Intel Core i7-7700T vs Intel Core i5-7500T

Intel Core i7-7700T

► remove from comparison Intel i7-7700T

The Intel Core i7-7700T is a fast quad-core processor for desktops based on the Kaby Lake architecture and was announced in January 2017. It is the top model of the 35 Watt models and significantly slower than the similar named Core i7-7700K. The four Skylake based CPU cores are clocked from 2.9 - 3.8 GHz and support HyperThreading / SMT (8 threads).

Architecture

Intel basically uses the same micro architecture compared to Skylake, so the per-MHz performance does not differ. The manufacturer only reworked the Speed Shift technology for faster dynamic adjustments of voltages and clocks, and the improved 14nm process allows much higher frequencies combined with better efficiency than before.

Performance

The performance of the i7-7700T is slightly faster than the Core i5-7600K with sufficient cooling and TDP settings. Therefore, the CPU is fine to handle even demanding tasks and apps.

Graphics

The integrated Intel HD Graphics 630 has 24 Execution Units (similar to previous HD Graphics 530) running at 350 - 1150 MHz. The performance depends a lot on the memory configuration; it should be comparable to a dedicated Nvidia GeForce 920M in combination with fast DDR4-2133 dual-channel memory.

Contrary to Skylake, Kaby Lake now supports hardware decoding for H.265/HEVC Main 10 with a 10-bit color depth as well as Google's VP9 codec. The dual-core Kaby Lake processors, which were announced in January, should also support HDCP 2.2.

Intel Core i5-7500T

► remove from comparison Intel i5-7500T

The Intel Core i5-7500T is a power efficient desktop quad-core based on the Kaby Lake architecture. It was announced early 2017 and offers four cores and no HyperThreading (only 4 threads). The CPU clocks between 2.7 and 3.3 GHz. The integrated Intel HD Graphics 630 graphics card offers 24 EUs clocked at 350 to 1100 MHz. The TDP is specified at only 35 Watt and therefore even lower than mobile HQ quad cores (45 Watt). Thats why the CPU is also used in some laptops.

