Intel Core i3-3130M

Intel 3130M

The Intel Core i3-3130M is a dual-core processor for laptops based on the Ivy Bridge architecture. Due to Hyperthreading, the two cores can handle up to four threads in parallel leading to better utilization of the CPU. Each core offers a base speed of 2.6 GHz, Turbo Boost is not supported. As its Sandy-Bridge-based predecessors, it offers a 3 MB L3-Cache.

Ivy Bridge is an enhanced die shrink of the Sandy Bridge architecture with improvements on both GPU and CPU performance. The CPUs are produced in 22nm (versus 32nm Sandy Bridge CPUs) and are the first to introduce 3D transistors for increased energy efficiency when compared to similarly clocked Sandy Bridge processors. Other new features are integrated PCI Express 3.0 and  DDR3(L)-1600 support.

The performance of the Core i3-3130M is slightly above a similarly clocked Sandy Bridge processor due to slight architectural improvements. As a result, overall performance should be about 10-15 % faster compared to the old i3-2370M. Thanks to their Turbo Boost, Core-i5-models like the i5-3210M are significantly faster.

The integrated Intel HD Graphics 4000 offers 16 Execution Units (EUs) clocked at 650 MHz up to 1100 MHz with Turbo Boost. Therefore, the performance should be similar to the AMD Radeon HD 6620G.

Just like most other Ivy Bridge dual-cores, the i3-3130M is rated at a TDP of 35 W. Therefore, even smaller laptops can use the Core i3.

SeriesIntel Core i3
CodenameIvy Bridge
Clock Rate2600 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache3072 KB
Number of Cores / Threads2 / 4
Max. Power Consumption (TDP = Thermal Design Power)35 Watt
Manufacturing Technology22 nm
Max. Temperature90 °C
SocketFCBGA1023, FCPGA988
FeaturesHD Graphics 4000 (650-1100MHz), DDR3-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1100 MHz)
64 Bit64 Bit support
Hardware VirtualizationVT-x
Starting Price $225 U.S.
Announcement Date01/25/2013
Product Link (external)Intel Core i3 3130M
