Lenovo ThinkBook 16p G2 ACH-20YM001SPB

Specifications

Lenovo ThinkBook 16p G2 ACH-20YM001SPB
Lenovo ThinkBook 16p G2 ACH-20YM001SPB (ThinkBook 16p Series)
Processor
AMD Ryzen 5 5600H 6 x 3.3 - 4.2 GHz, Cezanne-H (Zen 3)
Graphics adapter
NVIDIA GeForce RTX 3060 Laptop GPU - 6 GB VRAM, Core: 1282 MHz, 75 W TDP, GDDR6
Memory
16 GB
, DDr4-3200
Display
16.00 inch 16:10, 2560 x 1600 pixel 189 PPI, IPS, glossy: no, 60 Hz
Storage
512GB SSD
Connections
2 USB 3.0 / 3.1 Gen1, 2 USB 3.1 Gen2, USB-C Power Delivery (PD), 2 DisplayPort, Audio Connections: 3.5mm, Card Reader: SD, 1 Fingerprint Reader
Networking
802.11 a/b/g/n/ac/ax (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/), Bluetooth 5.2
Size
height x width x depth (in mm): 19.9 x 356 x 252 ( = 0.78 x 14.02 x 9.92 in)
Battery
71 Wh Lithium-Polymer
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: FHD 1080p
Primary Camera: 2 MPix
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes
Weight
1.99 kg ( = 70.2 oz / 4.39 pounds) ( = 0 oz / 0 pounds)



Pricecompare

Reviews for the Lenovo ThinkBook 16p G2 ACH-20YM001SPB

Lenovo ThinkBook 16p Gen 2 review – one of the best content creator laptops on the market
Source: Laptop Media English
If this is how the future looks like, then we are really excited about it. Lenovo managed to combine the power of a gaming notebook, the style of a business device, and the versatility of a content creator machine into one sleek laptop. And it did it successfully. We saw a very good performance from the hardware we had on hand, with the only hiccup being the high temperature of the CPU after long periods of stress. But arguably the best feature in this regard is the MUX switch. It allows you to toggle between switchable graphics, and direct connection to the dedicated GPU, ensuring you take advantage of the full horsepower this laptop provides. Lenovo ThinkBook 16p Gen 2’s IPS panel (MNG007DA1-4 (LEN8A97)) has a high resolution, 16:10 aspect ratio, wide viewing angles, and a very good contrast ratio. Thankfully, it doesn’t use PWM for brightness adjustment. What is even more appealing for professionals, is the fact that it has a color accuracy that matches the sRGB standard with the help of our Gaming and Web design profile.
Single Review, online available, Very Long, Date: 01/11/2022

Comment

NVIDIA GeForce RTX 3060 Laptop GPU: High-End laptop graphics card based on the Ampere GA106 chip with 3072 cores. Available in different versions with a TDP from 60 to 115 Watt.

With these GPUs you are able to play modern and demanding games fluently at medium detail settings and HD resolution.

» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


R5 5600H: A mobile Hexa-Core APU with six Zen 3 cores clocked at 3.3 GHz to 4.2 GHz and a Vega iGPU with 7 CUs clocked at up to 1800 MHz.» Further information can be found in our Comparison of Mobile Processsors.


16.00":

15-inch display variants are the standard and are used for more than half of all laptops.

The reason for the popularity of mid-sized displays is that this size is reasonably easy on the eyes, often allows high resolutions and thus offers rich details on the screen, yet does not consume too much power and the devices can still be reasonably compact - simply the standard compromise.

» To find out how fine a display is, see our DPI List.


Lenovo: Lenovo ("Le" from English legend, novo (Latin) for new) was founded in 1984 as a Chinese computer trading company. As of 2004, the company was the largest laptop manufacturer in China and, after acquiring IBM's PC division in 2005, the fourth largest in the world. In addition to desktops and notebooks, the company manufactures monitors, projectors, servers, etc, and specializes in developing, manufacturing and marketing consumer electronics, personal computers, software, enterprise solutions and related services.

In 2016, the company ranked first in the world in computer sales. It still held it in 2023 with about 23% global market share. Important product lines are Thinkpad, Legion and Ideapad.

In 2011, it acquired a majority stake in Medion AG, a European computer hardware manufacturer. In 2014, Motorola Mobility was purchased, which gave Lenovo a boost in the smartphone market.


» Further information can be found in our Notebook Purchase Guide.
