Lenovo Legion 5 15IAH7H, i5-12500H RTX 3060

Specifications

Lenovo Legion 5 15IAH7H, i5-12500H RTX 3060
Lenovo Legion 5 15IAH7H, i5-12500H RTX 3060 (Legion 5 15 Series)
Processor
Intel Core i5-12500H 12 x 1.8 - 4.5 GHz, Alder Lake-H
Graphics adapter
NVIDIA GeForce RTX 3060 Laptop GPU - 6 GB VRAM, Core: 1702 MHz, 130 W TDP, GDDR6
Memory
16 GB
, DDR5-4800
Display
15.60 inch 16:9, 1920 x 1080 pixel 141 PPI, IPS, glossy: no, 165 Hz
Storage
M.2 PCIe 4.0
Connections
3 USB 3.0 / 3.1 Gen1, 2 USB 3.1 Gen2, 1 Thunderbolt, USB-C Power Delivery (PD), 1 HDMI, Audio Connections: 3.5mm
Networking
10/100/1000 LAN Card (10/100/1000MBit/s), Wi-Fi 6E (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/ Wi-Fi 6E 6 GHz), Bluetooth 5.1
Size
height x width x depth (in mm): 19.99 x 358.8 x 262.4 ( = 0.79 x 14.13 x 10.33 in)
Battery
80 Wh Lithium-Polymer, 4-cell
Operating System
Microsoft Windows 11 Home
Camera
Primary Camera: 2 MPix
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes
Weight
2.4 kg ( = 84.66 oz / 5.29 pounds) ( = 0 oz / 0 pounds)



Pricecompare

Average Score: 91.5% - very good
Average of 2 scores (from 2 reviews)
price: 90%, performance: 100%, features: - %, display: 100% mobility: 80%, workmanship: 85%, ergonomy: 80%, emissions: - %

Reviews for the Lenovo Legion 5 15IAH7H, i5-12500H RTX 3060

94% Lenovo Legion 5 15IAH7H review: a powerful “legionnaire”
Source: Root Nation English
Despite the fact that the Legion 5 15IAH7H is a really good laptop, it also has some drawbacks. First of all, I would like the cooling to be more efficient. The laptop cools down on a table without any problems, but the cooling system needs to put a lot of effort into it, which creates a lot of noise. A cooling stand can help, but it would be better if the laptop could do a better job of it on its own. There’s also a lack of an SD card reader that could replace one or two USB connectors. On the other hand, the tested laptop is one of the most powerful among competitors in its price category, and therefore is the best option for gamers with a well-defined budget. Like the previous models in the Legion line, the Lenovo Legion 5 15IAH7H is a powerful laptop with an interesting design and the performance you need for gaming.
Single Review, online available, Very Long, Date: 06/29/2023
Rating: Total score: 94% price: 90% performance: 100% display: 100% mobility: 80% workmanship: 90% ergonomy: 90%

Foreign Reviews

89% Recenzja Lenovo Legion 5 15IAH7H: Potężny „legionista”
Source: Root Nation PL Turkish PL→EN
Single Review, online available, Very Long, Date: 08/02/2023
Rating: Total score: 89% price: 90% performance: 100% display: 100% mobility: 80% workmanship: 80% ergonomy: 70%

Comment

NVIDIA GeForce RTX 3060 Laptop GPU: High-End laptop graphics card based on the Ampere GA106 chip with 3072 cores. Available in different versions with a TDP from 60 to 115 Watt.

With these GPUs you are able to play modern and demanding games fluently at medium detail settings and HD resolution.

» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i5-12500H: Alder Lake based mobile CPU with 4 performance cores and 8 efficient cores. The performance cores offer hyper threading, leading to 16 threads that can be processed. The CPU clocks from 1.8 to 4.5 GHz and supports vPro.» Further information can be found in our Comparison of Mobile Processsors.


15.60":

15-inch display variants are the standard and are used for more than half of all laptops.

The reason for the popularity of mid-sized displays is that this size is reasonably easy on the eyes, often allows high resolutions and thus offers rich details on the screen, yet does not consume too much power and the devices can still be reasonably compact - simply the standard compromise.

» To find out how fine a display is, see our DPI List.


Lenovo: Lenovo ("Le" from English legend, novo (Latin) for new) was founded in 1984 as a Chinese computer trading company. As of 2004, the company was the largest laptop manufacturer in China and, after acquiring IBM's PC division in 2005, the fourth largest in the world. In addition to desktops and notebooks, the company manufactures monitors, projectors, servers, etc, and specializes in developing, manufacturing and marketing consumer electronics, personal computers, software, enterprise solutions and related services.

In 2016, the company ranked first in the world in computer sales. It still held it in 2023 with about 23% global market share. Important product lines are Thinkpad, Legion and Ideapad.

In 2011, it acquired a majority stake in Medion AG, a European computer hardware manufacturer. In 2014, Motorola Mobility was purchased, which gave Lenovo a boost in the smartphone market.


91.5%: There are not very many models that are rated better. Most of the assessments are in percentage ranges below that. The tested product is not considered perfect, but the sources give a clear purchase recommendation.


» Further information can be found in our Notebook Purchase Guide.