Intel Core i7-7700TIntel Core i5-7500T
Intel Kaby LakeIntel Kaby Lake
Kaby LakeKaby Lake
Series: Kaby Lake Kaby Lake
Intel Core i7-7700K compare4.2 - 4.5 GHz4 / 88 MB
Intel Core i7-7700 compare3.6 - 4.2 GHz4 / 88 MB
Intel Xeon E3-1535M v6 compare3.1 - 4.2 GHz4 / 88 MB
Intel Core i7-7920HQ compare3.1 - 4.1 GHz4 / 88 MB
» Intel Core i7-7700T2.9 - 3.8 GHz4 / 88 MB
Intel Core i5-7600K compare3.8 - 4.2 GHz4 / 48 MB
Intel Xeon E3-1505M v6 compare3 - 4 GHz4 / 88 MB
Intel Core i7-7820HQ compare2.9 - 3.9 GHz4 / 88 MB
Intel Core i7-7820HK compare2.9 - 3.9 GHz4 / 88 MB
Intel Core i7-7700HQ compare2.8 - 3.8 GHz4 / 86 MB
Intel Core i5-7500 compare3.4 - 3.8 GHz4 / 46 MB
Intel Core i5-7440HQ compare2.8 - 3.8 GHz4 / 46 MB
Intel Core i7-7567U compare3.5 - 4 GHz2 / 44 MB
Intel Core i7-7660U compare2.5 - 4 GHz2 / 44 MB
Intel Core i7-7600U compare2.8 - 3.9 GHz2 / 44 MB
Intel Core i5-7300HQ compare2.5 - 3.5 GHz4 / 46 MB
Intel Core i5-7500T2.7 - 3.3 GHz4 / 46 MB
Intel Core i5-7287U compare3.3 - 3.7 GHz2 / 44 MB
Intel Core i7-7560U compare2.4 - 3.8 GHz2 / 44 MB
Intel Core i5-7267U compare3.1 - 3.5 GHz2 / 44 MB
Intel Core i5-7360U compare2.3 - 3.6 GHz2 / 44 MB
Intel Core i7-7500U compare2.7 - 3.5 GHz2 / 44 MB
Intel Core i5-7300U compare2.6 - 3.5 GHz2 / 43 MB
Intel Core i5-7260U compare2.2 - 3.4 GHz2 / 44 MB
Intel Core i5-7200U compare2.5 - 3.1 GHz2 / 43 MB
Intel Core i3-7100H compare3 GHz2 / 43 MB
Intel Core i3-7167U compare2.8 GHz2 / 43 MB
Intel Core i3-7130U compare2.7 GHz2 / 43 MB
Intel Core i7-7Y75 compare1.3 - 3.6 GHz2 / 44 MB
Intel Core i5-7Y57 compare1.2 - 3.3 GHz2 / 44 MB
Intel Core i5-7Y54 compare1.2 - 3.2 GHz2 / 44 MB
Intel Core i3-7100U compare2.4 GHz2 / 43 MB
Intel Core m3-7Y32 compare1 - 3 GHz2 / 44 MB
Intel Pentium Gold 4415U compare2.3 GHz2 / 42 MB
Intel Core m3-7Y30 compare1 - 2.6 GHz2 / 44 MB
Intel Celeron 3965U compare2.2 GHz2 / 22 MB
Intel Core i3-7020U compare2.3 GHz2 / 43 MB
Intel Celeron 3867U compare1.8 GHz2 / 22 MB
Intel Celeron 3865U compare1.8 GHz2 / 22 MB
Intel Pentium Gold 4425Y compare1.7 GHz2 / 42 MB
Intel Pentium Gold 4415Y compare1.6 GHz2 / 42 MB
Intel Pentium Gold 4410Y compare1.5 GHz2 / 42 MB
Intel Celeron 3965Y compare1.5 GHz2 / 22 MB
Intel Core i7-7700K compare4.2 - 4.5 GHz4 / 88 MB
Intel Core i7-7700 compare3.6 - 4.2 GHz4 / 88 MB
Intel Xeon E3-1535M v6 compare3.1 - 4.2 GHz4 / 88 MB
Intel Core i7-7920HQ compare3.1 - 4.1 GHz4 / 88 MB
Intel Core i7-7700T2.9 - 3.8 GHz4 / 88 MB
Intel Core i5-7600K compare3.8 - 4.2 GHz4 / 48 MB
Intel Xeon E3-1505M v6 compare3 - 4 GHz4 / 88 MB
Intel Core i7-7820HQ compare2.9 - 3.9 GHz4 / 88 MB
Intel Core i7-7820HK compare2.9 - 3.9 GHz4 / 88 MB
Intel Core i7-7700HQ compare2.8 - 3.8 GHz4 / 86 MB
Intel Core i5-7500 compare3.4 - 3.8 GHz4 / 46 MB
Intel Core i5-7440HQ compare2.8 - 3.8 GHz4 / 46 MB
Intel Core i7-7567U compare3.5 - 4 GHz2 / 44 MB
Intel Core i7-7660U compare2.5 - 4 GHz2 / 44 MB
Intel Core i7-7600U compare2.8 - 3.9 GHz2 / 44 MB
Intel Core i5-7300HQ compare2.5 - 3.5 GHz4 / 46 MB
» Intel Core i5-7500T2.7 - 3.3 GHz4 / 46 MB
Intel Core i5-7287U compare3.3 - 3.7 GHz2 / 44 MB
Intel Core i7-7560U compare2.4 - 3.8 GHz2 / 44 MB
Intel Core i5-7267U compare3.1 - 3.5 GHz2 / 44 MB
Intel Core i5-7360U compare2.3 - 3.6 GHz2 / 44 MB
Intel Core i7-7500U compare2.7 - 3.5 GHz2 / 44 MB
Intel Core i5-7300U compare2.6 - 3.5 GHz2 / 43 MB
Intel Core i5-7260U compare2.2 - 3.4 GHz2 / 44 MB
Intel Core i5-7200U compare2.5 - 3.1 GHz2 / 43 MB
Intel Core i3-7100H compare3 GHz2 / 43 MB
Intel Core i3-7167U compare2.8 GHz2 / 43 MB
Intel Core i3-7130U compare2.7 GHz2 / 43 MB
Intel Core i7-7Y75 compare1.3 - 3.6 GHz2 / 44 MB
Intel Core i5-7Y57 compare1.2 - 3.3 GHz2 / 44 MB
Intel Core i5-7Y54 compare1.2 - 3.2 GHz2 / 44 MB
Intel Core i3-7100U compare2.4 GHz2 / 43 MB
Intel Core m3-7Y32 compare1 - 3 GHz2 / 44 MB
Intel Pentium Gold 4415U compare2.3 GHz2 / 42 MB
Intel Core m3-7Y30 compare1 - 2.6 GHz2 / 44 MB
Intel Celeron 3965U compare2.2 GHz2 / 22 MB
Intel Core i3-7020U compare2.3 GHz2 / 43 MB
Intel Celeron 3867U compare1.8 GHz2 / 22 MB
Intel Celeron 3865U compare1.8 GHz2 / 22 MB
Intel Pentium Gold 4425Y compare1.7 GHz2 / 42 MB
Intel Pentium Gold 4415Y compare1.6 GHz2 / 42 MB
Intel Pentium Gold 4410Y compare1.5 GHz2 / 42 MB
Intel Celeron 3965Y compare1.5 GHz2 / 22 MB
2900 - 3800 MHz2700 - 3300 MHz
256 KB256 KB
1 MB1 MB
8 MB6 MB
4 / 84 / 4
35 35
14 14
FCLGA1151FCLGA1151
DDR3(L)-1600/DDR4-2400 Memory Controller, AVX, AVX2, AES-NI, TSX-NI, Quick Sync, Virtualization, vProDDR3(L)-1600/DDR4-2400 Memory Controller, AVX, AVX2, AES-NI, TSX-NI, Quick Sync, Virtualization, vPro
iGPUIntel HD Graphics 630 (350 - 1150 MHz)Intel HD Graphics 630 (350 - 1100 MHz)
Architecturex86x86
$303 U.S.$202 U.S.
Intel Kaby Lake i7-7700TIntel Kaby Lake i5-7500T

