Lenovo Thinkpad T480-20L5000BMH

Specifications

Lenovo Thinkpad T480-20L5000BMH
Lenovo Thinkpad T480-20L5000BMH (ThinkPad T480 Series)
Processor
Intel Core i7-8550U 4 x 1.8 - 4 GHz, Kaby Lake Refresh
Graphics adapter
Memory
16384 MB
Display
15.00 inch 16:9, 2560 x 1440 pixel 196 PPI, glossy: no
Storage
512 GB SSD
Connections
4 USB 3.2 Gen 2x2 20Gbps, 1 HDMI
Networking
802.11 a/b/g/n/ac (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5), Bluetooth 4.1
Size
height x width x depth (in mm): 19.95 x 336.6 x 232.5 ( = 0.79 x 13.25 x 9.15 in)
Operating System
Microsoft Windows 10 Pro 64 Bit
Additional features
Keyboard Light: yes
Weight
1.7 kg ( = 59.97 oz / 3.75 pounds) ( = 0 oz / 0 pounds)



Pricecompare

Average Score: 40% - bad
Average of 1 scores (from 1 reviews)

Reviews for the Lenovo Thinkpad T480-20L5000BMH

40% Lenovo ThinkPad T480 20L5000BMH
Source: Tweakers Dutch NL→EN
Single Review, online available, Very Short, Date: 08/08/2020
Rating: Total score: 40%

Comment

Series:

The Lenovo ThinkPad T480 is a business laptop that is robust yet light enough to accompany users everywhere. Lenovo’s ThinkPad laptop offers a lot of customization when it comes to hardware components. This means that a user can customize the business notebook to fit their personal needs. The secondary battery, which can be added to the main internal battery, is a special feature here. As a genuine business notebook, the T480 has several security features to offer: Besides the almost-obligatory TPM-2.0 module and Kensington lock, the T480 also has many other features, such as NFC, an optional SmartCard reader, and the always-included fingerprint reader. The fingerprint scanner works flawlessly with Windows Hello. The manufacturer relies on a black case with a seemingly rubberized surface. This is why the device is very easy to hold, though it does make the laptop very susceptible to smudges. The chassis is made of tough plastic and is therefore very rigid. The hinges have no problem holding the display lid in a set position and have an opening angle of 180 degrees. When it comes to the dimensions, the ThinkPad T480 is almost identical to its predecessor, the T470. However, the additional battery has quite an impact on the overall weight of the device - the relatively high overall weight of 1.8 kg (3.96 lb) can be attributed to the 48-Wh ancillary battery.

The T480 comes with an Intel Core i5-8350U CPU, an Nvidia MX150 GPU, 8 GB of RAM and a 256GB PCIe SSD. This is why the business notebook can be used not only for simple office work but also for image and video editing and, to a very limited extent, for gaming. Besides that, the 720p lens on the ThinkPad T480 captures images with solid colors and brightness for a built-in webcam. In terms of the ports, only slight changes were made when compared to the Lenovo T470: On the left-hand side, a previously-available USB Type-A port has been replaced by a Docking port, which used to be located on the underside. Many extras from Lenovo can be connected through this port. This is why the number of normal USB-3.0 Type-A ports has been reduced to only two. That being said, the Docking port is connected via Thunderbolt 3. The power jack has also been removed. The ThinkPad T480 is now charged via a USB Type-C port. The ThinkPad T480 is the battery-life king: With its six-cell, 72-watt-hour battery attached, the T480 lasted 17 hours, which involves continuous web surfing over Wi-Fi. Because the ThinkPad T480 uses Lenovo's hot-swappable Power Bridge battery system, users can even carry extra batteries with them and swap them in without shutting the laptop down.

Hands-on article by Jagadisa Rajarathnam

NVIDIA GeForce MX150: Pascal GP108 based laptop graphics card and mobile version of the desktop GeForce GT 1030. Offers 384 shader cores and usually 2 GB GDDR5 with a 64 Bit memory bus. Manufactured in 14nm.

Modern games should be playable with these graphics cards at low settings and resolutions. Casual gamers may be happy with these cards.

» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i5-8550U: Kaby-Lake-Refresh based low power quad-core processor. The four cores are clocked between 1.8 and 4 GHz (Turbo Boost) and support HyperThreading. The integrated GPU is clocked between 300 and 1,150 MHz. The SoC is manufactured in a 14nm+ FinFET process.» Further information can be found in our Comparison of Mobile Processsors.


15.00":

This display size represents a treshold between the small sizes of subnotebooks and ultrabooks and the standard-sizes of office- and multimedia laptops on the other hand. Laptops with that size are somewhat rare, nowadays.

» To find out how fine a display is, see our DPI List.


1.7 kg:

This weight is typical for very big tablets, subnotebooks, ultrabooks and convertibles with a 11-13 inch display-diagonal.


Lenovo: Lenovo ( "Le" as in the English word legend and "novo" (Latin) for new) was founded in 1984 as a Chinese computer trading company. From 2004, the company has been the largest laptop manufacturer in China and got the fourth largest manufacturer worldwide after the acquisition of IBM's PC division in 2005. In addition to desktops and notebooks, the company also produces monitors, projectors, servers, etc.

In 2011, Lenovo acquired the majority of Medion AG, a European computer hardware manufacturer. In 2014, Lenovo took over Motorola Mobility, which gave them a boost in the smartphone market.

From 2014 to 2016 Lenovo's market share in the global notebook market was 20-21%, ranking second behind HP. However, the distance decreased gradually. In the smartphone market, Lenovo did not belong to the Top 5 global manufacturers in 2016.


40%: This average evaluation is exceptionally bad. There exist hardly any laptops, which are rated so negative.


» Further information can be found in our Notebook Purchase Guide.
