Mediatek MT8125

 MT8125

The Mediatek MT8125 is a low-cost ARM SoC (System on a Chip) mainly used in tablets. It is manufactured in 28 nm and integrates a quad-core Cortex-A7 processor and a PowerVR SGX 544 GPU. The CPU cores are typically clocked at 1.2 - 1.5 GHz while the GPU is clocked at 300 MHz.

Performance

Since the Cortex-A7 architecture is somewhat slower than a Krait or Cortex-A9 design at the same clock speeds, the performance of the MT8125 is just below Nvidia's Tegra 3 or the Samsung Exynos 4412. The PowerVR SGX 544 is also just a low-cost solution not designed for ultra-high resolution displays or very demanding games.

Features

In addition to the processor and GPU, the SoC integrates a decoder for 1080p video, WiFi, Bluetooth 4.0, FM radio, GPS and 2G/3G radios up to HSPA+. Cameras are supported up to a resolution of 13 MP.

Power consumption

Thanks to the energy-efficient A7 cores and 28 nm manufacturing, the power consumption is likely very low and suitable for even smaller tablets.

Series Mediatek
CodenameCortex-A7

Series: Mediatek Cortex-A7

Mediatek MT6592 compare1.7 GHz8 / 8 cores Cortex-A7
Mediatek MT8127 compare1.5 GHz4 / 4 cores Cortex-A7
Mediatek MT6589T compare1.5 GHz4 / 4 cores Cortex-A7
Mediatek MT8389 compare1.2 GHz4 / 4 cores Cortex-A7
Mediatek MT8125 « 1.2 GHz4 / 4 cores Cortex-A7
Mediatek MT8321 compare1.3 GHz4 / 4 cores Cortex-A7
Mediatek MT8121 compare1.3 GHz4 / 4 cores Cortex-A7
Mediatek MT6582 compare1.3 GHz4 / 4 cores Cortex-A7
Mediatek MT6582M compare1.3 GHz4 / 4 cores Cortex-A7
Mediatek MT6580M compare1.3 GHz4 / 4 cores Cortex-A7
Mediatek MT6589 compare1.2 GHz4 / 4 cores Cortex-A7
MediaTek MT6572 compare1.2 GHz2 / 2 cores Cortex-A7
Clock Rate1200 - 1500 MHz
Level 2 Cache1 MB
Number of Cores / Threads4 / 4
Manufacturing Technology28 nm
FeaturesWi-Fi, Bluetooth 4.0, GPS, FM, 3G/HSPA+, 2G/EDGE
GPUPowerVR SGX544 (300 MHz)
ArchitectureARM
Announcement Date05/29/2013
Product Link (external)www.mediatek.com

Benchmarks

3DMark - 3DMark Ice Storm Unlimited Physics
min: 7990     avg: 8125     median: 8080 (7%)     max: 8306 Points
Geekbench 2 - 32 Bit - Geekbench Integer
min: 1194     avg: 1208     median: 1204 (2%)     max: 1229 Points
Linpack Android / IOS - Linpack Multi Thread
min: 89.6     avg: 102.8     median: 89.7 (3%)     max: 127.1 MFLOPS
Linpack Android / IOS - Linpack Single Thread
min: 33.78     avg: 36.4     median: 37.6 (4%)     max: 38.4 MFLOPS
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 16900     avg: 19560     median: 17694 (21%)     max: 25950 ms
Vellamo 3.x - Vellamo 3.x Browser
min: 1386     avg: 1472     median: 1471.5 (19%)     max: 1557 Points
AnTuTu v4 - AnTuTu v4 Total Score
min: 13211     avg: 13244     median: 13243.5 (31%)     max: 13276 Points
PassMark PerformanceTest Mobile V1 - PerformanceTest Mobile V1 CPU Tests
min: 8230     avg: 8406     median: 8406 (1%)     max: 8580 Points
PCMark for Android - PCM f. Android Work Score
1873 Points (9%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
