Qualcomm Snapdragon 610 MSM8936

The Qualcomm Snapdragon 610 MSM8936 is a mid-range ARMv8-based SoC largely for Android tablets and smartphones. Announced in February 2014, the S610 is one of the first 64-bit capable SoCs from Qualcomm. In addition to 4 Cortex-A53 CPU cores at up to 1.7 GHz, the SoC integrates an Adreno 405 GPU with a 2x 32-bit memory controller (LPDDR3-1600, 12.8 GB/s) and supports Wi-Fi (802.11ac), Bluetooth 4.0, UMTS and LTE.

CPU

The Cortex-A53 is the successor to the very popular Cortex-A7 design. In addition to the new 64-bit capable ARMv8 ISA, the cores offer a variety of other improvements such as better branch prediction. This leads to a significantly higher performance per clock, which is even above the older Cortex-A9.

The four cores of the Snapdragon 610 are clocked at up to 1.7 GHz, offering a performance similar to that of the older Snapdragon 600 (Krait architecture).

GPU

Another new feature is the integrated graphics unit named Adreno 405 (550 MHz). The Adreno 400 series has been substantially redesigned and supports DirectX 11.2 (FL 11_1) including hardware tessellation, OpenGL ES 3.1, and OpenCL 1.2. Furthermore, the performance has been significantly improved, which is now similar to the Adreno 320 and PowerVR G6200.

Features

The Snapdragon 610 offers numerous wireless technologies such as Bluetooth 4.0 and WLAN 802.11a/b/g/n/ac as well as a Multi-SIM cellular modem supporting LTE cat. 4 (up to 150 Mbps), WCDMA, CDMA, EV-DO, TD-SCDMA and GSM/EDGE.

The SoC can encode and decode 1080p videos using dedicated hardware and stream content to displays with up to 2560 x 1600 pixels. A large number of video codecs including H.265 (playback only) will be supported. The camera ISP can handle sensors with up to 21 MP.

Power Consumption

The Snapdragon 610 is manufactured by TSMC in a 28 nm LP process. According to the specifications, we expect a medium power consumption for use in medium-sized smartphones and tablets.

Codename	Cortex-A53
Series	Qualcomm Snapdragon
Series: Snapdragon Cortex-A53 Qualcomm Snapdragon 630 2.2 GHz 8 / 8  Cortex-A53 Qualcomm Snapdragon 626 2.2 GHz 8 / 8  Cortex-A53 Qualcomm Snapdragon 625 2 GHz 8 / 8  Cortex-A53 Qualcomm Snapdragon 439 2 GHz 8 / 8  Cortex-A53 Qualcomm Snapdragon 450 1.8 GHz 8 / 8  Cortex-A53 Qualcomm Snapdragon 429 2 GHz 4 / 4  Cortex-A53 Qualcomm Snapdragon 617 MSM8952 1.5 GHz 8 / 8  Cortex-A53 Qualcomm Snapdragon 616 MSM8939v2 1.7 GHz 8 / 8  Cortex-A53 Qualcomm Snapdragon 615 MSM8939 1.7 GHz 8 / 8  Cortex-A53 Qualcomm Snapdragon 610 MSM8936 « 1.7 GHz 4 / 4  Cortex-A53 Qualcomm Snapdragon 435 1.4 GHz 8 / 8  Cortex-A53 Qualcomm Snapdragon 430 (MSM8937) 1.4 GHz 8 / 8  Cortex-A53 Qualcomm Snapdragon 415 MSM8929 1.4 GHz 8 / 8  Cortex-A53 Qualcomm Snapdragon 425 (MSM8917) 1.4 GHz 4 / 4  Cortex-A53 Qualcomm Snapdragon 410 MSM8916 1.4 GHz 4 / 4  Cortex-A53 Qualcomm Snapdragon 410 APQ8016 1.2 GHz 4 / 4  Cortex-A53
Clock Rate	1700 MHz
Number of Cores / Threads	4 / 4
Manufacturing Technology	28 nm
Features	Adreno 405 GPU, 802.11ac WLAN, Bluetooth 4.0, LTE Cat. 4, NFC, GPS/GLOSNASS/BeiDou, 2x 32 Bit LPDDR2/3 Memory Controller
GPU	Qualcomm Adreno 405 ( - 550 MHz)
64 Bit	64 Bit support
Architecture	ARM
Announcement Date	02/24/2014
Product Link (external)	www.qualcomm.com

Benchmarks

- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

No reviews found for this CPU (yet).
