Intel Celeron N2805

Intel N2805

The Intel Celeron N2805 is a power efficient dual-core SoC for entry-level notebooks. It is clocked at up to 1.46 GHz and part of the Bay Trail-M platform. Thanks to the specially optimized 22 nanometer low-power process (P1271) with tri-gate transistors, performance and energy efficiency have been significantly improved compared to previous Intel Atom CPUs.

Architecture

The processor cores are based on the new Silvermont architecture, which is an out-of-order design for the first time. The increased utilization of the pipeline and many other improvements (optimized branch prediction, increased buffers, enhanced decoders) have increased the performance per clock by about 50 percent. At the same time, however, the Hyper-Threading feature of the previous generation has been removed. Other major changes are the support for new instruction set extensions such as SSE 4.1 and 4.2 as well as AES-NI (depending on the model).

Performance

Thanks to the improved performance per clock, the Celeron N2805 is faster than previous Intel Atoms, e.g. the N2800. Presumably, the N2805 competes with AMD APUs like the AMD E1-1200. For simple everyday tasks such as Internet or Office the performance is adequate, but not for more complex software or modern games.

Graphics

The graphics unit of Bay Trail is based on the Intel Gen7 architecture, which supports DirectX 11 and is also found in the Ivy Bridge series (e.g. HD Graphics 4000). With only 4 EUs (Execution Units) and a relatively low clock speed of up to 667 MHz, the GPU is even slower than the HD Graphics (Ivy Bridge). Therefore, only older and less demanding games will run fluently.

Power Consumption

The entire SoC is rated at a TDP of 4.5 watts. Thus, the chip can be used in compact subnotebooks.

SeriesIntel Celeron
CodenameBay Trail-M
Clock Rate1460 MHz
Level 1 Cache112 KB
Level 2 Cache1024 KB
Number of Cores / Threads2 / 2
Max. Power Consumption (TDP = Thermal Design Power)4.5 Watt
Manufacturing Technology22 nm
FeaturesIntel HD Graphics (Bay Trail, max. 667 MHz)
64 Bit64 Bit support
Announcement Date09/11/2013
Product Link (external)Intel Celeron N2805

CPU Benchmarks

3DMark 06 - CPU:
0% 100%
min: 885     avg: 885 (8.25%)     max: 885 Points
Super Pi mod 1.5 XS 1M:
0% 100%
min: 55.66     avg: 55.7 (89.72%)     max: 55.66 Seconds*
Super Pi mod 1.5 XS 2M:
0% 100%
min: 121.242     avg: 121.2 (95.67%)     max: 121.242 Seconds*
Super Pi Mod 1.5 XS 32M:
0% 100%
min: 2580.263     avg: 2580.3 (88.59%)     max: 2580.263 Seconds*
PCMark Vantage: Result 1024x768
0% 100%
min: 2115     avg: 2115 (5.73%)     max: 2115 Points
Cinebench R10: Rendering Single 32Bit
0% 100%
min: 739     avg: 739 (9.69%)     max: 739 Points
Cinebench R10: Rendering Multiple CPUs 32Bit
0% 100%
min: 1393     avg: 1393 (5.1%)     max: 1393 Points
3DMark Vantage: P CPU no PhysX 1280x1024
0% 100%
min: 1534     avg: 1534 (3.84%)     max: 1534 Points
wPrime 2.0x: 32m
0% 100%
min: 85.209     avg: 85.2 (83.62%)     max: 85.209 seconds*
wPrime 2.0x: 1024m
0% 100%
min: 2633.862     avg: 2633.9 (69.94%)     max: 2633.862 seconds*
3DMark 11: Performance Physics 1280x720
0% 100%
min: 568     avg: 568 (4.71%)     max: 568 points
WinRAR: Result
0% 100%
min: 887     avg: 887 (17.08%)     max: 887 KB/s
X264 HD Benchmark 4.0: Pass 1
0% 100%
min: 17.35     avg: 17.4 (4.58%)     max: 17.35 fps
X264 HD Benchmark 4.0: Pass 2
0% 100%
min: 3.13     avg: 3.1 (2.36%)     max: 3.13 fps
TrueCrypt: AES Mean 100MB
0% 100%
min: 0.0786     avg: 0.1 (0.56%)     max: 0.0786 GB/s
TrueCrypt: Twofish Mean 100MB
0% 100%
min: 0.0621     avg: 0.1 (3.82%)     max: 0.0621 GB/s
TrueCrypt: Serpent Mean 100MB
0% 100%
min: 0.0395     avg: 0 (1.16%)     max: 0.0395 GB/s
Geekbench 2 - 32 Bit: Total Score
0% 100%
min: 1457     avg: 1457 (10.86%)     max: 1457 Points
Geekbench 2 - 32 Bit: Integer
0% 100%
min: 1397     avg: 1397 (9.87%)     max: 1397 Points
Geekbench 2 - 32 Bit: Floating Point
0% 100%
min: 1233     avg: 1233 (7.21%)     max: 1233 Points
Geekbench 2 - 32 Bit: Memory
0% 100%
min: 1712     avg: 1712 (17.56%)     max: 1712 Points
Geekbench 2 - 32 Bit: Stream
0% 100%
min: 1947     avg: 1947 (20.89%)     max: 1947 Points
3DMark (2013): Ice Storm Standard Physics 1280x720
0% 100%
min: 6672     avg: 6672 (12.32%)     max: 6672 Points
3DMark (2013): Cloud Gate Standard Physics 1280x720
0% 100%
min: 512     avg: 512 (1.27%)     max: 512 Points
3DMark (2013): Fire Strike Standard Physics 1920x1080
0% 100%
min: 634     avg: 634 (3.41%)     max: 634 Points
Geekbench 3: 32 Bit Single-Core Score
0% 100%
min: 599     avg: 599 (17.85%)     max: 599 Points
Geekbench 3: 32 Bit Multi-Core Score
0% 100%
min: 1017     avg: 1017 (7.92%)     max: 1017 Points
- Range of benchmarks for this CPU
- Average benchmark score
