Intel Pentium J2900

Intel J2900

The Intel Pentium J2900 is a power efficient quad-core SoC for desktops and nettops. It is clocked at 2.41 - 2.67 GHz and part of the Bay Trail-D platform. Thanks to the specially optimized 22 nanometer low-power process (P1271) with tri-gate transistors, performance and energy efficiency have been significantly improved compared to its predecessor.

Architecture

The processor cores are based on the new Silvermont architecture, which is an out-of-order design for the first time. The increased utilization of the pipeline and many other improvements (optimized branch prediction, increased buffers, enhanced decoders) have increased the performance per clock by about 50 percent. At the same time, however, the Hyper-Threading feature of the previous generation has been removed. Other major changes are the support for new instruction set extensions such as SSE 4.1 and 4.2 as well as AES-NI (depending on the model).

Performance

Thanks to 4 CPU cores and a clock speed of up to 2.67 GHz, the Pentium J2900 is significantly faster than previous Intel Atoms, e.g. the D2560. Presumably, the J2900 is just slightly slower than the AMD Kabini APU A6-5200. For everyday tasks such as Internet or Office the performance is adequate, but not for very complex software or modern games.

Graphics

The HD Graphics (Bay Trail) is based on the Intel Gen7 architecture, which supports DirectX 11 and is also found in the Ivy Bridge series (e.g. HD Graphics 4000). With only 4 EUs (Execution Units) and a relatively low clock speed of up 688 - 896 MHz, the GPU is even slower than the HD Graphics (Ivy Bridge). Therefore, only older and less demanding games will run fluently.

Power Consumption

The entire SoC is rated at a TDP of 10 watts. Thus, the chip can be used in compact nettops.

SeriesIntel Pentium
CodenameBay Trail-D
Series: Pentium Bay Trail-D
» Intel Pentium J29002410 - 2667 MHz4 / 4
Intel Pentium J2850 compare2400 MHz4 / 4
Clock Rate2410 - 2667 MHz
Level 1 Cache224 KB
Level 2 Cache2 MB
Number of Cores / Threads4 / 4
Power Consumption (TDP = Thermal Design Power)10 Watt
Manufacturing Technology22 nm
Max. Temperature105 °C
FeaturesHD Graphics (Bay Trail, 688 - 896 MHz), Dual-Channel DDR3(L)-1333 Memory Controller, CPU Burst
GPUIntel HD Graphics (Bay Trail) (688 - 896 MHz)
64 Bit64 Bit support
Starting Price$94 U.S.
Announcement Date11/01/2013
Product Link (external)Intel Pentium J2900
