Mediatek MT8121

MT8121

The Mediatek MT8121 is a low-cost ARM SoC (System on a Chip) mainly used in tablets. It is manufactured in 28 nm and integrates a quad-core Cortex-A7 processor and a PowerVR SGX 544 GPU. The CPU cores are typically clocked at 1.3 GHz while the GPU is clocked at 156 MHz.

Performance

Since the Cortex-A7 architecture is somewhat slower than a Krait or Cortex-A9 design at the same clock speeds, the performance of the MT8121 is just below Nvidia's Tegra 3 or the Samsung Exynos 4412. The PowerVR SGX 544 is also just a low-cost solution not designed for ultra-high resolution displays or very demanding games.

Features

In addition to the processor and GPU, the SoC integrates a decoder for 1080p video, WiFi, Bluetooth 4.0 as well as GPS, but lacks a 2G/3G/4G radio. Cameras are supported up to a resolution of 13 MP.

Power consumption

Thanks to the energy-efficient A7 cores and 28 nm manufacturing, the power consumption is likely very low and suitable for even smaller tablets.

Series Mediatek
CodenameCortex-A7
Clock Rate1300 MHz
Level 2 Cache1024 KB
Number of Cores / Threads4 / 4
Manufacturing Technology28 nm
FeaturesWi-Fi, Bluetooth 4.0, GPS
64 Bitno 64 Bit support
Announcement Date07/01/2013

Benchmarks

Vellamo 3.x - Metal
0% 100%
min: 696      avg: 696 (25%)     median: 696 (25%)     max: 696 Points
Octane V2 - Total Score
0% 100%
min: 2085      avg: 2085 (6%)     median: 2085 (6%)     max: 2085 Points
Mozilla Kraken 1.1 - Total Score
0% 100%
min: 16115      avg: 16115 (27%)     median: 16115 (27%)     max: 16115 ms
Geekbench 3 - 32 Bit Multi-Core Score
0% 100%
min: 1125      avg: 1140.5 (7%)     median: 1140.5 (7%)     max: 1156 Points
Geekbench 3 - 32 Bit Single-Core Score
0% 100%
min: 351      avg: 351 (8%)     median: 351 (8%)     max: 351 Points
AndEBench - Java
0% 100%
min: 358      avg: 367 (26%)     median: 367 (26%)     max: 376 Iter./s
AndEBench - Native
0% 100%
min: 6678      avg: 6881 (32%)     median: 6881 (32%)     max: 7084 Iter./s
3DMark (2013) - Ice Storm Unlimited Physics 1280x720 offscreen
0% 100%
min: 8982      avg: 8982 (15%)     median: 8982 (15%)     max: 8982 Points
3DMark (2013) - Ice Storm Standard Physics 1280x720
0% 100%
min: 8296      avg: 8296 (15%)     median: 8296 (15%)     max: 8296 Points
PassMark PerformanceTest Mobile V1 - CPU Tests
0% 100%
min: 9544      avg: 9761 (13%)     median: 9761 (13%)     max: 9978 Points
AnTuTu Benchmark v4 - Total Score
0% 100%
min: 16946      avg: 17314 (40%)     median: 17314 (40%)     max: 17682 points
Geekbench 2 - 32 Bit - Stream
0% 100%
min: 351      avg: 351 (4%)     median: 351 (4%)     max: 351 Points
Geekbench 2 - 32 Bit - Memory
0% 100%
min: 836      avg: 836 (9%)     median: 836 (9%)     max: 836 Points
Geekbench 2 - 32 Bit - Floating Point
0% 100%
min: 1975      avg: 1975 (11%)     median: 1975 (11%)     max: 1975 Points
Sunspider - 1.0 Total Score
0% 100%
min: 1451.8      avg: 1452.9 (36%)     median: 1452.9 (36%)     max: 1454 ms
Sunspider - 0.9.1 Total Score
0% 100%
min: 1464.3      avg: 1464.3 (14%)     median: 1464.3 (14%)     max: 1464.3 ms
Quadrant Standard Edition 2.0 -
0% 100%
min: 8256      avg: 8492 (35%)     median: 8492 (35%)     max: 8728 points
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card

#0 Did not recreate cache, as it is less than 5 days old +0.002s ... 0.002s

#1 min, max, avg, median took 0.00028347969055176s +0.339s ... 0.341s

#2 return log +0s ... 0.341s

Reviews for the Mediatek MT8121 processor

Lenovo A8-50 (PowerVR SGX544, 8.0")
» Lenovo Tab A8 Tablet Review - Review
» Lenovo A8-50 - External Review

Lenovo Ideapad A10 (PowerVR SGX544, 10.1")
» Lenovo A10 Tablet Review - Review
» Lenovo Ideapad A10 - External Review

Lenovo IdeaTab A8-50 A5500 (PowerVR SGX544, 8.0")
» Lenovo IdeaTab A8-50 A5500 - External Review

» Mobile CPU Comparison
Comparison of all mobile CPU series

» Mobile Processors - Benchmarklist
Benchmarklist of all known CPUs that are used in laptops (desktop and laptop CPUs)

Other CPUs of the series Mediatek

» Mediatek MT6595 Turbo
   2.5 GHz / 2 MB
» Mediatek MT6595
   2.2 GHz / 2 MB
» Mediatek MT6595M
   2 GHz / 2 MB
» Mediatek MT6795
   2.2 GHz / 0 MB
» Mediatek MT8135
   1.7 GHz / 0 MB
» Mediatek MT6752
   2 GHz / 0 MB
» Mediatek MT6592
   1.7 GHz / 1 MB
» Mediatek MT6589T
   1.5 GHz / 2 MB
» Mediatek MT8389
   1.2 GHz / 1 MB
» Mediatek MT8125
   1.2 GHz / 1 MB
» Mediatek MT8121
   1.3 GHz / 1 MB
» Mediatek MT6582
   1.3 GHz / 0.5 MB
» Mediatek MT6582M
   1.3 GHz / 0.5 MB
» Mediatek MT6589
   1.2 GHz / 0 MB
» Mediatek MT8312
   1.3 GHz / 0 MB
» Mediatek MT8377
   1.2 GHz / 1 MB
» Mediatek MT6572
   1.2 GHz / 1 MB
» Mediatek MT8317T
   1.2 GHz / 0 MB
» Mediatek MT6577
   1 GHz / 0 MB
» Mediatek MT6575
   1 GHz / 0 MB

Surrounding CPUs

- NVIDIA Tegra 3
   1.2 GHz / 0 MB
- Mediatek MT6589T
   1.5 GHz / 2 MB
- Mediatek MT8389
   1.2 GHz / 1 MB
- Mediatek MT8125
   1.2 GHz / 1 MB
- Samsung Exynos 3470 Quad
   1.4 GHz / 0 MB
» Mediatek MT8121
   1.3 GHz / 1 MB
+ Mediatek MT6582
   1.3 GHz / 512 KB
+ Mediatek MT6582M
   1.3 GHz / 512 KB
> Notebook / Laptop Reviews and News > FAQ / Tips / Technics > Notebook Processors > Mediatek MT8121 SoC
Author: Klaus Hinum (Update: 2014-06- 9)
