1.5 XS 32M -
0% 100%
min: 2077      avg: 2077 (9%)     median: 2077 (9%)     max: 2077 Seconds
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card

#0 Did not recreate cache, as it is less than 5 days old +0.001s ... 0.001s

#1 min, max, avg, median took 0.00011324882507324s +0.327s ... 0.329s

#2 return log +0s ... 0.329s