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
714 Points (16%)
04080120160200240280320360400440480520560600640680714698.09688.9689.82687.6687.42687.96685.94687.42682.83681.92685.2682.49682.83685.75687.04684.84685.39687.59683.74686.67686.86687.59687.96684.29682.65683.01688.17686.31687.59687.4686.67686.67684.29685.39685.93683.74682.1686.86685.13688.33682.09686.14688.33687.4686.67684.84679.74684.46684.65Tooltip
512 Points (11%)
0306090120150180210240270300330360390420450480510509.2502.99504.97512.46508.39511.03506.48513.7511.33508.49511.43510.82511.44510.42510.11509.81511.54511.64514.11510.51510.63509.6511.03509.81509.5512.46512.46512.25510.61508.8511.03508.5512.66511.64510.31511.13512.45511.33512.45510.92Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
155 Points (57%)
129 Points (47%)
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
7.6 Points (15%)
5.9 Points (12%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.8 Points (56%)
1.5 Points (47%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
6824 (61%)
5002 (45%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
21587 (35%)
13614 (22%)
wPrime 2.10 - wPrime 2.0 1024m *
234 s (3%)
333 s (4%)
wPrime 2.10 - wPrime 2.0 32m *
6.9 s (1%)
10.5 s (2%)
WinRAR - WinRAR 4.0
4268 (27%)
X264 HD Benchmark 4.0 - x264 Pass 2
42.7 fps (19%)
X264 HD Benchmark 4.0 - x264 Pass 1
173 fps (51%)
TrueCrypt - TrueCrypt Serpent
0.4 GB/s (18%)
0.3 GB/s (11%)
TrueCrypt - TrueCrypt Twofish
0.7 GB/s (18%)
0.4 GB/s (12%)
TrueCrypt - TrueCrypt AES
4.4 GB/s (16%)
2.7 GB/s (10%)
Blender 2.79 - Blender 2.79 BMW27 CPU *
626 Seconds (4%)
3DMark 06 - CPU - 3DMark 06 - CPU
8273 Points (46%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
14.5 s (3%)
12 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
28.7 s (1%)
26.6 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
661 s (3%)
629 s (3%)
3DMark 11 - 3DM11 Performance Physics
8078 Points (30%)
6740 Points (25%)
3DMark - 3DMark Ice Storm Physics
33605 Points (22%)
3DMark - 3DMark Ice Storm Extreme Physics
50218 Points (53%)
3DMark - 3DMark Ice Storm Unlimited Physics
51843 Points (54%)
3DMark - 3DMark Cloud Gate Physics
4748 Points (12%)
3DMark - 3DMark Fire Strike Standard Physics
6773 Points (17%)
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
4342 (54%)
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
13974 (22%)
Sunspider - Sunspider 1.0 Total Score *
83.2 ms (1%)

Average Benchmarks Intel Core i7-7700T → 100% n=15

Average Benchmarks Intel Core i5-7500T → 82% n=15

- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
