Intel Core i3-1210U vs Intel Core i7-1180G7 vs Intel Core i5-1245U

Intel Core i3-1210U

The Intel Core i3-1210U is a low power mobile CPU for thin and light laptops based on the Alder Lake architecture. It was announced in early 2022 and offers 2 performance cores (P-cores, Golden Cove architecture) and 4 efficient cores (E-cores, Gracemont architecture). The P-cores support Hyper-Threading leading to 8 supported threads when combined with the E-cores. The clock rate ranges from 1 to 4.4 GHz on the performance cluster and 0.7 to 3.3 GHz on the efficient cluster. The performance of the E-cores should be similar to old Skylake cores (compare to the Core i7-6700HQ). All cores can use up to 10 MB L3 cache.

Performance

While we have not tested a single system built around the 1210U as of August 2023, we fully expect its multi-thread performance to be pretty much identical to that of the i3-1215U. Which is pretty fast for an entry-level chip, as of mid 2023.

Your mileage may vary depending on how high the CPU power limits are and how competent the cooling solution of your system is.

Features

The integrated memory controller supports various memory types up to DDR5-4800, DDR4-3200, LPDDR5-5200, and LPDDR4x-4267. The Thread Director (in hardware) can support the operating system to decide which thread to use on the performance or efficient cores for the best performance. For AI tasks, the CPU also integrates GNA 3.0 and DL Boost (via AVX2). Quick Sync in version 8 is the same as in the Rocket Lake CPUs and supports MPEG-2, AVC, VC-1 decode, JPEG, VP8 decode, VP9, HEVC, and AV1 decode in hardware. The CPU only supports PCIe 4.0 (x8 for a GPU and two x4 for SSDs).

The integrated graphics adapter is based on the Xe-architecture and offers 64 of the 96 EUs (Execution Units) operating at up to 0.9 GHz.

Power consumption

This Core i3 has a Base power consumption of 9 W, with 29 W being its maximum Intel-recommended Turbo power consumption. TDP values that low allow for passively designs as long as performance is not a priority.

The CPU is built with Intel's 3rd generation 10 nm process marketed as Intel 7 for decent, as of early 2023, energy efficiency.

Intel Core i7-1180G7

The Intel Core i7-1180G7 is a power-efficient quad-core SoC for laptops and Ultrabooks based on the Tiger Lake-U generation (UP4) that was introduced in early 2021. It integrates four Willow Cove processor cores (8 threads thanks to Hyper-Threading). The guaranteed base clock speed depends on the TDP setting and can range from 0.9 (7 W TDP) to 2.2 GHz (15 W TDP). The Turbo clock speed is specified at 4.6 GHz for one core, all cores can reach up to 3.7 GHz.

Another novelty is the integrated Xe graphics card with 96EUs based on the completely new Gen 12 architecture. It offers a significantly higher performance compared to the older Iris Plus G7 (Ice Lake). The GPU and CPU can together use the 12 MB of L3 cache.

Furthermore, Tiger Lake SoCs add PCIe 4 support (four lanes), AI hardware acceleration, and the partial integration of Thunderbolt 4 / USB 4 and Wi-Fi 6 in the chip. The i5-1140G7 also supports the management feature vPro.

The chip is produced on the improved 10nm process (called SuperFin) at Intel that should be comparable to the 7nm process at TSMC (e.g. Ryzen 4000 series).

The operating range of the UP4 series is specified at 7 to 15 Watt. Therefore, the processor is well suited for very thin and light laptops, convertibles or tablets.

Intel Core i5-1245U

The Intel Core i5-1245U is a mid-range mobile CPU for thin and light laptops based on the Alder Lake architecture. It was announced in early 2022 and offers 2 performance cores (P-cores, Golden Cove architecture) and 8 efficient cores (E-cores, Gracemont architecture). The P-cores support Hyper-Threading leading to 12 supported threads when combined with the E-cores. The clock rate ranges from 1.6 to 4.4 GHz on the performance cluster and 1.2 to 3.3 GHz on the efficient cluster. The performance of the E-cores should be similar to old Skylake cores (compare to the Core i7-6700HQ). All cores can use up to 12 MB L3 cache. Compared to the i7-1265U (fastest U-series CPU at launch), the 1245U offers lower clock speeds, a slower iGPU, but the full "Enterprise" vPro management features. Compared to the P-series (28W) or H-series (45W), the 15W TDP may limit the sustained performance.

Performance

Thanks to the 10 cores, the multi-threaded performance should be clearly faster than the older quad-core Tiger Lake CPUs with 15 Watt (like the Intel Core i7-1160G7). The sustained performance will be limited by the TDP setting and thermals and therefore only short term loads. Thanks to the architectural improvements of the big Golden Cove cores, the single thread performance should be better than similar clocked Tiger Lake CPUs.

Features

The integrated memory controller supports various memory types up to DDR5-4800, DDR4-3200, LPDDR5-5200, and LPDDR4x-4267. The Thread Director (in hardware) can support the operating system to decide which thread to use on the performance or efficient cores for the best performance. For AI tasks, the CPU also integrates GNA 3.0 and DL Boost (via AVX2). Quick Sync in version 8 is the same as in the Rocket Lake CPUs and supports MPEG-2, AVC, VC-1 decode, JPEG, VP8 decode, VP9, HEVC, and AV1 decode in hardware. The CPU only supports PCIe 4.0 (x8 for a GPU and two x4 for SSDs).

The integrated graphics adapter is based on the Xe-architecture and offers 80 of the 96 EUs (Execution Units) operating at up to 1.2 GHz.

The CPU is rated at 15 W base power (TDP, PL1) and 55 W max. Turbo power (PL2) and the whole SoC is manufactured on a 10nm process at Intel, which is known as Intel 7.
