Mediatek MT8121

MT8121

The Mediatek MT8121 is a low-cost ARM SoC (System on a Chip) mainly used in tablets. It is manufactured in 28 nm and integrates a quad-core Cortex-A7 processor and a PowerVR SGX 544 GPU. The CPU cores are typically clocked at 1.3 GHz while the GPU is clocked at 156 MHz.

Performance

Since the Cortex-A7 architecture is somewhat slower than a Krait or Cortex-A9 design at the same clock speeds, the performance of the MT8121 is just below Nvidia's Tegra 3 or the Samsung Exynos 4412. The PowerVR SGX 544 is also just a low-cost solution not designed for ultra-high resolution displays or very demanding games.

Features

In addition to the processor and GPU, the SoC integrates a decoder for 1080p video, WiFi, Bluetooth 4.0 as well as GPS, but lacks a 2G/3G/4G radio. Cameras are supported up to a resolution of 13 MP.

Power consumption

Thanks to the energy-efficient A7 cores and 28 nm manufacturing, the power consumption is likely very low and suitable for even smaller tablets.

Series Mediatek
CodenameCortex-A7
Clock Rate1300 MHz
Level 2 Cache1024 KB
Number of Cores / Threads4 / 4
Manufacturing Technology28 nm
FeaturesWi-Fi, Bluetooth 4.0, GPS
GPUPowerVR SGX544 (156 MHz)
64 Bitno 64 Bit support
Announcement Date07/01/2013

Benchmarks

Vellamo 3.x - Metal
0%
100%
min: 696     avg: 696 (19%)     median: 696 (19%)     max: 696 Points
Octane V2 - Total Score
0%
100%
min: 2085     avg: 2085 (5%)     median: 2085 (5%)     max: 2085 Points
Mozilla Kraken 1.1 - Total Score
0%
100%
min: 16115     avg: 16115 (27%)     median: 16115 (27%)     max: 16115 ms
Geekbench 3 - 32 Bit Multi-Core Score
0%
100%
min: 1125     avg: 1140.5 (7%)     median: 1140.5 (7%)     max: 1156 Points
Geekbench 3 - 32 Bit Single-Core Score
0%
100%
min: 351     avg: 351 (8%)     median: 351 (8%)     max: 351 Points
AndEBench - Java
0%
100%
min: 358     avg: 367 (11%)     median: 367 (11%)     max: 376 Iter./s
AndEBench - Native
0%
100%
min: 6678     avg: 6881 (23%)     median: 6881 (23%)     max: 7084 Iter./s
3DMark - Ice Storm Unlimited Physics 1280x720 offscreen
0%
100%
min: 8982     avg: 8982 (14%)     median: 8982 (14%)     max: 8982 Points
3DMark - Ice Storm Standard Physics 1280x720
0%
100%
min: 8296     avg: 8296 (5%)     median: 8296 (5%)     max: 8296 Points
PassMark PerformanceTest Mobile V1 - CPU Tests
0%
100%
min: 9544     avg: 9761 (4%)     median: 9761 (4%)     max: 9978 Points
AnTuTu Benchmark v4 - Total Score
0%
100%
min: 16946     avg: 17314 (40%)     median: 17314 (40%)     max: 17682 points
Geekbench 2 - 32 Bit - Stream
0%
100%
min: 351     avg: 351 (3%)     median: 351 (3%)     max: 351 Points
Geekbench 2 - 32 Bit - Memory
0%
100%
min: 836     avg: 836 (8%)     median: 836 (8%)     max: 836 Points
Geekbench 2 - 32 Bit - Floating Point
0%
100%
min: 1975     avg: 1975 (12%)     median: 1975 (12%)     max: 1975 Points
Sunspider - 1.0 Total Score
0%
100%
min: 1451.8     avg: 1452.9 (36%)     median: 1452.9 (36%)     max: 1454 ms
Quadrant Standard Edition 2.0 -
0%
100%
min: 8256     avg: 8492 (23%)     median: 8492 (23%)     max: 8728 points
Linpack Android / IOS - Single Thread
0%
100%
min: 114.2     avg: 114.6 (11%)     median: 114.6 (11%)     max: 114.998 MFLOPS
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card

v1.3

#0 Did not recreate cache, as it is less than 5 days old! +0.001s ... 0.001s

#1 min, max, avg, median took s +0.554s ... 0.555s

#2 return log +0s ... 0.555s

Reviews for the Mediatek MT8121 processor

Lenovo A8-50 (PowerVR SGX544, 8.0")
» Lenovo Tab A8 Tablet Review - Review
» Lenovo A8-50 - External Review

Lenovo Ideapad A10 (PowerVR SGX544, 10.1")
» Lenovo A10 Tablet Review - Review
» Lenovo Ideapad A10 - External Review

Lenovo IdeaTab A8-50 A5500 (PowerVR SGX544, 8.0")
» Lenovo IdeaTab A8-50 A5500 - External Review

Lenovo Tab2 A7-10F (PowerVR SGX544, 7.0")
» Lenovo Tab2 A7-10F - External Review
